3-10
AMP board
Block No. [0][2]
UR144 2001-000786 C RESISTOR 47K Ω 1/8W
UR145 2001-000786 C RESISTOR 47K Ω 1/8W
UR146 2001-000786 C RESISTOR 47K Ω 1/8W
UR147 2001-000786 C RESISTOR 47K Ω 1/8W
UR148 2001-000786 C RESISTOR 47K Ω 1/8W
UR149 2001-000786 C RESISTOR 47K
Ω 1/8W
UR150 2001-000429 C RESISTOR 1K
Ω 1/8W
UR151 2001-000290 C RESISTOR 10K Ω 1/8W
UR152 2001-000290 C RESISTOR 10K Ω 1/8W
UR153 2001-000290 C RESISTOR 10K Ω 1/8W
UR154 2001-000290 C RESISTOR 10K Ω 1/8W
UR155 2001-000290 C RESISTOR 10K Ω 1/8W
UR156 2001-000290 C RESISTOR 10K Ω 1/8W
UR157 2001-000290 C RESISTOR 10K Ω 1/8W
UR158 2001-000290 C RESISTOR 10K Ω 1/8W
UR159 2001-000290 C RESISTOR 10K Ω 1/8W
UR160 2001-000290 C RESISTOR 10K Ω 1/8W
UR161 2001-000429 C RESISTOR 1K Ω 1/8W
UR162 2001-000429 C RESISTOR 1K Ω 1/8W
UR163 2001-000429 C RESISTOR 1K Ω 1/8W
UR172 2001-000281 C RESISTOR 100
Ω 1/8W
UR173 2001-000281 C RESISTOR 100
Ω 1/8W
UR174 2001-000281 C RESISTOR 100 Ω 1/8W
UR175 2001-000281 C RESISTOR 100 Ω 1/8W
UR176 2001-000281 C RESISTOR 100 Ω 1/8W
UR177 2001-000295 C RESISTOR 10M Ω 1/8W
UR178 2001-000850 C RESISTOR 560K Ω 1/8W
UR179 2001-000435 C RESISTOR 1M Ω 1/8W
UR180 2001-000449 C RESISTOR 2.2K Ω 1/8W
UR181 2001-000734 C RESISTOR 4.7K Ω 1/8W
UR182 2001-000508 C RESISTOR 220K Ω 1/8W
UR183 2001-000793 C RESISTOR 47 Ω 1/8W
UR184 2001-000734 C RESISTOR 4.7K Ω 1/8W
UR186 2001-000780 C RESISTOR 470K Ω 1/8W
UR187 2001-000780 C RESISTOR 470K Ω 1/8W
VR101 3406-001047 ROTARY SWITCH 5V DC 0.5mA
BZ101 3002-001134 BUZZER 85DB 12V
FW101 3708-001939 CONNECTOR 32P
FW102 3708-001696 CONNECTOR 24P
FW201 3708-001696 CONNECTOR 24P
FW202 3711-003408 CONNECTOR 2P
FW203 3711-003409 CONNECTOR BOX 3P
FW204 3711-003409 CONNECTOR BOX 3P
FW301 AH39-00108A LEAD CONNECTOR 2P
FW302 AH39-00479A WIRE HARNESS 3P
FW303 AH39-00479A WIRE HARNESS 3P
PS102 3406-001050 ROTARY SWITCH
5V DC 0.5mA
12mm
REYE1 0609-001187 MODULE REMOCON
SW201 3404-000165 TACT SWITCH 12V 50mA
SW202 3404-000165 TACT SWITCH 12V 50mA
SW203 3404-000165 TACT SWITCH 12V 50mA
SW204 3404-000165 TACT SWITCH 12V 50mA
SW205 3404-000165 TACT SWITCH 12V 50mA
SW206 3404-000165 TACT SWITCH 12V 50mA
SW207 3404-000165 TACT SWITCH 12V 50mA
SW208 3404-000165 TACT SWITCH 12V 50mA
SW209 3404-000165 TACT SWITCH 12V 50mA
SW210 3404-000165 TACT SWITCH 12V 50mA
SW211 3404-000165 TACT SWITCH 12V 50mA
SW212 3404-000165 TACT SWITCH 12V 50mA
SW213 3404-000165 TACT SWITCH 12V 50mA
SW214 3404-000165 TACT SWITCH 12V 50mA
SW215 3404-000165 TACT SWITCH 12V 50mA
SW216 3404-000165 TACT SWITCH 12V 50mA
SW217 3404-000165 TACT SWITCH 12V 50mA
SW218 3404-000165 TACT SWITCH 12V 50mA
SW219 3404-000165 TACT SWITCH 12V 50mA
SW220 3404-000165 TACT SWITCH 12V 50mA
SW221 3404-000165 TACT SWITCH 12V 50mA
SW222 3404-000165 TACT SWITCH 12V 50mA
