JVC HX-Z30 Service Manual

3-12
Input board
Block No. [0][2][0][0]
 Symbol No. Part No. Part Name Description Local
 IC240 KIA7812API IC
IC415 BA033T REGULATOR IC
IC425 M61519FP VOLUME IC
IC466 HA17558A IC
IC467 HA17558A IC
IC491 HA17558A IC
IC492 HA17558A IC
 IC602 STK432-070 IC
Q201 KTC2026/Y/ TRANSISTOR
Q202 KTC3199/GL/-T TRANSISTOR
Q260 KTC3203/OY/-T TRANSISTOR
Q415 KRC104M-T TRANSISTOR
Q416 KRC102M-T DIGI TRANSISTOR
Q486 KTC3199/GL/-T TRANSISTOR
Q487 KTC3199/GL/-T TRANSISTOR
Q491 2SC2785/FE/-T TRANSISTOR
Q492 2SC2785/FE/-T TRANSISTOR
Q493 2SC2785/FE/-T TRANSISTOR
Q513 2SC3576-JVC-T TRANSISTOR
Q514 2SC3576-JVC-T TRANSISTOR
Q515 2SC3576-JVC-T TRANSISTOR
Q516 2SC3576-JVC-T TRANSISTOR
Q517 2SC3576-JVC-T TRANSISTOR
Q518 KRA102M-T DIGI TRANSISTOR
Q530 KTC3199/GL/-T TRANSISTOR
Q531 KRC111M-T TRANSISTOR
Q601 KTC3200/GL/-T TRANSISTOR
Q602 KTC3200/GL/-T TRANSISTOR
Q612 KTA1267/YG/-T TRANSISTOR
Q613 KRC102M-T DIGI TRANSISTOR
Q682 KTC3203/OY/-T TRANSISTOR
Q690 KTC3199/GL/-T TRANSISTOR
Q733 2SC3576-JVC-T TRANSISTOR
Q734 2SC3576-JVC-T TRANSISTOR
Q735 2SC3576-JVC-T TRANSISTOR
Q736 2SC3576-JVC-T TRANSISTOR
Q737 KRA111M-T DIGI TRANSISTOR
 D201 1N5402M-20 DIODE
 D202 1N5402M-20 DIODE
 D203 1N5402M-20 DIODE
 D204 1N5402M-20 DIODE
 D211 1N5402M-20 DIODE
 D212 1N5402M-20 DIODE
 D213 1N5402M-20 DIODE
 D214 1N5402M-20 DIODE
D219 MTZJ20B-T2 Z DIODE
D220 MTZJ6.8B-T2 Z DIODE
D221 1SS119-041-T2 DIODE
D222 MTZJ18B-T2 Z DIODE
D240 MTZJ13B-T2 Z DIODE
D260 1SS119-041-T2 DIODE
D261 1SS119-041-T2 DIODE
D262 1SS119-041-T2 DIODE
D263 1SS119-041-T2 DIODE
D264 MTZJ5.1B-T2 Z DIODE
D265 1SS119-041-T2 DIODE
D266 1SS119-041-T2 DIODE
D411 1SS119-041-T2 DIODE
D412 1SS119-041-T2 DIODE
D415 MTZJ3.9B-T2 Z DIODE
D425 1SS119-041-T2 DIODE
D466 1SS119-041-T2 DIODE
D467 1SS119-041-T2 DIODE
D486 1SS119-041-T2 DIODE
D491 1SS119-041-T2 DIODE
D492 1SS119-041-T2 DIODE
D513 MTZJ3.9B-T2 Z DIODE
D514 MTZJ3.9B-T2 Z DIODE
D530 1SS119-041-T2 DIODE
D619 1SS119-041-T2 DIODE
D620 1SS119-041-T2 DIODE
D622 MTZJ9.1B-T2 Z DIODE
D650 1SS119-041-T2 DIODE
D725 1SS119-041-T2 DIODE
C201 QFKC2EK-103Z MM CAPACITOR 0.01uF 250V K
C202 QFKC2EK-103Z MM CAPACITOR 0.01uF 250V K
C203 QFKC2EK-104Z MM CAPACITOR 0.1uF 250V K
C204 QEZ0613-478 E CAPACITOR 4700uF
C205 QEZ0613-478 E CAPACITOR 4700uF
C211 QFLC2AJ-103Z M CAPACITOR 0.01uF 100V J
C212 QFLC2AJ-103Z M CAPACITOR 0.01uF 100V J
C213 QFKC2EK-104Z MM CAPACITOR 0.1uF 250V K
C214 QETM1HM-228 E CAPACITOR 2200uF 50V M
C215 QETM1HM-228 E CAPACITOR 2200uF 50V M
C217 QETN1JM-107Z E CAPACITOR 100uF 63V M
C218 QETN1HM-226Z E CAPACITOR 22uF 50V M
C219 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C220 QETN1HM-226Z E CAPACITOR 22uF 50V M
C222 QETN1EM-106Z E CAPACITOR 10uF 25V M
C236 QETM1EM-688 E CAPACITOR 6800uF 25V M
C240 QETN1HM-106Z E CAPACITOR 10uF 50V M
C241 QETN1HM-106Z E CAPACITOR 10uF 50V M
