KD-LX110R/KD-LX330R

3-8

Item

Parts number Parts name Area

Electrical parts list

Remarks

Block No. 01

BZ791 000393760 BUZZER CD11PA-XZ

C 1 CY473623J CAPACITOR CY 0.047 UF

C 2 CE2263468 CAPACITOR CE 22UF 16V

C 3 CY103623J CAPACITOR CY 0.001 UF

C 4 CZ1016D2J CAPACITOR CZ 100PF

C 5 CE2271468 CAPACITOR CY 0.01 UF

C 6 CY473623J CAPACITOR CY 0.047 UF

C 7 CY183623J CAPACITOR CE 0.018UF

C 8 CY104423J CAPACITOR CY 0.1UF

C 9 CE2263468 CAPACITOR CE 22UF/16V

C 11 CY473623J CAPACITOR CY 0.047UF

C 20 CY153623J CAPACITOR CY 0.015UF

C 21 CZ3316D2J CAPACITOR CZ 330PF

C 22 CY103623J CAPACITOR CY0.01UF

C 23 CY472623J CAPACITOR CY 0.0047 UF

C 24 CY104423J CAPACITOR CY 0.1UF

C 25 CE4746468 CAPACITOR CE 0.47UF/50V

C 31 CY103623J CAPACITOR CY 0.01 UF

C 32 CE4746468 CAPACITOR CE 0.47UF/50V

C 33 CY102623J CAPACITOR CY 0.001 UF

C 34 CY682623J CAPACITOR CY 0.0068UF

C 35 CE2263468 CAPACITOR CE 22 UF/16V

C 36 CY152623J CAPACITOR CY 0.0015UF

C 37 CY103623J CAPACITOR CY 0.01 UF

C 38 CY473623J CAPACITOR CY 0.047 UF

C 39 CE1046468 CAPACITOR CE 0.1 UF/50V

C 40 CE1056468 CAPACITOR CE 1 UF/50V

C 41 CY103623J CAPACITOR CY 0.01UF

C 42 CE1056468 CAPACITOR CE 1 UF/50V

C 43 CE1056468 CAPACITOR CE 1 UF/50V

C 44 CE1056468 CAPACITOR CE 1 UF/50V

C 45 CE1056468 CAPACITOR CE 1 UF/50V

C 46 CE1056468 CAPACITOR CE 1 UF/50V

C 51 CZ1206D2J CAPACITOR CZ 12PF

C 52 CZ1206D2J CAPACITOR CZ 12PF

C 53 CE4760468 CAPACITOR CE47 UF/6.3V

C 54 CY103623J CAPACITOR CY 0.01UF

C 55 CZ5616D2J CAPACITOR CZ 560 PF

C 56 CY223623J CAPACITOR CY 0.022UF

C 57 CE2256468 CAPACITOR CE 2.2UF/50V

C 101 CY153623J CAPACITOR CY 0.015UF

C 102 CZ6816D2J CAPACITOR CZ 680 PF

C 103 CE2246468 CAPACITOR CE 0.22UF/50V

C 112 CE1056468 CAPACITOR CE 1 UF

C 118 CY472623J CAPACITOR CY 0.0047UF

C 119 CE1063468 CAPACITOR CE 10 UF

C 120 CZ4716D2J CAPACITOR CZ 470 PF

C 141 CE1056468 CAPACITOR CE 1 UF

C 142 CE1056468 CAPACITOR CE 1 UF

C 143 CZ3316D2J CAPACITOR CZ 330 PF

C 144 CZ3316D2J CAPACITOR CZ 330 PF

C 151 CY105122J CAPACITOR CY 1 UF

C 152 CY122623J CAPACITOR CY 0.0012UF

C 153 CZ1216D2J CAPACITOR CZ 120 PF

C 154 CZ1016D2J CAPACITOR CZ 100 PF

C 155 CE4760468 CAPACITOR CE 47 UF

C 156 CE1071468 CAPACITOR CE 100 UF

C 161 CE1056468 CAPACITOR CE 1 UF

C 162 CE2263468 CAPACITOR CE 22 UF

C 163 CY473623J CAPACITOR CY 0.047 UF

C 164 CY224122J CAPACITOR CY 0.22 UF

C 172 CE1063468 CAPACITOR KD-LX330R

