3-15
Switch board (UT2.UH2.UN2.U2)
Block No. [0][4]
R908 NRSA63J-273X MG RESISTOR 27k
Ω
1/16W J
R909 NRSA63J-273X MG RESISTOR 27k
Ω
1/16W J
R910 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R911 NRSA02J-222X MG RESISTOR 2.2k
Ω
1/10W J
R912 NRSA02J-222X MG RESISTOR 2.2k
Ω
1/10W J
R918 NRSA02J-103X MG RESISTOR 10k
Ω
1/10W J
R971 NRSA02J-101X MG RESISTOR 100
Ω
1/10W J
R972 NRSA02J-101X MG RESISTOR 100
Ω
1/10W J
L1 QQL244J-4R7Z COIL 4.7uH J
L571 QQL244K-4R7Z COIL 4.7uH K
L701 QQL244K-4R7Z COIL 4.7uH K
L901 QQR0703-001 CHOKE COIL
CN501 QGB2027M4-22S CONNECTOR B-B (1-22)
CN701 QGZ1601J1-15 CONNECTOR (1-15)
CN901 QNZ0611-001 16P CONNECTOR
J1 QNB0190-001 CAR ANT JACK
J321 QNN0519-001 PIN JACK
TU1 QAU0394-002 TUNER PACK
X521 QAX0714-001Z C RESONATOR 16.000MHz
X701 QAX0406-001Z CRYSTAL 4.500MHz
Symbol No.
Part No. Part Name Description Local
IC601 PT6523LQ-L LCD DRIVER
IC602 RPM7338-V4 RM.RECEIVER
Q671 2SB624/4/-X TRANSISTOR
Q672 UN2211-X TRANSISTOR
D601 SML-310VT/JK/-X LED
D602 SML-310VT/JK/-X LED
D603 SML-310VT/JK/-X LED
D604 SML-310LT/MN/-X LED
D605 SML-310VT/JK/-X LED
D606 SML-310VT/JK/-X LED
D607 SML-310VT/JK/-X LED
D608 SML-310VT/JK/-X LED
D609 SML-310VT/JK/-X LED
D610 SML-310VT/JK/-X LED
D611 SML-310VT/JK/-X LED
D612 SML-310VT/JK/-X LED
D613 SML-310VT/JK/-X LED
D614 SML-310VT/JK/-X LED
D615 SML-310VT/JK/-X LED
D616 SML-310VT/JK/-X LED
D617 SML-310LT/MN/-X LED
D618 SML-310LT/MN/-X LED
D631 NSPW310BS/BRST/ WHITE LED
D632 NSPW310BS/BRST/ WHITE LED
D641 MA8051/M/-X Z DIODE
D643 MA111-X SI DIODE
D644 MA8062/M/-X Z DIODE
C601 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C602 NCS31HJ-681X C CAPACITOR 680pF 50V J
C603 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C612 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
R601 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R602 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R603 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R604 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R605 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R606 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R607 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R608 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R609 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R610 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R611 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
Symbol No.
Part No. Part Name Description Local
R612 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R613 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R614 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R615 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R627 NRSA02J-391X MG RESISTOR 390
Ω
1/10W J
R628 NRSA02J-391X MG RESISTOR 390
Ω
1/10W J
R629 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R630 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R632 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R634 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R636 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R638 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R640 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R642 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R644 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R651 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R652 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R653 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R654 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R655 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R656 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R657 NRSA63J-513X MG RESISTOR 51k
Ω
1/16W J
R658 NRSA63J-184X MG RESISTOR 180k
Ω
1/16W J
R661 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R662 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R671 NRSA02J-471X MG RESISTOR 470
Ω
1/10W J
R672 NRSA02J-473X MG RESISTOR 47k
Ω
1/10W J
R673 NRSA02J-102X MG RESISTOR 1k
Ω
1/10W J
S601 NSW0124-001X TACT SW
S602 NSW0124-001X TACT SW
S603 NSW0124-001X TACT SW
S604 NSW0124-001X TACT SW
S605 NSW0124-001X TACT SW
S606 NSW0124-001X TACT SW
S607 NSW0124-001X TACT SW
S608 NSW0124-001X TACT SW
S609 NSW0124-001X TACT SW
S610 NSW0124-001X TACT SW
S611 NSW0124-001X TACT SW
S612 NSW0124-001X TACT SW
S613 NSW0124-001X TACT SW
S614 NSW0124-001X TACT SW
S615 NSW0124-001X TACT SW
S616 NSW0124-001X TACT SW
S617 NSW0124-001X TACT SW
S618 NSW0124-001X TACT SW
Symbol No.
Part No. Part Name Description Local
