3-10

C76 NCB31EK-223X C CAPACITOR 0.022uF 25V K

C80 NCB31EK-223X C CAPACITOR 0.022uF 25V K

C81 NCB31CK-473X C CAPACITOR 0.047uF 16V K

C82 NCB31EK-223X C CAPACITOR 0.022uF 25V K

C102 NCB31HK-103X C CAPACITOR 0.01uF 50V K

C103 NCB31HK-103X C CAPACITOR 0.01uF 50V K

C104 NCB31HK-103X C CAPACITOR 0.01uF 50V K

C701 NDC31HJ-7R0X C CAPACITOR 7pF 50V J

C702 NDC31HJ-7R0X C CAPACITOR 7pF 50V J

C703 NDC31HJ-330X C CAPACITOR 33pF 50V J

C704 NDC31HJ-180X C CAPACITOR 18pF 50V J

C705 QERF1CM-107Z E CAPACITOR 100uF 16V M

C707 NDC31HJ-101X C CAPACITOR 100pF 50V J

C708 NBE21AM-106X TA E CAPACITOR 10uF 10V M

C709 NCB31HK-103X C CAPACITOR 0.01uF 50V K

C710 NCB31CK-473X C CAPACITOR 0.047uF 16V K

C712 NCB31HK-103X C CAPACITOR 0.01uF 50V K

C713 QERF0JM-337Z E CAPACITOR 330uF 6.3V M

C714 NCB31HK-103X C CAPACITOR 0.01uF 50V K

C715 NCB31CK-104X C CAPACITOR 0.1uF 16V K

C716 NCB31HK-471X C CAPACITOR 470pF 50V K

C717 NCB31HK-103X C CAPACITOR 0.01uF 50V K

C719 QERF0JM-337Z E CAPACITOR 330uF 6.3V M

C720 NCB31HK-103X C CAPACITOR 0.01uF 50V K

C721 NDC31HJ-101X C CAPACITOR 100pF 50V J

C776 NBE20JM-476X TA E CAPACITOR 47uF 6.3V M

C777 NCB31HK-103X C CAPACITOR 0.01uF 50V K

C901 QEZ0723-338 E CAPACITOR 3300uF

C902 NEA71CM-226X E CAPACITOR 22uF 16V M

C903 NEA71CM-226X E CAPACITOR 22uF 16V M

C904 NCB31HK-103X C CAPACITOR 0.01uF 50V K

C905 QERF1AM-107Z E CAPACITOR 100uF 10V M

C906 NCB31CK-104X C CAPACITOR 0.1uF 16V K

C907 NCB31HK-103X C CAPACITOR 0.01uF 50V K

C908 QERF1AM-227Z E CAPACITOR 220uF 10V M

C909 NBP21CM-106X TA E CAPACITOR 10uF 16V M

C910 NBP21CM-106X TA E CAPACITOR 10uF 16V M

C911 NCB31CK-104X C CAPACITOR 0.1uF 16V K

C912 NEA71HM-225X E CAPACITOR 2.2uF 50V M

C941 QERF1CM-107Z E CAPACITOR 100uF 16V M

C942 QERF1CM-476Z E CAPACITOR 47uF 16V M

C943 QERF0JM-107Z E CAPACITOR 100uF 6.3V M

C944 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M

C950 QERF1CM-476Z E CAPACITOR 47uF 16V M

C951 QERF1CM-226Z E CAPACITOR 22uF 16V M

C952 NCB31HK-103X C CAPACITOR 0.01uF 50V K

C953 QERF1CM-106Z E CAPACITOR 10uF 16V M

C954 QERF1EM-475Z E CAPACITOR 4.7uF 25V M

C955 QERF1HM-225Z E CAPACITOR 2.2uF 50V M

C971 NCB31CK-104X C CAPACITOR 0.1uF 16V K

C972 QERF1CM-107Z E CAPACITOR 100uF 16V M

C973 NCB31CK-104X C CAPACITOR 0.1uF 16V K

C974 NCB31HK-104X C CAPACITOR 0.1uF 50V K

C975 NCB31HK-472X C CAPACITOR 4700pF 50V K

C983 QERF1CM-107Z E CAPACITOR 100uF 16V M

C984 NCB31HK-103X C CAPACITOR 0.01uF 50V K

C985 QERF0JM-337Z E CAPACITOR 330uF 6.3V M

C987 QEXL1AM-476Z E CAPACITOR 47uF 10V M

C988 NCB31HK-103X C CAPACITOR 0.01uF 50V K

C989 QERF0JM-107Z E CAPACITOR 100uF 6.3V M

C991 QERF1AM-107Z E CAPACITOR 100uF 10V M

C992 NCB31CK-473X C CAPACITOR 0.047uF 16V K

C1001 NCB31HK-103X C CAPACITOR 0.01uF 50V K

C1003 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M

C1004 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M

C1005 NBE20JM-476X TA E CAPACITOR 47uF 6.3V M

C1006 NCB31CK-104X C CAPACITOR 0.1uF 16V K

C1007 NCB31CK-104X C CAPACITOR 0.1uF 16V K

C1008 NBE20JM-476X TA E CAPACITOR 47uF 6.3V M

C1009 NCB31CK-473X C CAPACITOR 0.047uF 16V K

C1010 NCB31CK-473X C CAPACITOR 0.047uF 16V K

C1011 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M

C1012 NCB31CK-473X C CAPACITOR 0.047uF 16V K

C1401 QERF1HM-225Z E CAPACITOR 2.2uF 50V M

C1402 NCB31HK-472X C CAPACITOR 4700pF 50V K

C1403 NDC31HJ-101X C CAPACITOR 100pF 50V J

C1404 NCB31HK-102X C CAPACITOR 1000pF 50V K



Symbol

No.

