2
PACKING AND ACCESSORY ASSEMBLY <M1>
!
REF. MODEL
HR-J680EU HR-J580EU HR-J581EU HR-J587EU HR-J588EU HR-J589EU
NO. ITEM
Notes : Mark — is not used.
Mark is same as left.
301 PACKING CASE LP30855-001A LP30897-001A
302 CUSHION ASSY LP30909-001B LP30898-001A
306 REMOTECONTROLLER LP20878-002A LP20878-003A
306A COVER(BATTERY) LP40610-002A LP40610-001A
! 310 INST BOOK(EN) LPT0482-001A LPT0481-001A LPT0482-001A
! INST BOOK(GE) LPT0482-002A LPT0481-002A LPT0482-002A
! INST BOOK(FR) LPT0482-003A LPT0481-003A LPT0482-003A
! INST BOOK(DU) LPT0482-004A LPT0481-004A LPT0482-004A
! INST BOOK(SP) LPT0482-005A LPT0481-005A LPT0482-005A
! INST BOOK(IT) LPT0482-006A LPT0481-006A LPT0482-006A
! INST BOOK(DA) LPT0482-007A LPT0481-007A LPT0482-007A
! INST BOOK(FI) LPT0482-008A LPT0481-008A LPT0482-008A
! INST BOOK(SW) LPT0482-009A LPT0481-009A LPT0482-009A
! INST BOOK(NO) LPT0482-010A LPT0481-010A LPT0482-010A
! INST BOOK(PT) LPT0482-011A LPT0481-011A LPT0482-011A
! INST BOOK(GR) LPT0482-012A LPT0481-012A LPT0482-012A
! INST BOOK(CZ) LPT0482-013A LPT0481-013A LPT0482-013A
! INST BOOK(PO) LPT0482-014A LPT0481-014A LPT0482-014A
! INST BOOK(HU) LPT0482-015A LPT0481-015A LPT0482-015A
[HR-J580EU/J581EU/J587EU/J588EU/J589EU]
The following tables indicate main different points between models HR-J680EU and HR-J580EU,HR-J581EU,HR-587EU,HR-J588EU,HR-J589EU.
MODEL
HR-J680EU HR-J580EU HR-J581EU HR-J587EU HR-J588EU HR-J589EU
ITEM
SAT_CTL USED NOT USED NOT USED USED
PLUG &PLAY AUTO SET.AUTO CLOK AUTO TUNE AUTO TUNE AUTO SET.AUTO CLOK
VCR PLUS+ VIDEO PLUS+ DELUXE VIDEO PLUS VIDEO PLUS VIDEO PLUS+ DELUXE
AUTO CLOCK/JUST CLOCK USED NOT USED NOT USED USED
REC LINK USED NOT USED NOT USED USED
FRONT PANEL color PURE SILVER BLACK&GRAY PURE SILVER BLACK BLACK&GOLD
DISPLAY WINDOW color LIGHT GRAY SMOKE GRAY
FRONT PANEL color SILVER BLACK SILVER BLACK
The following tables indicate different parts number between models HR-J680EU and HR-J580EU,HR-J581EU,HR-J587EU,HR-J588EU,HR-J589EU.
FINAL ASSEMBLY <M2>
!
REF. MODEL
HR-J680EU HR-J580EU HR-J581EU HR-J587EU HR-J588EU HR-J589EU
NO. ITEM
! 501 FRONT PANEL ASSY LP10333-001B LP10293-025B LP10293-037A LP10293-036A LP10293-026B LP10293-027B
501A CASSETTE DOOR LP20961-001A LP20868-031A LP20868-032A LP20868-031A LP20868-032A LP20868-036A
501C BUTTON(OPE) LP30798-001A ——— — —
501D DISPLAY WINDOW — LP20869-081B LP20869-097A LP20869-096A LP20869-082B LP20869-083B
501E ORNAMENT — LP30649-005A LP30649-002A LP30649-005A LP30649-002A
! 502 TOP COVER LP10013-051A PQ11898-52-23 PQ11898-50-23 PQ11898-52-23 PQ11898-50-23
503 SCREW,X4 TOP COVER(SIDE) QYTDSF3010R QYTDSF3010M QYTDSF3010R QYTDSF3010M
! 511 BOTTOM CHASSIS LP10108-001E LP21026-001B
! 512 BOTTOM COVER LP10014-002B PQ11899-3-7
534 PC SUPPORT,MINI FRONT — LP40628-001B
535 BRACKET — LP40854-001A
536 SCREW — QYTDSF3010Z
WR3 FF WIRE,MINI FRONT — QUQ112-0914CG
MAIN BOARD ASSEMBLY <03>
!
REF. MODEL
HR-J680EU HR-J580EU HR-J581EU HR-J587EU HR-J588EU HR-J589EU
NO. ITEM
PW1 MAIN BOARD ASSY LPA10131-01D1 LP10131-10F1 LP10131-06E1
MINI FRONT BOARD ASSEMBLY <28>
!
REF. MODEL
HR-J680EU HR-J580EU HR-J581EU HR-J587EU HR-J588EU HR-J589EU
NO. ITEM
PW1 MINI FRONT BOARD ASSY — LPA20005-01A
SAT_CTL BOARD ASSEMBLY <92>
!
REF. MODEL
HR-J680EU HR-J580EU HR-J581EU HR-J587EU HR-J588EU HR-J589EU
NO. ITEM
PW4 SAT_CTL BOARD ASSY LPA10131-01A4 ——LPA10131-01A4
