3-23
Packing and Accessories
Block No. [M][3][M][M]
Symbol No. Part No. Part Name Description Local
A 1 GET0267-001A INST BOOK ENG SPA FRE
A 2 GET0267-002A INSTALL MANUAL
A 3 LVT0717-001B TROUBLE SHEET(C
A 4 ------------ WARRANTY CARD BT-52006-2
A 5 BT-51034-2 REGISTRATION CARD
A 6 ------------ WARRANTY CARD BT-51029-2 AR560J2,AR560
A 6 ------------ WARRANTY CARD BT-51018-4 G510J2,G510
A 7 VKZ4027-202 PLUG NUT
A 8 VKH4871-003 MOUNT BOLT
A 9 VKZ4328-003 LOCK NUT
A 10 QYWWS53A008ZA WASHER 0mm/5.3mm x
A 11 GE40130-002A HOOK (x2)
A 12 FSJB3002-30C HARD CASE
A 13 GE20137-003A MOUNTING SLEEVE
A 14 GE20149-010A TRIM PLATE AR560J2,AR560
A 14 GE20149-013A TRIM PLATE G510J2,G510
A 15 RM-RK50 REMOCON UNIT
A 16 ------------ BATTERY
A 17 QAM0675-001 16P CORD ASSY AR560J2,AR560
A 17 QAM0306-002 16P CORD ASSY G510J2,G510
KIT SRW-385U SCREW PARTS KIT A7 A8 A9 A10 A11
P 1 GE31465-002A CARTON AR560J2,AR560
P 1 GE31462-002A CARTON G510J2,G510
P 2 FSPG4002-001 POLY BAG
P 3 QPC03004315P POLY BAG 30cm x 43cm
P 4 QPA00801205 POLY BAG 8cm x 12cm
P 5 GE10108-001A PAPER CUSHION (x2)
P 6 FSYH4036-068 SHEET
P 7 QPA01003003 POLY BAG 10cm x 30cm