Part No. Part Name Description Local

C1451 NDC31HJ-101X C CAPACITOR 100pF 50V J

C1452 NDC31HJ-101X C CAPACITOR 100pF 50V J

C1501 NDC31HJ-101X C CAPACITOR 100pF 50V J

C1502 NCB30JK-105X C CAPACITOR 1uF 6.3V K

C1552 NCB31HK-332X C CAPACITOR 3300pF 50V K

C1601 NDC31HJ-101X C CAPACITOR 100pF 50V J

C1602 NCB31HK-821X C CAPACITOR 820pF 50V K

C1603 QTE1H55-225Z E CAPACITOR 2.2uF 50V

C1604 NCS31HJ-121X C CAPACITOR 120pF 50V J

C1605 QERF1EM-475Z E CAPACITOR 4.7uF 25V M

C1606 QERF0JM-476Z E CAPACITOR 47uF 6.3V M

C1651 QTE1H55-225Z E CAPACITOR 2.2uF 50V

C1701 QERF1EM-475Z E CAPACITOR 4.7uF 25V M

C1702 NCB31CK-104X C CAPACITOR 0.1uF 16V K

C1703 QERF1AM-107Z E CAPACITOR 100uF 10V M

C1704 NCB31HK-152X C CAPACITOR 1500pF 50V K

C1705 NEA71HM-225X E CAPACITOR 2.2uF 50V M

C1721 QERF1EM-475Z E CAPACITOR 4.7uF 25V M

C1722 NCB31CK-104X C CAPACITOR 0.1uF 16V K

C1723 QERF1AM-107Z E CAPACITOR 100uF 10V M

C1724 NCB31HK-152X C CAPACITOR 1500pF 50V K

C1725 NEA71HM-225X E CAPACITOR 2.2uF 50V M

C1751 NFV81CM-105X MF CAPACITOR 1uF 16V M

C1752 NDC31HJ-101X C CAPACITOR 100pF 50V J

C1771 NFV81CM-105X MF CAPACITOR 1uF 16V M

C1772 NDC31HJ-101X C CAPACITOR 100pF 50V J

C1801 NCB31CK-104X C CAPACITOR 0.1uF 16V K

C1901 QERF1EM-475Z E CAPACITOR 4.7uF 25V M

C1902 NCB21CK-105X C CAPACITOR 1uF 16V K

C1921 QERF1EM-475Z E CAPACITOR 4.7uF 25V M

C1922 NCB21CK-105X C CAPACITOR 1uF 16V K

C2401 QERF1HM-225Z E CAPACITOR 2.2uF 50V M

C2402 NCB31HK-472X C CAPACITOR 4700pF 50V K

C2403 NDC31HJ-101X C CAPACITOR 100pF 50V J

C2404 NCB31HK-102X C CAPACITOR 1000pF 50V K

C2451 NDC31HJ-101X C CAPACITOR 100pF 50V J

C2452 NDC31HJ-101X C CAPACITOR 100pF 50V J

C2501 NDC31HJ-101X C CAPACITOR 100pF 50V J

C2502 NCB30JK-105X C CAPACITOR 1uF 6.3V K

