JVC KD-AR5500 Service Manual

(No.MA140)1-27
AUTO ADJ
It is not used for the item used inside at the time of manufacture.
AUTO ADJ
BACK
AUTO ADJ
1
87.5MHz
FM DAA
40dBuV 0%
BACK
AUTO ADJ
2
97.9MHz
FM DAA
40dBuV 0%
BACK
AUTO ADJ
3
108.0MHz
FM DAA
40dBuV 0%
BACK
AUTO ADJ
4
108.0MHz
FM S.METER
40dBuV 0%
BACK
AUTO ADJ
5
97.9MHz
FM S.METER
70dBuV 0%
BACK
AUTO ADJ
6
97.9MHz
Lch
FM FULL SP
70dBuV 0%
40kHZmod 1kHZ
BACK
AUTO ADJ
7
97.9MHz
FM IF CUMT
70dBuV 0%
BACK
AUTO ADJ
8
999kHz
AM S.METER
26dBuV 0%
BACK
AUTO ADJ
9
999kHz
AM S.METER
56dBuV 0%
BACK
AUTO ADJ
10
999kHz
AM IF CUNT
56dBuV 0%
BACK
AUTO ADJ
Completed
BACK
AUTO ADJ
1
87.5MHz
FM DAA
40dBuV 0%
No Signal
BACK
AUTO ADJ
2
97.9MHz
FM DAA
40dBuV 0%
No Signal
BACK
AUTO ADJ
3
108MHz
FM DAA
40dBuV 0%
No Signal
BACK
AUTO ADJ
4
108MHz
FM S.METER
40dBuV 0%
No Signal
Low Signal
H Signal
BACK
AUTO ADJ
5
97.9MHz
FM S.METER
70dBuV 0%
No Signal
Low Siganl
H Signal
BACK
AUTO ADJ
6
97.9MHz
FM FULL SP
70dBuV 0%
No Signal
Adjust NG
BACK
AUTO ADJ
7
97.9MHz
FM IF CUMT
70dBuV 0%
No Signal
Low Signal
H Signal
BACK
AUTO ADJ
8
999kHz
AM S.METER
26dBuV 0%
No Signal
Low Signal
H Signal
BACK
AUTO ADJ
9
999kHz
AM S.METER
56dBuV 0%
No Signal
Low Signal
H Signal Low Signal
H Signal
BACK
AUTO ADJ
10
999kHz
AM IF CUNT
56dBuV 0%
No Signal
Adjust NG
H
J
END
