Electrical parts list
Main board (KD-AR560J , KD-G510J)
Block No. [0][1]
Symbol No.
Part No. Part Name Description Local
IC31 TB2118F-X PLL IC
IC161 TDA7404D-E-X IC
IC251 NJM4565M-WE IC
IC271 CD4066BPW-X IC
IC291 CD4066BPW-X IC
G510
IC301 TB2906HQ IC
IC361 NJM2160BV-X IC
AR560
IC381 NJM2160BV-X IC
AR560
IC701 UPD784217AGC322 IC
IC702 IC-PST3433U-X IC
IC771 BR24L16F-W-X IC
IC801 HD74HC126FP-X IC
IC901 HA13164A IC
Q1 KTD1304-X TRANSISTOR
Q5 2SB709A/R/-X TRANSISTOR
Q6 2SB624/4/-X TRANSISTOR
Q7 UN2211-X TRANSISTOR
Q8 UN2211-X TRANSISTOR
Q31 UN2211-X TRANSISTOR
Q241 2SD601A/R/-X TRANSISTOR
Q271 KTD1304-X TRANSISTOR
AR560
Q272 UN2111-X TRANSISTOR
Q273 UN2211-X TRANSISTOR
Q274 UN2211-X TRANSISTOR
Q291 UN2211-X TRANSISTOR
G510
Q292 UN2211-X TRANSISTOR
G510
Q321 KTD1304-X TRANSISTOR
Q331 KTD1304-X TRANSISTOR
Q341 KTD1304-X TRANSISTOR
Q351 KTD1304-X TRANSISTOR
Q701 UN2211-X TRANSISTOR
Q702 UN2211-X TRANSISTOR
Q703 UN2211-X TRANSISTOR
Q704 UN2211-X TRANSISTOR
Q705 UN2211-X TRANSISTOR
Q781 UN2111-X TRANSISTOR
Q782 KTD1304-X TRANSISTOR
Q784 UN2111-X TRANSISTOR
Q881 UN2211-X TRANSISTOR
Q891 UN2211-X TRANSISTOR
AR560
Q901 2SB1132/QR/-W TRANSISTOR
Q976 UN2211-X TRANSISTOR
Q977 2SB709A/QR/-X TRANSISTOR
D1 MA111-X SI DIODE
D2 MA111-X SI DIODE
D4 MA111-X SI DIODE
D5 MA111-X SI DIODE
D242 MA111-X SI DIODE
D243 RB160M-30-X SB DIODE
D244 UDZS5.1B-X Z DIODE
D251 UDZS4.7B-X Z DIODE
D271 MA111-X SI DIODE
AR560
D273 MA111-X SI DIODE
D321 MA111-X SI DIODE
D325 UDZS11B-X Z DIODE
D331 MA111-X SI DIODE
D341 MA111-X SI DIODE
D351 MA111-X SI DIODE
D701 MA8062/M/-X Z DIODE
D702 MA8062/M/-X Z DIODE
D703 MA8062/M/-X Z DIODE
D704 MA8062/M/-X Z DIODE
D705 MA8062/M/-X Z DIODE
D706 MA8062/M/-X Z DIODE
D707 MA8062/M/-X Z DIODE
D708 MA8062/M/-X Z DIODE
D709 MA8062/M/-X Z DIODE
D710 MA111-X SI DIODE
D711 MA8062/M/-X Z DIODE
D713 UDZS5.6B-X Z DIODE 1.5k
Ω
1/10W J
D714 SML-310VT/JK/-X LED
D715 SML-310VT/JK/-X LED
D716 SML-310VT/JK/-X LED
D717 MA8062/M/-X Z DIODE
D718 MA8062/M/-X Z DIODE
D719 MA8062/M/-X Z DIODE
D720 MA8062/M/-X Z DIODE
D781 MA111-X SI DIODE
D782 MA111-X SI DIODE
D783 MA111-X SI DIODE
D784 UDZS11B-X Z DIODE
D891 MA111-X SI DIODE
AR560
D892 MA111-X SI DIODE
AR560
D901 1N5401-F64 DIODE
D902 MA111-X SI DIODE
D971 RB160M-30-X SB DIODE
D972 RB160M-30-X SB DIODE
D996 RB160M-30-X SB DIODE
D997 RB160M-30-X SB DIODE
C1 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C2 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C3 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C4 QERF1AM-227Z E CAPACITOR 220uF 10V M
C5 QEKJ1HM-104Z E CAPACITOR 0.1uF 50V M
C6 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C9 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C10 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C11 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C12 QERF1AM-227Z E CAPACITOR 220uF 10V M
C30 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C31 QERF1AM-107Z E CAPACITOR 100uF 10V M
C32 NDC31HJ-470X C CAPACITOR 47pF 50V J
C33 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C34 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C35 NDC31HJ-100X C CAPACITOR 10pF 50V J
C36 NDC31HJ-7R0X C CAPACITOR 7pF 50V J
C37 NDC31HJ-100X C CAPACITOR 10pF 50V J
C38 NCB31HK-102X C CAPACITOR 1000pF 50V K
C39 NCB31HK-102X C CAPACITOR 1000pF 50V K
C40 QERF1CM-106Z E CAPACITOR 10uF 16V M
C41 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C42 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C43 QFV61HJ-473Z MF CAPACITOR 0.047uF 50V J
C44 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C45 NCB31HK-272X C CAPACITOR 2700pF 50V K
C46 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C47 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C48 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C49 NCB31HK-102X C CAPACITOR 1000pF 50V K
C50 NDC31HJ-101X C CAPACITOR 100pF 50V J
C51 NCB31HK-331X C CAPACITOR 330pF 50V K
C81 QERF1HM-105Z E CAPACITOR 1uF 50V M
C82 NCB31HK-682X C CAPACITOR 6800pF 50V K
C84 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C85 NCB31EK-153X C CAPACITOR 0.015uF 25V K
C91 QERF1HM-105Z E CAPACITOR 1uF 50V M
C92 NCB31HK-682X C CAPACITOR 6800pF 50V K
C94 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C95 NCB31EK-153X C CAPACITOR 0.015uF 25V K
C161 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C162 QERF1HM-105Z E CAPACITOR 1uF 50V M
C163 QTE1H55-225Z E CAPACITOR 2.2uF 50V
C165 QERF1HM-105Z E CAPACITOR 1uF 50V M
C171 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C172 QERF1HM-105Z E CAPACITOR 1uF 50V M
C173 QTE1H55-225Z E CAPACITOR 2.2uF 50V
C174 QERF1HM-105Z E CAPACITOR 1uF 50V M
C175 QERF1HM-105Z E CAPACITOR 1uF 50V M
C176 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C177 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C179 QERF1CM-476Z E CAPACITOR 47uF 16V M
C181 QERF1CM-107Z E CAPACITOR 100uF 16V M
C182 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C184 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C241 QERF1HM-105Z E CAPACITOR 1uF 50V M