SW223 3404-000165 TACT SWITCH 12V 50mA
SW224 3404-000165 TACT SWITCH 12V 50mA
SW225 3404-000165 TACT SWITCH 12V 50mA
SW226 3404-000165 TACT SWITCH 12V 50mA
UW001 3708-000448 CONNECTOR 6P 1.25mm
UX101 2801-001394 CRYSTAL 32.768KHz
 Symbol No. Part No. Part Name Description Local
UX102 2802-001198 C RESONATOR 10MHz
VFD1 AH07-00152B VFD DISPLAY BN016GNK
 Symbol No. Part No. Part Name Description Local
AIC01 1204-002519 IC STA308A
AIC02 1203-003526 IC KIA7029AP
EIC02 1002-001448 IC AK5358ET
FIC01 1204-002518 IC R2S15904SP
FIC02 1201-002414 IC STA508
HIC01 1201-000163 IC BA4560
JIC01 1205-002894 IC PCM2704DBR
VIC01 1201-002085 IC MM1623XFBE
WIC01 1201-002414 IC STA508
WIC02 1201-002414 IC STA508
XIC01 AH14-10004R IC M74HCU04
AQ101 KSC2331 TRANSISTOR 0501-000369
AQ102 KTA1273 TRANSISTOR 0501-000422
EQ101 KTD1304 TRANSISTOR 0501-002184
HQ002 KTD1304 TRANSISTOR 0501-002184
HQ01L KTD1304 TRANSISTOR 0501-002184
HQ01R KTD1304 TRANSISTOR 0501-002184
SQ102 KSC2331 TRANSISTOR 0501-000369
SQ103 KSC2331 TRANSISTOR 0501-000369
SQ104 KTC3199-Y TRANSISTOR 0501-000014
SQ105 KTC3199-Y TRANSISTOR 0501-000014
SQ106 KSR2103 DIGI TRANSISTOR 0504-000156
SQ107 KTA1268 TRANSISTOR 0501-000630
ED101 1SR154 DIODE 0402-000309
ED102 1SS355 DIODE 0401-001090
SD101 1SS355 DIODE 0401-001090
SD102 1SS355 DIODE 0401-001090
SZ102 RLZ5.6A Z DIODE 0403-001008
SZ103 RLZ5.6A Z DIODE 0403-001008
SZ104 RLZ7.5B Z DIODE 0403-000622
SZ105 1N4739A Z DIODE 0403-000145
SZ106 UZP33B Z DIODE 0403-000390
AE101 2401-001508 E CAPACITOR 47uF 16V
AE102 2401-000048 E CAPACITOR 47uF 25V
EC01L 2203-000575 CHIP CAPACITOR 220nF 25V
EC01R 2203-000575 CHIP CAPACITOR 220nF 25V
EC02L 2203-000575 CHIP CAPACITOR 220nF 25V
EC02R 2203-000575 CHIP CAPACITOR 220nF 25V
EC03L 2203-001036 CHIP CAPACITOR 5.6nF 50V
EC03R 2203-001036 CHIP CAPACITOR 5.6nF 50V
EC101 2203-000206 CHIP CAPACITOR 100nF 50V
EC102 2203-000206 CHIP CAPACITOR 100nF 50V
EC103 2203-000206 CHIP CAPACITOR 100nF 50V
EC105 2203-000206 CHIP CAPACITOR 100nF 50V
EC106 2203-001596 CHIP CAPACITOR 2200nF 50V
EC107 2203-000206 CHIP CAPACITOR 100nF 50V
EE005 2401-000414 E CAPACITOR 10uF 16V
EE006 2401-000414 E CAPACITOR 10uF 16V
EE007 2401-002042 E CAPACITOR 220uF 10V
EE008 2401-002042 E CAPACITOR 220uF 10V
EE009 2401-001952 E CAPACITOR 4.7uF 50V
EE010 2401-001952 E CAPACITOR 4.7uF 50V
EE011 2401-001931 E CAPACITOR 220nF 50V
EE01L 2401-000650 E CAPACITOR 2.2uF 50V
EE01R 2401-000650 E CAPACITOR 2.2uF 50V
EE02L 2401-000598 E CAPACITOR 1uF 50V
EE02R 2401-000598 E CAPACITOR 1uF 50V
EE03L 2401-000598 E CAPACITOR 1uF 50V
EE03R 2401-000598 E CAPACITOR 1uF 50V
EE04L 2401-000598 E CAPACITOR 1uF 50V
EE04R 2401-000598 E CAPACITOR 1uF 50V
EE06L 2401-000588 E CAPACITOR 1uF 50V
EE06R 2401-000588 E CAPACITOR 1uF 50V
 Symbol No. Part No. Part Name Description Local
