JVC KD-G501 Service Manual

3-3
General Assembly
Block No. [M][1][M][M]
 Symbol No. Part No. Part Name Description Local
1 GE10043-210A TOP CHASSIS
2 GE40135-001A EARTH PLATE
3 GE30938-003A SIDE PANEL
4 GE30393-002A BOTTOM COVER
5 FSMA3005-001 INSULATOR
6 QYSDST2604Z SCREW 2.6mm x 4mm(x3)
7 FSKZ4005-001 SCREW (x2)
8 QYSDST2606Z SCREW 2.6mm x 6mm(x2)
9 QYSDST2604Z SCREW 2.6mm x 4mm(x3)
10 QYSDST2610Z SCREW 2.6mm x 10mm
11 QYSDSF2006M SCREW 2mm x 6mm(x2)
12 GE30823-001A F. CHASSIS ASSY
13 QYSDST2004M MINI SCREW 2mm x 4mm(x2)
14 FSYH4036-098 SHEET
15 GE30827-002A OPEN LEVER
16 GE30824-002A LOCK LEVER(O.L)
17 GE31245-001A RELEASE LEVER
18 GE30829-001A LOCK LEVER(TOP)
19 GE30825-002A LOCK LEVER(L)
20 GE30828-002A LOCK LEVER(R)
21 GE40154-001A GEAR
22 QZW0108-002 OIL DAMPER
23 GE40153-001A T.SPRING
24 GE40157-001A T.SPRING
25 VKW5264-005 T.SPRING
26 FSKW4012-002 T.SPRING
27 VKW5263-002 T.SPRING
28 GE40155-001A T.SPRING
29 QYSDSF2006M SCREW 2mm x 6mm
30 GE40156-001A BLIND
31 GE10080-004A FRONT PANEL
32 GE31048-009A FINDER ASSY
G501
E,G50
1EX
32 GE31048-012A FINDER ASSY
G507
EE
33 GE31044-001A POWER BUTTON
34 GE31038-001A VOLUME KNOB
35 GE40218-002A SHEET
36 GE31039-003A SEL BUTTON
37 FSYH4036-053 SHEET
38 GE31040-001A RIM LENS
39 FSYH4036-069 SHEET
40 GE31029-001A D.FUNC BTN
41 GE20161-001A PRESET BUTTON
42 GE31043-001A UP/DOWN BTN
43 GE31028-003A SSM BTN
44 GE31025-001A SEARCH BTN
45 GE31041-004A EJECT BUTTON
46 GE31250-001A EJECT COVER
47 GE40220-001A LIGHT SHIELD
48 GE31042-004A DETACH BTN
49 GE31045-001A RIM COVER
50 GE40204-001A JVC BADGE
51 VKW3001-330 COMP.SPRING
52 GE40202-004A COMP.SPRING
53 GE10081-001A REAR COVER
54 VKZ4777-001 MINI SCREW (x4)
55 GE31035-001A LCD CASE
56 GE31036-001A LCD LENS
57 GE31037-001A LENS CASE
58 GE40200-003A LIGHTING SHEET
59 GE31133-001A NAME PLATE
G501
E,G50
1EX
59 GE31286-001A NAME PLATE
G507
EE
60 QLD0298-001 LCD MODULE
61 QNZ0442-001 LCD CONNECTOR
 62 QMFZ047-150-T FUSE 15A
63 GE30912-005A REAR BRACKET
64 QYSDST2606Z SCREW 2.6mm x 6mm
65 QYSDST2606Z SCREW 2.6mm x 6mm
66 QYSDST2606Z SCREW 2.6mm x 6mm
67 QYSDSF2606Z SCREW 2.6mm x 6mm
68 GE40172-004A IC BRACKET
69 GE40124-002A REG BRACKET
70 QAM0544-002 STEERING CABLE
G501
E,G50
1EX
71 LV41843-002A LASER CAUTION
72 GE30854-001A LED HOLDER
 Symbol No. Part No. Part Name Description Local

JVC KD-G501 Specifications

Audio Amplifier Specifications

maximum power output front	50 W per channel
maximum power output rear	50 W per channel
continuous power output front	19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion
continuous power output rear	19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion
load impedance	4 Ω (4 Ω to 8 Ω allowance)
tone control range bass	±10 dB at 100 Hz
tone control range treble	±10 dB at 10 kHz
frequency response	40 Hz to 20 000 Hz
signal-to-noise ratio	70 dB
line-out level/impedance	2.0 V/20 kΩ load (full scale)
output impedance	1 kΩ

CD Player Specifications

operating voltage	DC 14.4 V (11 V to 16 V allowance)
allowable operating temperature	0°C to +40°C
dimensions installation size	182 mm × 52 mm × 150 mm
dimensions panel size	188 mm × 58 mm × 12 mm
mass	1.4 kg (excluding accessories)
frequency response	5 Hz to 20 000 Hz
dynamic range	96 dB
signal-to-noise ratio	98 dB
max. bit rate	320 Kbps

Tuner Specifications

frequency range FM	87.5 MHz to 108.0 MHz
frequency range AM (MW)	522 kHz to 1 620 kHz
frequency range AM (LW)	144 kHz to 279 kHz
usable sensitivity FM	11.3 dBf (1.0 µV/75 Ω)
50 dB quieting sensitivity FM	16.3 dBf (1.8 µV/75 Ω)
alternate channel selectivity (400 kHz) FM	65 dB
frequency response FM	40 Hz to 15 000 Hz
stereo separation FM	30 dB
capture ratio FM	1.5 dB
sensitivity MW	20 µV
selectivity MW	35 dB
sensitivity LW	50 µV
