3-23
Switch board
(KD-G152/G151_E2.EX2.EY2.EU2)
Block No. [0][8]
Symbol
No.
Part No. Part Name Description Local
IC601 PT6523LQ-L LCD DRIVER
D601 SML-310VT/JK/-X LED
D602 SML-310VT/JK/-X LED
D603 SML-310VT/JK/-X LED
D604 SML-310VT/JK/-X LED
G151
E2,G1
51EU
2,G15
1EX2,
G151
EY2
D604 SML-310LT/MN/-X LED
G152
E2,G1
52EU
2,G15
2EX2,
G152
EY2
D605 SML-310VT/JK/-X LED
D606 SML-310VT/JK/-X LED
D607 SML-310VT/JK/-X LED
D608 SML-310LT/MN/-X LED
D609 SML-310LT/MN/-X LED
D610 SML-310VT/JK/-X LED
D611 SML-310VT/JK/-X LED
D612 SML-310VT/JK/-X LED
D613 SML-310VT/JK/-X LED
D614 SML-310VT/JK/-X LED
D615 SML-310VT/JK/-X LED
D616 SML-310VT/JK/-X LED
D617 SML-310VT/JK/-X LED
G151
E2,G1
51EU
2,G15
1EX2,
G151
EY2
D617 SML-310LT/MN/-X LED
G152
E2,G1
52EU
2,G15
2EX2,
G152
EY2
D618 SML-310LT/MN/-X LED
D631 NSPW310BS/BRS/ LED
D632 NSPW310BS/BRS/ LED
D641 MA8051/M/-X Z DIODE
D643 MA111-X SI DIODE
C601 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C602 NCS31HJ-681X C CAPACITOR 680pF 50V J
C603 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
R601 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R602 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R603 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R604 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R605 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R606 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R607 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R608 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R609 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R610 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R611 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R612 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R613 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R614 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R615 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R627 NRSA02J-391X MG RESISTOR 390
Ω
1/10W J
R628 NRSA02J-391X MG RESISTOR 390
Ω
1/10W J
R629 NRSA63J-911X MG RESISTOR 910
Ω
1/16W J
G151
E2,G1
51EU
2,G15
1EX2,
G151
EY2
R629 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
G152
E2,G1
52EU
2,G15
2EX2,
G152
EY2
R630 NRSA63J-132X MG RESISTOR 1.3k
Ω
1/16W J
G151
E2,G1
51EU
2,G15
1EX2,
G151
EY2
R630 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
G152
E2,G1
52EU
2,G15
2EX2,
G152
EY2
R631 NRSA63J-132X MG RESISTOR 1.3k
Ω
1/16W J
G151
E2,G1
51EU
2,G15
1EX2,
G151
EY2
R632 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R634 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R636 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R638 NRSA63J-511X MG RESISTOR 510
Ω
1/16W J
R640 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R642 NRSA63J-132X MG RESISTOR 1.3k
Ω
1/16W J
G151
E2,G1
51EU
2,G15
1EX2,
G151
EY2
R642 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
G152
E2,G1
52EU
2,G15
2EX2,
G152
EY2
R643 NRSA63J-132X MG RESISTOR 1.3k
Ω
1/16W J
G151
E2,G1
51EU
2,G15
1EX2,
G151
EY2
R644 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R651 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R652 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R653 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R654 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R655 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R656 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R657 NRSA63J-513X MG RESISTOR 51k
Ω
1/16W J
R658 NRSA63J-184X MG RESISTOR 180k
Ω
1/16W J
R671 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
CJ601 QGZ1601K1-15S CONNECTOR (1-15)
S601 NSW0124-001X TACT SW
S602 NSW0124-001X TACT SW
S603 NSW0124-001X TACT SW
S604 NSW0124-001X TACT SW
S605 NSW0124-001X TACT SW
S606 NSW0124-001X TACT SW
S607 NSW0124-001X TACT SW
S608 NSW0124-001X TACT SW
S609 NSW0124-001X TACT SW
S610 NSW0124-001X TACT SW
