SPECIFICATIONS
GENERAL
Power requirement : AC 220 – 240 V`, 50/60 Hz
Power consumption : 24 W
Temperature
Operating : 5°C to 40°C
Storage : –20°C to 60°C
Operating position : Horizontal only
Dimensions (WxHxD) : 400 x 94 x 340 mm
Weight : 4.3 kg
Format : VHS standard
Maximum recording time
(SP) : 240 min. with E-240 video cassette (PAL/
MESECAM)
: 160 min. with T-160 video cassette (NTSC)
(LP) : 480 min. with E-240 video cassette (PAL/
MESECAM)
(EP) : 480 min. with T-160 video cassette (NTSC)
VIDEO/AUDIO
Signal system : PAL-type colour signal and CCIR monochrome
signal, 625 lines 50 fields
: NTSC colour and EIA monochrome signals,
525 lines/60 fields
Recording system : DA-4 (Double Azimuth) head helical scan system
Signal-to-noise ratio : 45 dB
Horizontal resolution : 250 lines (PAL/MESECAM)
: 220 lines (NTSC)
Frequency range : 70 Hz to 10,000 Hz (Normal audio)
20 Hz to 20,000 Hz (Hi-Fi audio)
Input/Output : RCA connectors (IN x 2, OUT x 1)
TUNER/TIMER
TV channel storage
capacity : 48 positions (+AUX position "AU")
Tuning system : Voltage synthesized tuner
Channel coverage : AUS NZ
VHF 44 – 153 MHz CH 0 – 5, 5A, CATV CH 1 – 3, CATV
153 – 470 MHz CH 6 – 11, CATV CH 4 – 11, CATV
UHF 470 – 862 MHz CH 28 – 69 CH 21 – 69
Aerial output : UHF channel 37 (Adjustable 33 – 41)
Memory backup time : Approx. 18 hours.
ACCESSORIES
Provided accessories : RF cable, Infrared remote control unit,
"R6/UM-3" battery x 2, Audio/Video cable
Specifications shown are for SP mode unless otherwise specified.
Design and specifications subject to change without notice.
