JVC KD-AR5500 Service Manual

3-15
CD mechanism control board
Block No. [0][3]
R8203 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R8301 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R8302 NRSA63J-474X MG RESISTOR 470k
Ω 1/16W J
R8401 NRSA63J-470X MG RESISTOR 47
Ω 1/16W J
R8402 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R8501 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R8705 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R8708 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R8711 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R8713 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R8715 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R8716 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R8718 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R8719 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R8720 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R8721 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R8752 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R8753 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R8754 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R8756 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R8757 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R8758 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R8760 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R8761 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R8762 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R8764 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R8765 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R8766 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R8768 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R8769 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R8770 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R8772 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R8773 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R8774 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R8776 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R8777 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R8778 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R8780 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R8781 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R8782 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R8784 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R8785 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R8786 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R8801 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R8802 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R8803 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R8804 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R8805 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R8806 NRSA63J-152X MG RESISTOR 1.5k
Ω 1/16W J
R8811 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
AR55
00J
R8811 NRSA63J-152X MG RESISTOR 1.5k
Ω 1/16W J
LHX5
50J
R8812 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
AR55
00J
R8812 NRSA63J-152X MG RESISTOR 1.5k
Ω 1/16W J
LHX5
50J
R8813 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R8814 NRSA63J-152X MG RESISTOR 1.5k
Ω 1/16W J
R8822 NRSA63J-271X MG RESISTOR 270
Ω 1/16W J
R8825 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R8828 NRSA63J-271X MG RESISTOR 270
Ω 1/16W J
R8831 NRSA63J-271X MG RESISTOR 270
Ω 1/16W J
R8834 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R8837 NRSA63J-271X MG RESISTOR 270
Ω 1/16W J
L8301 NQL79GM-470X COIL 47uH M
CN801 NNZ0098-003X CAR CONNECTOR
CN851 QGF0523F1-35W CONNECTOR FFC/FPC (1-35)
CN871 QGF1041C1-06W CONNECTOR FFC/FPC (1-6)
S8001 NSW0066-001X TACT SW
S8002 NSW0066-001X TACT SW
S8003 NSW0066-001X TACT SW
S8004 NSW0066-001X TACT SW
S8005 NSW0066-001X TACT SW
S8006 NSW0218-001X LUMISWITCH
S8007 NSW0066-001X TACT SW
S8201 NSW0066-001X TACT SW
 Symbol No. Part No. Part Name Description Local
TH801 NAD0028-103X N THERMISTOR 10k Ω
X8001 NAX0652-001X C RESONATOR 25.000MHz
 Symbol No. Part No. Part Name Description Local
IC430 SN74AHCU04PW-X IC
IC501 TMP91CY22FG6AP3 IC
IC502 BR24L01AFV-W-X IC
IC503 SN74AHCT126PW-X IC(DIGITAL)
IC504 NJU7241F33-X IC
IC601 TC94A15FG IC
IC651 NJU7772F15-X IC
IC652 TC94A34FG-002 IC
IC653 MSM51V17405F5TS IC
IC654 SN74CBTLV3257PX IC
IC655 SN74AHC1G08V-X IC
IC681 LA6242H-X IC
Q430 2SB624/4/-X TRANSISTOR
Q431 UN2211-X TRANSISTOR
Q501 UN2111-X TRANSISTOR
Q502 UN2211-X TRANSISTOR
Q503 RPM-22PB
TRANSISTOR
Q504 UN2211-X TRANSISTOR
Q601 2SB1132/QR/-W TRANSISTOR
Q651 UN2211-X TRANSISTOR
Q652 2SB624/4/-X TRANSISTOR
Q681 2SB1184/QR/-X TRANSISTOR
D506 1SS355-X SI DIODE
D682 1SR154-400-X DIODE
C431 NDC31HJ-270X C CAPACITOR 27pF 50V J
C432 NDC31HJ-270X C CAPACITOR 27pF 50V J
C433 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C501 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C502 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C503 NEAD0GM-227X E CAPACITOR 220uF 4V M
C504 NDC31HJ-220X C CAPACITOR 22pF 50V J
C505 NDC31HJ-220X C CAPACITOR 22pF 50V J
C506 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C507 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C508 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C509 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C510 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C511 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C512 NEAD0GM-227X E CAPACITOR 220uF 4V M
C513 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C514 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C516 NEAD0GM-227X E CAPACITOR 220uF 4V M
C530 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C551 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C597 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C598 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C599 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C601 NEAF0JM-107X E CAPACITOR 100uF 6.3V M
C602 NCB31HK-681X C CAPACITOR 680pF 50V K
C603 NEAF0JM-107X E CAPACITOR 100uF 6.3V M
C604 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C605 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C606 NEAF0JM-476X E CAPACITOR 47uF 6.3V M
C607 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C608 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C610 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C612 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C613 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C614 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C615 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C616 NEAF0JM-476X E CAPACITOR 47uF 6.3V M
C617 NCB31CK-104X C CAPACITOR 0.1uF 16V K
 Symbol No. Part No. Part Name Description Local
