3-13
CD module board
Block No. [0][3]
R429 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R430 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R431 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R432 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R433 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R434 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R435 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R436 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R437 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R438 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R439 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R440 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R441 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R442 NRSA63J-680X MG RESISTOR 68
Ω
1/16W J
R443 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R444 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R445 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R446 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R447 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R448 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R449 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R450 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R451 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R452 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R453 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R454 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R455 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R456 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R457 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R458 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R459 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R460 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R461 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R462 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R463 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R465 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R466 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R467 NRSA63J-474X MG RESISTOR 470k
Ω
1/16W J
R468 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R469 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R470 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R471 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R472 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R473 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R474 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R475 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R476 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R477 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R478 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R479 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R480 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R481 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R482 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R483 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R484 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R485 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R486 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R487 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R488 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R489 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R490 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R491 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R492 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R493 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R494 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R495 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R496 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R498 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R4002 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R4003 NRSA63J-474X MG RESISTOR 470k
Ω
1/16W J
R4004 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
RA401 NRZ0065-331X NET RESISTOR 330
Ω
RA402 NRZ0065-331X NET RESISTOR 330
Ω
RA403 NRZ0065-331X NET RESISTOR 330
Ω
RA404 NRZ0065-331X NET RESISTOR 330
Ω
RA405 NRZ0065-331X NET RESISTOR 330
Ω
RA406 NRZ0065-103X NET RESISTOR 10k
Ω
RA407 NRZ0065-331X NET RESISTOR 330
Ω
Symbol No.
Part No. Part Name Description Local
RA408 NRZ0065-331X NET RESISTOR 330
Ω
RA409 NRZ0065-331X NET RESISTOR 330
Ω
RA410 NRZ0065-331X NET RESISTOR 330
Ω
L401 NQL114K-470X INDUCITOR 47uH K
CN401 NNZ0098-003X CAR CONNECTOR
CN402 QGF0523F1-35W CONNECTOR FFC/FPC (1-35)
S401 NSW0206-001X TACT SWITCH
S402 NSW0206-001X TACT SWITCH
S403 NSW0206-001X TACT SWITCH
S404 NSW0206-001X TACT SWITCH
S405 NSW0206-001X TACT SWITCH
S406 NSW0206-001X TACT SWITCH
S407 NSW0206-001X TACT SWITCH
S408 NSW0206-001X TACT SWITCH
S409 NSW0206-001X TACT SWITCH
S410 NSW0206-001X TACT SWITCH
S411 NSW0206-001X TACT SWITCH
S412 NSW0206-001X TACT SWITCH
S413 NSW0206-001X TACT SWITCH
S414 NSW0206-001X TACT SWITCH
S415 NSW0206-001X TACT SWITCH
S418 NSW0206-001X TACT SWITCH
TH401 NAD0028-103X N THERMISTOR 10k
Ω
X401 NAX0652-001X C RESONATOR 25.000MHz
Symbol No.
Part No. Part Name Description Local
IC401 PCM1753-X IC
IC410 NJM4580V-X IC
IC430 SN74AHCU04PW-X IC
IC501 TMP91FY22FG6AP3 IC
IC502 BR24L01AFV-W-X IC
IC503 SN74AHCT126PW-X IC(DIGITAL)
IC504 NJU7241F33-X IC
IC601 TC94A15F IC
IC651 NJU7772F15-X IC
IC652 TC94A34FG-002 IC
IC653 MSM51V17405F5TS IC
IC654 SN74CBTLV3257PX IC
IC655 SN74AHC1G08V-X IC
IC681 LA6242H-X IC
Q401 2SA1037AK/R/-X TRANSISTOR
Q402 UN2211-X TRANSISTOR
Q430 2SB624/4/-X TRANSISTOR
Q431 UN2211-X TRANSISTOR
Q501 UN211M-X DIGI TRANSISTOR
Q502 UN2211-X TRANSISTOR
Q503 RPM-22PB
TRANSISTOR
Q504 UN2211-X TRANSISTOR
Q601 2SB1132/QR/-W TRANSISTOR
Q651 UN2211-X TRANSISTOR
Q652 2SB624/4/-X TRANSISTOR
Q681 2SB1184/QR/-X TRANSISTOR
D506 1SS355-X SI DIODE
D682 1SR154-400-X DIODE
C403 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C404 NEAF0JM-227X E CAPACITOR 220uF 6.3V M
C405 NEAF0JM-107X E CAPACITOR 100uF 6.3V M
C406 NCB31EK-123X C CAPACITOR 0.012uF 25V K
C407 NCB31EK-123X C CAPACITOR 0.012uF 25V K
C411 NDC31HJ-101X C CAPACITOR 100pF 50V J
C412 NDC31HJ-101X C CAPACITOR 100pF 50V J
C413 NDC31HJ-821X C CAPACITOR 820pF 50V J
C414 NDC31HJ-821X C CAPACITOR 820pF 50V J
C415 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
Symbol No.
Part No. Part Name Description Local
