Wiring
Block No. [0][3]
DVD servo board (FMU-SM1-25M)
Block No. [0][4]
WR10R 2007-000312 CHIP RESISTOR 10 Ω 1/4W
XR101 2007-000477 CHIP RESISTOR 1M Ω
XR102 2007-000931 CHIP RESISTOR 470 Ω
FL01L AH27-00061A COIL FILTER 45m Ω
FL01R AH27-00061A COIL FILTER 45m Ω
FL02L AH27-00061A COIL FILTER 45m Ω
FL02R AH27-00061A COIL FILTER 45m Ω
JL001 2702-000112 COIL 10uH
WL01L AH27-00062A COIL FILTER 45m Ω
WL01R AH27-00062A COIL FILTER 45m Ω
WL02L AH27-00062A COIL FILTER 45m Ω
WL02R AH27-00062A COIL FILTER 45m Ω
WL03L AH27-00062A COIL FILTER 45m Ω
WL03R AH27-00062A COIL FILTER 45m Ω
WL04L AH27-00062A COIL FILTER 45m Ω
WL04R AH27-00062A COIL FILTER 45m Ω
BEAD1 3301-001345 FERRITE BEADS 600 Ω 300mA
CHGND AH39-50001N HARNESS WIRE 250MM
CN101 3708-001939 CONNECTOR 32P
CN102 3711-000724 CONNECTOR 15P
CN103 3708-001761 CONNECTOR 28P
CN104 3708-000347 CONNECTOR 10P 1MM
CN106 AH39-00295B CONNECT WIRE
9P for SMPS
SMCN01
CN107 AH39-00885A CONNECT WIRE
15P for SMPS
SMCN02
CN108 3711-000820 CONNECTOR 2P 1R 2.5mm
EL101 3301-001345 FERRITE BEADS 600 Ω 300mA
EL102 3301-001345 FERRITE BEADS 600 Ω 300mA
FL003 3301-001345 FERRITE BEADS 600 Ω 300mA
FL03L AH29-00014A LINE FILTER PLF1109-002
FL03R AH29-00014A LINE FILTER PLF1109-002
GND1 AH38-00013A WIRE 250MM
GND5 AH39-50001L LEAD FASTEN
RING4 200MM
BLK
HL01L 3301-001345 FERRITE BEADS 600 Ω 300mA
HL01R 3301-001345 FERRITE BEADS 600 Ω 300mA
ML101 3301-001345 FERRITE BEADS 600 Ω 300mA
ML102 3301-001345 FERRITE BEADS 600 Ω 300mA
ML103 3301-001345 FERRITE BEADS 600 Ω 300mA
ML104 3301-001345 FERRITE BEADS 600 Ω 300mA
SP101 3716-001208 TERMINAL BLOCK 8P
TU101 AH40-00123A TUNER
UX103 2801-004396 CRYSTAL UNIT 12.0MHz 30ppm
VJ102 3722-002145 PIN JACK 1P VHS+PIN
VJ103 3707-001060 CONNECTOR 3P
WL05L 3301-001345 FERRITE BEADS 600 Ω 300mA
WL05R 3301-001345 FERRITE BEADS 600
Ω 300mA
XT101 2801-004354 CRYSTAL 12.288MHZ
ZJ101 3722-002310 PIN JACK 3P
ZJ102 3722-002292 USB JACK 4P/1P
ZJ103 3722-001588 PHONE JACK 7P 3.6PI AG BLK
ZW101 AH39-00862A LEAD CONNECTOR
15P for AMP
CN102
 Symbol No. Part No. Part Name Description Local
XXXXX 3301-000132 FERRITE BEADS (x3)
XXXXX 3809-001452 FLAT CABLE
24P KEY FW201to
VED FW102
XXXXX 3809-001718 FLAT CABLE
10P for AMP
CN104 to DVD
XXXXX 3809-001720 FLAT CABLE
28P for AMP
CN103 to DVD
XXXXX 3809-001823 FLAT CABLE
32P for VFD
FW101 to AMP
CN101
 Symbol No. Part No. Part Name Description Local
 Symbol No. Part No. Part Name Description Local
IC201 LA6502-X IC
IC301 MN2DS0009AA IC
IC302 MM1701CH-X IC
IC305 MM1563BF-X IC 3.1V Regulator
IC451 MN101C61GNW IC
IC452 BR93L56RFV-W-X IC(DIGITAL)
IC453 S-80827CNNB-G-W IC
IC505 K4S641632H-UC75 IC
IC505 or HY57V641620ETP7 IC(DIGITAL)
IC505 or K4S641632K-UC75 IC
IC509 SG32M90TFICA600 IC(MICRO C ROM)
IC510 BR24L16FV-W-X IC(DIGITAL)
IC701 AK4384ET-X IC
IC705 MM1615AN-X IC
Q101 KTA1001/Y/-X TRANSISTOR
Q101 or 2SB1424/R/-W TRANSISTOR
Q102 2SC4617/R/-X TRANSISTOR
Q103 KTA1001/Y/-X TRANSISTOR
Q103 or 2SB1424/R/-W TRANSISTOR
Q104 2SC4617/R/-X TRANSISTOR
Q105 UN2119-X TRANSISTOR
Q105 or KRA116S-X TRANSISTOR
C101 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C102 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C103 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C104 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C105 NEAF0JM-476X E CAPACITOR 47uF 6.3V M
C106 NBE20JM-226X TA E CAPACITOR 22uF 6.3V M
C107 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C108 NBE20JM-226X TA E CAPACITOR 22uF 6.3V M
C201 NDC31HJ-221X C CAPACITOR 220pF 50V J
C202 NDC31HJ-221X C CAPACITOR 220pF 50V J
C203 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C204 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C205 NCB31HK-271X C CAPACITOR 270pF 50V K
C206 NDC31HJ-151X C CAPACITOR 150pF 50V J
C210 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C211 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C217 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C251 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C256 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C257 NCB31HK-822X C CAPACITOR 8200pF 50V K
C258 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C259 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C260 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C261 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C262 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C263 NEAF1CM-107X E CAPACITOR 100uF 16V M
C300 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C301 NEAF0GM-476X E CAPACITOR 47uF 4V M
C302 NEAF0GM-476X E CAPACITOR 47uF 4V M
C303 NEAF0GM-476X E CAPACITOR 47uF 4V M
C304 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C305 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C306 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C307 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C308 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C309 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C310 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C311 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C312 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C313 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C314 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C315 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C316 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C318 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C319 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C320 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C321 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C322 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C323 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C324 NCB30JK-105X C CAPACITOR 1uF 6.3V K
