3-11
Switch board (KD-AR560J , KD-G510J)
Block No. [0][2]
R881 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R882 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R891 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
AR560
R892 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
AR560
R893 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
AR560
R901 QRE142J-102X C RESISTOR 1k
Ω
1/4W J
R902 NRSA02J-912X MG RESISTOR 9.1k
Ω
1/10W J
R903 NRSA02J-472X MG RESISTOR 4.7k
Ω
1/10W J
R904 NRSA02J-221X MG RESISTOR 220
Ω
1/10W J
R971 NRS181J-222X MG RESISTOR 2.2k
Ω
1/8W J
R972 NRS181J-222X MG RESISTOR 2.2k
Ω
1/8W J
R976 NRSA02J-203X MG RESISTOR 20k
Ω
1/10W J
R977 NRSA02J-822X MG RESISTOR 8.2k
Ω
1/10W J
RA30 NRZ0065-222X NET RESISTOR 2.2k
Ω
L1 QQL244J-4R7Z COIL 4.7uH J
L701 QQL244K-4R7Z COIL 4.7uH K
L901 QQR1378-002 COIL
CN101 QGB2027M4-22S CONNECTOR B-B (1-22)
CN251 QGA2501C1-03 CONNECTOR W-B (1-3)
AR560
CN701 QNZ0605-001 CAR CONNECTOR
CN901 QNZ0611-001 16P CONNECTOR
J1 QNB0100-002 CAR ANT JACK
J321 QNN0490-001 PIN JACK
AR560
J321 QNN0489-001 PIN JACK
G510
J801 QNZ0095-001 CONNECTOR
S701 QSW0451-001 DETECT SW
S702 QSW0451-001 DETECT SW
S703 QSW1049-001Z TACT SW
TU1 QAU0312-002 TUNER PACK
X31 QAX0616-001Z CRYSTAL 10.250MHz
X701 QAX0617-001Z CRYSTAL 12.500MHz
X702 QAX0401-001 CRYSTAL 32.768KHz
Symbol No.
Part No. Part Name Description Local
IC601 PT6523LQ-L LCD DRIVER
IC602 RPM7338-V4 RM.RECEIVER
Q640 2SB624/4/-X TRANSISTOR
Q641 UN2211-X TRANSISTOR
D601 SML-310VT/JK/-X LED
D602 SML-310VT/JK/-X LED
D603 SML-310VT/JK/-X LED
D604 SML-310VT/JK/-X LED
D605 SML-310VT/JK/-X LED
D606 SML-310VT/JK/-X LED
D607 SML-310VT/JK/-X LED
D608 SML-310VT/JK/-X LED
D609 SML-310VT/JK/-X LED
D610 SML-310VT/JK/-X LED
D611 SML-310VT/JK/-X LED
D612 SML-310VT/JK/-X LED
D613 SML-310VT/JK/-X LED
D614 SML-310VT/JK/-X LED
D615 SML-310VT/JK/-X LED
D616 SML-310VT/JK/-X LED
D617 SML-310VT/JK/-X LED
D618 SML-310VT/JK/-X LED
D619 SML-310VT/JK/-X LED
D640 MA152WK-X SI DIODE
D641 UDZS5.1B-X Z DIODE
D642 MA111-X SI DIODE
D643 MA8062/M/-X Z DIODE
D645 NSPW310BS/BRS/ LED
D646 NSPW310BS/BRS/ LED
C601 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C602 NCS31HJ-681X C CAPACITOR 680pF 50V J
Symbol No.
Part No. Part Name Description Local
C603 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C611 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C612 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
R601 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R602 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R603 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R604 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R605 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R606 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R607 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R608 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R609 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R610 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R611 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R612 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R613 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R614 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R620 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R621 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R630 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
AR560
R630 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
G510
R631 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
AR560
R632 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
AR560
R632 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
G510
R633 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
AR560
R634 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
AR560
R634 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
G510
R636 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
AR560
R636 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
G510
R638 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R640 NRSA02J-331X MG RESISTOR 330
Ω
1/10W J
R641 NRSA02J-391X MG RESISTOR 390
Ω
1/10W J
AR560
R641 NRSA02J-201X MG RESISTOR 200
Ω
1/10W J
G510
R642 NRSA02J-331X MG RESISTOR 330
Ω
1/10W J
R643 NRSA02J-391X MG RESISTOR 390
Ω
1/10W J
R644 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R646 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R648 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
AR560
R648 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
G510
R651 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R652 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R653 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R654 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R655 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R656 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R657 NRSA63J-513X MG RESISTOR 51k
Ω
1/16W J
R658 NRSA63J-184X MG RESISTOR 180k
Ω
1/16W J
R660 NRSA02J-391X MG RESISTOR 390
Ω
1/10W J
R661 NRSA02J-391X MG RESISTOR 390
Ω
1/10W J
R670 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R672 NRSA02J-471X MG RESISTOR 470
Ω
1/10W J
R673 NRSA02J-473X MG RESISTOR 47k
Ω
1/10W J
R674 NRSA02J-102X MG RESISTOR 1k
Ω
1/10W J
R691 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R692 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
CN601 NNZ0085-001 CAR CONNECTOR
EN601 QSW1115-002 ROTARY ENCODER
J601 QNS0245-001 AUX JACK
S601 NSW0206-001X TACT SWITCH
S602 NSW0206-001X TACT SWITCH
S603 NSW0206-001X TACT SWITCH
S604 NSW0206-001X TACT SWITCH
S605 NSW0206-001X TACT SWITCH
S606 NSW0206-001X TACT SWITCH
S607 NSW0206-001X TACT SWITCH
S608 NSW0206-001X TACT SWITCH
S609 NSW0206-001X TACT SWITCH
S610 NSW0206-001X TACT SWITCH
S611 NSW0206-001X TACT SWITCH
S612 NSW0206-001X TACT SWITCH
S613 NSW0206-001X TACT SWITCH
S614 NSW0206-001X TACT SWITCH
S616 NSW0206-001X TACT SWITCH
S617 NSW0206-001X TACT SWITCH
Symbol No.
Part No. Part Name Description Local