C2552 NCB31HK-332X C CAPACITOR 3300pF 50V K

C2601 NDC31HJ-101X C CAPACITOR 100pF 50V J

C2602 NCB31HK-821X C CAPACITOR 820pF 50V K

C2603 QTE1H55-225Z E CAPACITOR 2.2uF 50V

C2604 NCS31HJ-121X C CAPACITOR 120pF 50V J

C2605 QERF1EM-475Z E CAPACITOR 4.7uF 25V M

C2606 QERF0JM-476Z E CAPACITOR 47uF 6.3V M

C2651 QTE1H55-225Z E CAPACITOR 2.2uF 50V

C2701 QERF1EM-475Z E CAPACITOR 4.7uF 25V M

C2702 NCB31CK-104X C CAPACITOR 0.1uF 16V K

C2703 QERF1AM-107Z E CAPACITOR 100uF 10V M

C2704 NCB31HK-152X C CAPACITOR 1500pF 50V K

C2705 NEA71HM-225X E CAPACITOR 2.2uF 50V M

C2721 QERF1EM-475Z E CAPACITOR 4.7uF 25V M

C2722 NCB31CK-104X C CAPACITOR 0.1uF 16V K

C2723 QERF1AM-107Z E CAPACITOR 100uF 10V M

C2724 NCB31HK-152X C CAPACITOR 1500pF 50V K

C2725 NEA71HM-225X E CAPACITOR 2.2uF 50V M

C2751 NFV81CM-105X MF CAPACITOR 1uF 16V M

C2752 NDC31HJ-101X C CAPACITOR 100pF 50V J

C2771 NFV81CM-105X MF CAPACITOR 1uF 16V M

C2772 NDC31HJ-101X C CAPACITOR 100pF 50V J

C2801 NCB31CK-224X C CAPACITOR 0.22uF 16V K

C2901 QERF1EM-475Z E CAPACITOR 4.7uF 25V M

C2902 NCB21CK-105X C CAPACITOR 1uF 16V K

C2921 QERF1EM-475Z E CAPACITOR 4.7uF 25V M

C2922 NCB21CK-105X C CAPACITOR 1uF 16V K

C3401 NEA71CM-476X E CAPACITOR 47uF 16V M

C3402 NCB31CK-473X C CAPACITOR 0.047uF 16V K

C3403 NCB31CK-473X C CAPACITOR 0.047uF 16V K

C3451 NCB31CK-473X C CAPACITOR 0.047uF 16V K

C3452 NCB31HK-102X C CAPACITOR 1000pF 50V K

C3501 NCB31CK-473X C CAPACITOR 0.047uF 16V K

C3601 QERF1CM-476Z E CAPACITOR 47uF 16V M

C3651 QERF1CM-106Z E CAPACITOR 10uF 16V M

C3652 NCB31CK-104X C CAPACITOR 0.1uF 16V K

C3653 NBE21AM-106X TA E CAPACITOR 10uF 10V M

C3701 NBE20JM-226X TA E CAPACITOR 22uF 6.3V M



Symbol

No.

Part No. Part Name Description Local
