Switch board
(KD-S1501_E2.EX2.EY2.EU2)
Block No. [0][6]
CN701 QGZ1601J1-15 CONNECTOR (1-15)
CN702 QGA2006F1-02 CONNECTOR W-B (1-2)
CN901 QNZ0650-001 CAR CONNECTOR
J1 QNB0100-002 CAR ANT JACK
J301 QNN0519-001 PIN JACK
PP1 QZW0010-001 STYLE PIN
PP2 QZW0010-001 STYLE PIN
TU1 QAU0222-001 TUNER PACK
X71 QAX0263-001Z CRYSTAL 4.332MHz
X521 QAX0413-001Z CRYSTAL 16.9344MHz
X701 QAX0406-001Z CRYSTAL 4.500MHz
Symbol
No.
Part No. Part Name Description Local
IC601 PT6523LQ-L LCD DRIVER
D601 SML-310LT/MN/-X LED
D602 CL-165SR/PG-D-X LED
D603 CL-165SR/PG-D-X LED
D604 CL-165SR/PG-D-X LED
D605 CL-165SR/PG-D-X LED
D606 CL-165SR/PG-D-X LED
D607 CL-165SR/PG-D-X LED
D608 CL-165SR/PG-D-X LED
D609 CL-165SR/PG-D-X LED
D610 CL-165SR/PG-D-X LED
D611 CL-165SR/PG-D-X LED
D612 CL-165SR/PG-D-X LED
D613 CL-165SR/PG-D-X LED
D614 CL-165SR/PG-D-X LED
D615 CL-165SR/PG-D-X LED
D616 CL-165SR/PG-D-X LED
D617 CL-165SR/PG-D-X LED
D618 CL-165SR/PG-D-X LED
D631 NSPW310BS/BRS/ LED
D632 NSPW310BS/BRS/ LED
D641 MA8051/M/-X Z DIODE
D643 MA111-X SI DIODE
C601 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C602 NCS31HJ-681X C CAPACITOR 680pF 50V J
C603 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
R601 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R602 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R603 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R604 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R605 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R606 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R607 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R608 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R609 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R610 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R611 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R612 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R613 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R614 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R615 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R619 NRSA02J-391X MG RESISTOR 390
Ω
1/10W J
R620 NRSA02J-391X MG RESISTOR 390
Ω
1/10W J
R621 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R622 NRS181J-471X MG RESISTOR 470
Ω
1/8W J
R624 NRS181J-471X MG RESISTOR 470
Ω
1/8W J
R626 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R628 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R630 NRS181J-561X MG RESISTOR 560
Ω
1/8W J
R632 NRS181J-152X MG RESISTOR 1.5k
Ω
1/8W J
R633 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
Symbol
No.
Part No. Part Name Description Local
R634 NRSA02J-271X MG RESISTOR 270
Ω
1/10W J
R636 NRSA02J-391X MG RESISTOR 390
Ω
1/10W J
R638 NRSA02J-331X MG RESISTOR 330
Ω
1/10W J
R640 NRSA02J-391X MG RESISTOR 390
Ω
1/10W J
R642 NRSA02J-181X MG RESISTOR 180
Ω
1/10W J
R644 NRSA02J-271X MG RESISTOR 270
Ω
1/10W J
R646 NRS181J-471X MG RESISTOR 470
Ω
1/8W J
R648 NRS181J-471X MG RESISTOR 470
Ω
1/8W J
R650 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R652 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R654 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R670 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
R673 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R674 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R675 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R676 NRSA63J-184X MG RESISTOR 180k
Ω
1/16W J
R677 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R678 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R679 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R680 NRSA63J-513X MG RESISTOR 51k
Ω
1/16W J
CJ601 QGZ1601K1-15S CONNECTOR (1-15)
S601 NSW0124-001X TACT SW
S602 NSW0124-001X TACT SW
S603 NSW0124-001X TACT SW
S604 NSW0124-001X TACT SW
S605 NSW0124-001X TACT SW
S606 NSW0124-001X TACT SW
S607 NSW0124-001X TACT SW
S608 NSW0124-001X TACT SW
S609 NSW0124-001X TACT SW
S610 NSW0124-001X TACT SW
S611 NSW0124-001X TACT SW
S612 NSW0124-001X TACT SW
S613 NSW0124-001X TACT SW
S614 NSW0124-001X TACT SW
S615 NSW0124-001X TACT SW
S616 NSW0124-001X TACT SW
S617 NSW0124-001X TACT SW
S618 NSW0124-001X TACT SW
