JVC HA-RF100S - Electrical Parts List

HA-RF100S(J)
22
Trandmitter
7. Electrical parts list
Receiver (Headphones)
Speakers
In case of some problem arise in this transmitter unit, have to change the transmitter unit itself,
due to avoid the law radio regulation.
* Parts marked (A) ave safety parts. When replacing, be sure to use the specifide one.
* Parts marked (A) ave safety parts. When replacing, be sure to use the specifide one.
* Parts marked (A) ave safety parts. When replacing, be sure to use the specifide one.
A Symbol No. Parts No. Parts Name Description
A J22015-001 Transmitter Unit Adjusted
A Symbol No. Parts No. Parts Name Description
A J22016-001 P.C.B. Ass'y Adjusted
D3 J46520-001 LED ST.Indicator
D4 J46520-001 LED Power Indicator
VR1 J46521-001 Variable Resistor Tuning control
VR2 J46522-001 Variable Resistor Volume control
A JX1 J46523-001 DC IN Jack Charging Input Jack
SW1 J46532-001 Switch Power switch
A Symbol No. Parts No. Parts Name Description
A J33591-001
Main P.C.B. Ass'y(L) Adjusted
A J33592-001
Main P.C.B. Ass'y(R) Adjusted
A J46929-001 SW. P.C.B. Ass'y
A J46917-001
Power P.C.B. Ass'y
VR2 J46925-001 Variable Resistor Volume control
SW1 J46926-001 Push Switch Boost Bass
SW3 J46927-001 Push Switch Aute Tuning
A JX2 J46298-001 DC IN jack
SP-1 J33558-001 10cm SPK Unit Wooter
SP-2 J33559-001 5cm SPK Unit Tweeter
