3-11
Main board (G115.116_UH2.UN2.U2)
Block No. [0][3]
R653 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R654 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R655 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R656 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R657 NRSA63J-513X MG RESISTOR 51k
Ω
1/16W J
R658 NRSA63J-184X MG RESISTOR 180k
Ω
1/16W J
R671 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
CJ601 QGZ1601K1-15S CONNECTOR (1-15)
S601 NSW0124-001X TACT SW
S602 NSW0124-001X TACT SW
S603 NSW0124-001X TACT SW
S604 NSW0124-001X TACT SW
S605 NSW0124-001X TACT SW
S606 NSW0124-001X TACT SW
S607 NSW0124-001X TACT SW
S608 NSW0124-001X TACT SW
S609 NSW0124-001X TACT SW
S610 NSW0124-001X TACT SW
S611 NSW0124-001X TACT SW
S612 NSW0124-001X TACT SW
S613 NSW0124-001X TACT SW
S614 NSW0124-001X TACT SW
S615 NSW0124-001X TACT SW
S616 NSW0124-001X TACT SW
S617 NSW0124-001X TACT SW
S618 NSW0124-001X TACT SW
Symbol No.
Part No. Part Name Description Local
Symbol
No.
Part No. Part Name Description Local
IC161 TEA6320T-X IC
IC301 LA47516 POWER IC
IC501 TA2157FN-X RF AMP IC
IC521 TC94A14FA CD LSI IC
IC561 LA6242H-X IC
IC571 NJM4565M-WE IC
IC701 UPD178078GF-707 IC
IC901 HA13164A IC
Q1 UN2211-X TRANSISTOR
Q4 2SB709A/R/-X TRANSISTOR
Q5 2SB624/4/-X TRANSISTOR
Q6 UN2211-X TRANSISTOR
Q7 UN2211-X TRANSISTOR
Q31 2SD601A/QR/-X TRANSISTOR
Q32 2SD601A/QR/-X TRANSISTOR
Q41 2SC3661-X TRANSISTOR
Q42 2SC3661-X TRANSISTOR
Q341 KTD1304-X TRANSISTOR
Q351 KTD1304-X TRANSISTOR
Q501 2SB1241/QR/-T TRANSISTOR
Q521 UN2111-X TRANSISTOR
Q522 UN2211-X TRANSISTOR
Q561 2SB1322/RS/-T TRANSISTOR
Q781 UN2111-X TRANSISTOR
Q782 UN2213-X DIGI TRANSISTOR
Q783 UN2111-X TRANSISTOR
Q901 2SB709A/QR/-X TRANSISTOR
Q902 UN2211-X TRANSISTOR
D1 MA111-X SI DIODE
D2 MA111-X SI DIODE
D3 MA111-X SI DIODE
D4 MA111-X SI DIODE
D5 MA111-X SI DIODE
D321 MA111-X SI DIODE
D341 MA111-X SI DIODE
D561 1A3G-T1 SI DIODE
D702 MA8062/M/-X Z DIODE
D703 MA8062/M/-X Z DIODE
D704 MA8062/M/-X Z DIODE
D705 MA8062/M/-X Z DIODE
D706 MA8062/M/-X Z DIODE
D707 MA8062/M/-X Z DIODE
D708 MA8062/M/-X Z DIODE
D781 MA111-X SI DIODE
D782 MA111-X SI DIODE
D783 MA8091/M/-X Z DIODE
D851 RB160M-30-X SB DIODE
D852 RB160M-30-X SB DIODE
D901 1N5401-F64 DIODE
D902 MA111-X SI DIODE
D971 RB160M-30-X SB DIODE
D972 RB160M-30-X SB DIODE
C2 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C3 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C6 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C8 NCB31HK-102X C CAPACITOR 1000pF 50V K
C9 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C10 QEKJ1HM-104Z E CAPACITOR 0.1uF 50V M
C11 NDC31HJ-151X C CAPACITOR 150pF 50V J
C15 QEKJ1HM-224Z E CAPACITOR 0.22uF 50V M
C18 NDC31HJ-101X C CAPACITOR 100pF 50V J
C19 NDC31HJ-470X C CAPACITOR 47pF 50V J
C31 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C32 NCS31HJ-102X C CAPACITOR 1000pF 50V J
C41 NCB31EK-563X C CAPACITOR 0.056uF 25V K
C42 NCB31EK-123X C CAPACITOR 0.012uF 25V K
C43 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
C55 NDC31HJ-331X C CAPACITOR 330pF 50V J
C81 NCB31HK-183X C CAPACITOR 0.018uF 50V K
C82 NCB31HK-272X C CAPACITOR 2700pF 50V K
