3-12
Switch board
Block No. [0][2]
PP2 QZW0010-001 STYLE PIN
PP3 QZW0010-001 STYLE PIN
TU1 QAU0403-001 TUNER
X701 QAX0617-001Z CRYSTAL 12.500MHz
X702 QAX0401-001 CRYSTAL 32.768KHz
Symbol No.
Part No. Part Name Description Local
IC401 MN102H60KDP1 IC
IC402 SA16M90TFIR1C02 IC
IC403 IC-PST3424U-X IC
IC404 NJU7241F33-X IC
IC405 GP1UM261XKVF IR DETECT UNIT
Q411 2SB709A/QR/-X TRANSISTOR
Q412 2SB709A/QR/-X TRANSISTOR
Q413 2SD601A/QR/-X TRANSISTOR
Q421 2SD601A/QR/-X TRANSISTOR
Q422 2SD601A/QR/-X TRANSISTOR
Q423 2SD601A/QR/-X TRANSISTOR
Q424 2SD601A/QR/-X TRANSISTOR
Q425 2SD601A/QR/-X TRANSISTOR
Q426 2SD601A/QR/-X TRANSISTOR
Q427 2SD601A/QR/-X TRANSISTOR
Q428 2SD601A/QR/-X TRANSISTOR
Q429 2SD601A/QR/-X TRANSISTOR
Q430 2SD601A/QR/-X TRANSISTOR
Q431 2SD601A/QR/-X TRANSISTOR
Q432 2SD601A/QR/-X TRANSISTOR
Q433 2SD601A/QR/-X TRANSISTOR
Q434 2SD601A/QR/-X TRANSISTOR
Q435 2SD601A/QR/-X TRANSISTOR
Q436 2SD601A/QR/-X TRANSISTOR
Q437 2SD601A/QR/-X TRANSISTOR
Q438 2SD601A/QR/-X TRANSISTOR
D400 MC2838-X DIODE
D401 SML-310LT/MN/-X LED
D402 SML-310LT/MN/-X LED
D403 SML-310LT/MN/-X LED
D404 SML-310LT/MN/-X LED
D405 SML-310LT/MN/-X LED
D406 SML-310LT/MN/-X LED
D407 SML-310LT/MN/-X LED
D408 SML-310LT/MN/-X LED
D409 SML-310LT/MN/-X LED
D410 SML-310LT/MN/-X LED
D411 SML-310LT/MN/-X LED
D412 SML-310LT/MN/-X LED
D413 SML-310LT/MN/-X LED
D414 SML-310LT/MN/-X LED
D415 SML-310LT/MN/-X LED
D421 MA8062/M/-X Z DIODE
D422 MA8062/M/-X Z DIODE
D423 MA8062/M/-X Z DIODE
D424 MA8062/M/-X Z DIODE
D425 MA8062/M/-X Z DIODE
D426 MA8062/M/-X Z DIODE
D427 MA8062/M/-X Z DIODE
D428 MA8062/M/-X Z DIODE
D429 MA8062/M/-X Z DIODE
D430 MC2838-X DIODE
D431 MC2836-X DIODE
D432 MA111-X SI DIODE
D433 MA8062/M/-X Z DIODE
D434 MA8062/M/-X Z DIODE
D435 MA8062/M/-X Z DIODE
D436 MA8062/M/-X Z DIODE
D437 MA8062/M/-X Z DIODE
D438 MA8062/M/-X Z DIODE
D439 MA8062/M/-X Z DIODE
Symbol No.
Part No. Part Name Description Local
D440 MA8062/M/-X Z DIODE
D441 MA8062/M/-X Z DIODE
D451 NSCM315C/Z/-W LED
D452 NSCM315C/Z/-W LED
D453 NSCM315C/Z/-W LED
C401 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C403 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C404 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C405 NDC31HJ-7R0X C CAPACITOR 7pF 50V J
C406 NDC31HJ-7R0X C CAPACITOR 7pF 50V J
C407 NDC31HJ-471X C CAPACITOR 470pF 50V J
C408 NDC31HJ-471X C CAPACITOR 470pF 50V J
C409 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C410 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C411 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C412 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C414 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C415 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C416 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C417 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C418 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C419 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C420 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C421 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C422 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C423 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C424 NCB31HK-471X C CAPACITOR 470pF 50V K
C426 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C430 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C431 NCJ31CK-105X-A C CAPACITOR
C432 NCJ31CK-105X-A C CAPACITOR
C433 NCJ31CK-105X-A C CAPACITOR
C434 NCJ31CK-105X-A C CAPACITOR
C435 NCJ31CK-105X-A C CAPACITOR
C436 NCJ31CK-105X-A C CAPACITOR
C437 NCJ31CK-105X-A C CAPACITOR
C438 NCJ31CK-105X-A C CAPACITOR
C439 NCJ31CK-105X-A C CAPACITOR
C440 NCJ31CK-105X-A C CAPACITOR
C441 NCB11EM-105X C CAPACITOR 1uF 25V M
C442 NCB11EM-105X C CAPACITOR 1uF 25V M
C443 NCJ31CK-105X-A C CAPACITOR
C444 NCB11EM-105X C CAPACITOR 1uF 25V M
C445 NCJ31CK-105X-A C CAPACITOR
C446 NCJ31CK-105X-A C CAPACITOR
C447 NCB21CK-105X C CAPACITOR 1uF 16V K
C448 NCB21CK-105X C CAPACITOR 1uF 16V K
C449 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C450 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C451 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C452 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C453 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C454 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C455 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C456 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C457 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C458 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C459 NCB31EK-473X C CAPACITOR 0.047uF 25V K
R402 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R403 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R405 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R407 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R409 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R411 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R413 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R415 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R417 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R419 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R421 NRSA63J-301X MG RESISTOR 300
Ω
1/16W J
R422 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
R423 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R424 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R425 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R426 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R427 NRSA63J-301X MG RESISTOR 300
Ω
1/16W J
R428 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
Symbol No.
Part No. Part Name Description Local
