3-12
Switch board
(KD-G120,G120R,G123,G124,G125,G126)
Block No. [0][3]
Switch board (KD-G161,G162)
Block No. [0][4]
X702 QAX0401-001 CRYSTAL 32.768KHz
 Symbol No. Part No. Part Name Description Local
IC661 PT6523LQ-L LCD DRIVER
IC681 RPM7338-V4 RM.RECEIVER
G120RJ
D630 SML-310LT/MN/-X LED
D631 SML-310VT/JK/-X LED
D633 SML-310VT/JK/-X LED
D635 SML-310VT/JK/-X LED
D636 SML-310VT/JK/-X LED
D637 SML-310VT/JK/-X LED
D638 SML-310VT/JK/-X LED
D639 SML-310VT/JK/-X LED
D640 SML-310VT/JK/-X LED
D641 SML-310VT/JK/-X LED
D642 SML-310VT/JK/-X LED
D643 SML-310VT/JK/-X LED
D644 SML-310VT/JK/-X LED
D645 SML-310VT/JK/-X LED
D646 SML-310VT/JK/-X LED
D647 SML-310VT/JK/-X LED
D648 SML-310VT/JK/-X LED
D649 SML-310VT/JK/-X LED
D652 NSPW310BS/BRST/ WHITE LED
D653 NSPW310BS/BRST/ WHITE LED
D661 1SS355W-X DIODE C.M
D662 UDZW5.1B-X SI DIODE
D681 MA8062/M/-X Z DIODE
G120RJ
C661 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C662 NDC31HJ-681X C CAPACITOR 680pF 50V J
C663 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C681 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
G120RJ
C682 NCB31HK-123X C CAPACITOR 0.012uF 50V K
G120RJ
C686 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C687 NCB31HK-223X C CAPACITOR 0.022uF 50V K
R601 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R602 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R603 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R604 NRSA63J-911X MG RESISTOR 910
Ω 1/16W J
R605 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R606 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R607 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R608 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R609 NRSA63J-911X MG RESISTOR 910
Ω 1/16W J
R610 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R611 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R612 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R613 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R630 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R631 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R633 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R637 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R639 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R641 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R643 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R645 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R649 NRS181J-361X MG RESISTOR 360
Ω 1/8W J
R650 NRS181J-361X MG RESISTOR 360
Ω 1/8W J
R661 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R662 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R663 NRSA63J-184X MG RESISTOR 180k
Ω 1/16W J
R664 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R665 NRSA63J-513X MG RESISTOR 51k
Ω 1/16W J
R666 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R667 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
R668 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R670 NRS181J-0R0X MG RESISTOR 0
Ω 1/8W J
R681 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
G120RJ
R682 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
G120RJ
R686 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
CJ601 QGZ1601K1-15S CONNECTOR (1-15)
JS686 QSW0976-001 ROTARY ENCODER
S601 NSW0124-001X TACT SW
S602 NSW0124-001X TACT SW
S603 NSW0124-001X TACT SW
S604 NSW0124-001X TACT SW
S605 NSW0124-001X TACT SW
S606 NSW0124-001X TACT SW
S607 NSW0124-001X TACT SW
S608 NSW0124-001X TACT SW
S609 NSW0124-001X TACT SW
S610 NSW0124-001X TACT SW
S611 NSW0124-001X TACT SW
S612 NSW0124-001X TACT SW
S613 NSW0124-001X TACT SW
S614 NSW0124-001X TACT SW
S615 NSW0124-001X TACT SW
S616 NSW0124-001X TACT SW
 Symbol No. Part No. Part Name Description Local
IC661 PT6523LQ-L LCD DRIVER
D630 SML-310LT/MN/-X LED
D631 LNJ308G81/1-3/X LED
G161E
G161EU
G161EX
G161EY
D631 SML-310VT/JK/-X LED
G162E
G162EU
G162EX
G162EY
D632 LNJ308G81/1-3/X LED
G161E
G161EU
G161EX
G161EY
D633 SML-310VT/JK/-X LED
G162E
G162EU
G162EX
G162EY
D634 LNJ308G81/1-3/X LED
G161E
G161EU
G161EX
G161EY
D635 LNJ308G81/1-3/X LED
G161E
G161EU
G161EX
G161EY
D635 SML-310VT/JK/-X LED
G162E
G162EU
G162EX
G162EY
D636 LNJ308G81/1-3/X LED
G161E
G161EU
G161EX
G161EY
D636 SML-310VT/JK/-X LED
G162E
G162EU
G162EX
G162EY
D637 LNJ308G81/1-3/X LED
G161E
G161EU
G161EX
G161EY
D637 SML-310VT/JK/-X LED
G162E
G162EU
G162EX
G162EY
D638 LNJ308G81/1-3/X LED
G161E
G161EU
G161EX
G161EY
D638 SML-310VT/JK/-X LED
G162E
G162EU
G162EX
G162EY
D639 LNJ308G81/1-3/X LED
G161E
G161EU
G161EX
G161EY
D639 SML-310VT/JK/-X LED
G162E
G162EU
G162EX
G162EY
 Symbol No. Part No. Part Name Description Local
