JVC HX-D77UJ - Page 29

2-11
Front board
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
reverse side
Front VFD board Front key board
Jog LED boardVolume LED boardUSB LED board
UIC01
UIC02