C260 QETN1EM-476Z E CAPACITOR 47uF 25V M
C401 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C402 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C403 FQCF31HP-223Z M CAPACITOR
C404 FQCF31HP-103Z D.CAPACITOR
C408 FQCF31HP-103Z D.CAPACITOR
C409 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C410 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C411 QCBB1HK-222Y C CAPACITOR 2200pF 50V K
C415 QETN1AM-227Z E CAPACITOR 220uF 10V M
C417 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C418 QETN1HM-106Z E CAPACITOR 10uF 50V M
C419 QETN1HM-106Z E CAPACITOR 10uF 50V M
C420 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C422 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C423 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C425 QETN1HM-106Z E CAPACITOR 10uF 50V M
C426 QETN1HM-106Z E CAPACITOR 10uF 50V M
C427 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C428 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C429 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C430 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C431 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C432 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C433 QETN1EM-106Z E CAPACITOR 10uF 25V M
C434 QETN1EM-106Z E CAPACITOR 10uF 25V M
C436 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C437 QETN1CM-107Z E CAPACITOR 100uF 16V M
C438 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C440 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C441 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C442 QFLC1HJ-472Z M CAPACITOR 4700pF 50V J
C443 QETN1HM-105Z E CAPACITOR 1uF 50V M
C444 QETN1HM-106Z E CAPACITOR 10uF 50V M
C445 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C446 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C447 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C448 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C449 QFLC1HJ-472Z M CAPACITOR 4700pF 50V J
C450 QETN1AM-477Z E CAPACITOR 470uF 10V M
C451 QETN1HM-106Z E CAPACITOR 10uF 50V M
C452 QETN1HM-105Z E CAPACITOR 1uF 50V M
C453 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C455 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C456 QDGB1HK-681Y C CAPACITOR 680pF 50V K
C457 QETN1HM-106Z E CAPACITOR 10uF 50V M
C458 QETN1HM-106Z E CAPACITOR 10uF 50V M
C463 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C464 QETN1AM-477Z E CAPACITOR 470uF 10V M
C465 QETN1HM-106Z E CAPACITOR 10uF 50V M
C466 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C467 QFLC1HJ-153Z M CAPACITOR 0.015uF 50V J
C468 QFLC1HJ-822Z M CAPACITOR 8200pF 50V J
C469 QFVJ1HJ-274Z MF CAPACITOR 0.27uF 50V J
C470 QETN1CM-107Z E CAPACITOR 100uF 16V M
C471 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C472 QFVJ1HJ-224Z MF CAPACITOR 0.22uF 50V J
