JVC KD-G152 Service Manual

3-27
Packing and Accessories
Block No. [M][3][M][M]
 Symbol No. Part No. Part Name Description Local
A 1 VND3050-002 IDENTITY CARD
G151E,G151E2,G151EX,G151EX2,G151EY,
G151EY2,G152E,G152E2,G152EX,G152EX2,
G152EY,G152EY2,S1501E,S1501E2,
S1501EX,S1501EX2,S1501EY,S1501EY2
A 2 GE20137-005A-N MOUNTING SLEEVE
G151EU,G151EX,G151EY
A 2 GE20137-003A MOUNTING SLEEVE
G151E,G151E2,G151EU2,G151EX2,
G151EY2,G152E,G152E2,G152EU,G152EU2,
G152EX,G152EX2,G152EY,G152EY2,
S1501E,S1501E2,S1501EU,S1501EU2,
S1501EX,S1501EX2,S1501EY,S1501EY2
A 3 GE20135-003A TRIM PLATE
G151E,G151E2,G151EU,G151EU2,G151EX,
G151EX2,G151EY,G151EY2
A 3 GE20135-009A TRIM PLATE
G152E,G152E2,G152EU,G152EU2,G152EX,
G152EX2,G152EY,G152EY2
A 3 GE20135-001A TRIM PLATE
S1501E,S1501E2,S1501EU,S1501EU2,
S1501EX,S1501EX2,S1501EY,S1501EY2
A 4 GET0287-001A INST BOOK GER FRE ITA
G151E,G151E2,G152E,G152E2,S1501E,
S1501E2
A 4 GET0287-003A INST BOOK ENG FRE
G151EU,G151EU2,G151EX,G151EX2,
G152EU,G152EU2,G152EX,G152EX2,
S1501EU,S1501EU2,S1501EX,S1501EX2
A 4 GET0287-006A INST BOOK ENG GER RUS
G151EY,G151EY2,G152EY,G152EY2,
S1501EY,S1501EY2
A 5 GET0287-002A INST BOOK SPA GRE POR
G151E,G151E2,G152E,G152E2,S1501E,
S1501E2
A 5 GET0287-005A INST BOOK SPA TUR PER
G151EU,G151EU2,G152EU,G152EU2,
S1501EU,S1501EU2
A 5 GET0287-004A INST BOOK DUT SWE DAN FIN
G151EX,G151EX2,G152EX,G152EX2,
S1501EX,S1501EX2
A 5 GET0287-007A INST BOOK POL CZE HUN
G151EY,G151EY2,G152EY,G152EY2,
S1501EY,S1501EY2
A 6 GET0287-008A INSTALL MANUAL
G151E,G151E2,G152E,G152E2,S1501E,
S1501E2
A 6 GET0287-010A INSTALL MANUAL
G151EU,G151EU2,G151EX,G151EX2,
G152EU,G152EU2,G152EX,G152EX2,
S1501EU,S1501EU2,S1501EX,S1501EX2
A 6 GET0287-013A INSTALL MANUAL
G151EY,G151EY2,G152EY,G152EY2,
S1501EY,S1501EY2
A 7 GET0287-009A INSTALL MANUAL
G151E,G151E2,G152E,G152E2,S1501E,
S1501E2
A 7 GET0287-012A INSTALL MANUAL
G151EU,G151EU2,G152EU,G152EU2,
S1501EU,S1501EU2
A 7 GET0287-011A INSTALL MANUAL
G151EX,G151EX2,G152EX,G152EX2,
S1501EX,S1501EX2
A 7 GET0287-014A INSTALL MANUAL
G151EY,G151EY2,G152EY,G152EY2,
S1501EY,S1501EY2
A 8 ------------ WARRANTY CARD BT-54023-1
G151E,G151E2,G151EX,G151EX2,G151EY,
G151EY2,G152E,G152E2,G152EX,G152EX2,
G152EY,G152EY2,S1501E,S1501E2,
S1501EX,S1501EX2,S1501EY,S1501EY2
A 9 VND3046-001 SERIAL TICKET
G151E,G151E2,G151EX,G151EX2,G151EY,
G151EY2,G152E,G152E2,G152EX,G152EX2,
G152EY,G152EY2,S1501E,S1501E2,
S1501EX,S1501EX2,S1501EY,S1501EY2
A 10 VKZ4027-202 PLUG NUT
A 11 VKH4871-003 MOUNT BOLT
A 12 VKZ4328-003 LOCK NUT
A 13 QYWWS53A008ZA WASHER 0mm/5.3mm x
A 14 GE40130-002A HOOK (x2)
A 15 FSJB3002-00C HARD CASE
A 16 QAM0157-002 POWER CORD
G151E,G151E2,G151EU,G151EU2,G151EX,
G151EX2,G151EY,G151EY2,G152E,G152E2,
G152EU,G152EU2,G152EX,G152EX2,
G152EY,G152EY2
A 16 QAM0175-002 POWER CORD
S1501E,S1501E2,S1501EU,S1501EU2,
S1501EX,S1501EX2,S1501EY,S1501EY2
KIT SRW-385U SCREW PART KIT A10 A11 A12 A13 A14
P 1 QPC03004315P POLY BAG 30cm x 43cm
P 2 FSPG4002-001 POLY BAG (x2)
P 3 QPA00801205 POLY BAG 8cm x 12cm
P 4 GE10070-003A EPS CUSHION
P 5 GE31402-002A CARTON
G151E,G151E2,G151EU,G151EU2,G151EX,
G151EX2,G151EY,G151EY2
P 5 GE31432-003A CARTON
G152E,G152E2,G152EU,G152EU2,G152EX,
G152EX2,G152EY,G152EY2
P 5 GE31405-001A CARTON
S1501E,S1501E2,S1501EU,S1501EU2,S1501
EX,S1501EX2,S1501EY,S1501EY2
P 6 QPA01003003 POLY BAG 10cm x 30cm
P 7 FSYH4036-068 SHEET