C 173 CE2260468 CAPACITOR KD-LX330R

C 174 CY223623J CAPACITOR KD-LX330R

C 175 CE4760468 CAPACITOR 0.22 UF

C 202 CZ5616D2J CAPACITOR CZ 560 PF

C 203 CE2246468 CAPACITOR CE 0.022UF/50V

C 212 CE1056468 CAPACITOR CE 1 UF

C 218 CY472623J CAPACITOR CY 0.0047UF

C 219 CE1063468 CAPACITOR CE 10 UF

C 220 CZ4716D2J CAPACITOR CZ 470 PF

C 241 CE1056468 CAPACITOR CE 1 UF

C 242 CE1056468 CAPACITOR CE 1 UF

C 243 CZ3316D2J CAPACITOR CZ 330 PF

C 244 CZ3316D2J CAPACITOR CZ 330 PF

C 251 CY105122J CAPACITOR CY 1 UF

C 252 CY122623J CAPACITOR CY 0.0012UF

C 253 CZ1216D2J CAPACITOR CZ 120 PF

C 254 CZ1016D2J CAPACITOR CZ 100 PF

C 272 CE1063468 CAPACITOR KD-LX330R UF

C 273 CE2260468 CAPACITOR KD-LX330R

C 301 CE4754468 CAPACITOR KD-LX330R

C 302 CE4754468 CAPACITOR KD-LX330R

C 303 CE4763468 CAPACITOR KD-LX330R

C 305 CE4754468 CAPACITOR 4.7UF125V

C 306 CE4754468 CAPACITOR 4.7UF125V

C 307 CE1071468 CAPACITOR KD-LX330R

C 308 CE4754468 CAPACITOR KD-LX330R

C 309 CE4754468 CAPACITOR KD-LX330R

C 310 CE1071468 CAPACITOR KD-LX330R

C 321 CE1063468 CAPACITOR KD-LX330R

C 322 CY103623J CAPACITOR KD-LX330R

C 323 CE4763468 CAPACITOR KD-LX330R

C 324 CE1063468 CAPACITOR KD-LX330R

C 325 CE2256468 CAPACITOR KD-LX330R

C 326 CY682623J CAPACITOR KD-LX330R

C 327 CY823423J CAPACITOR KD-LX330R

C 329 CE2256468 CAPACITOR KD-LX330R

C 330 CY123623J CAPACITOR KD-LX330R

C 331 CY562623J CAPACITOR KD-LX330R

C 332 CY273623J CAPACITOR KD-LX330R

C 333 CY273623J CAPACITOR KD-LX330R

C 334 CY333623J CAPACITOR KD-LX330R

C 335 CE2256468 CAPACITOR KD-LX330R

C 336 CY473623J CAPACITOR KD-LX330R

C 337 CY473623J CAPACITOR KD-LX330R

C 351 CY104423J CAPACITOR CY 0.1 UF

C 352 CY103623J CAPACITOR CY 0.01 UF

C 353 CE4754468 CAPACITOR CE 4.7 UF

C 354 CY104423J CAPACITOR CY 0.1 UF

C 355 CZ4716D2J CAPACITOR CZ 470 PF

C 356 CE1063468 CAPACITOR CE 10 UF

C 357 CY472623J CAPACITOR CY 0.0047UF

C 358 CY224122J CAPACITOR CY 0.22 UF

C 359 CY224122J CAPACITOR CY 0.22 UF

C 361 CE4754468 CAPACITOR KD-LX110R

C 362 CE4754468 CAPACITOR KD-LX110R

C 363 CZ1016D2J CAPACITOR KD-LX110R

C 364 CZ1016D2J CAPACITOR KD-LX110R

C 367 CE2271468 CAPACITOR KD-LX110R

C 401 CE4754468 CAPACITOR KD-LX330R

C 402 CE4754468 CAPACITOR KD-LX330R

C 403 CE4763468 CAPACITOR KD-LX330R

C 405 CE4754468 CAPACITOR 4.7UF 125V

C 406 CE4754468 CAPACITOR 4.7UF 125V

C 407 CE1071468 CAPACITOR KD-LX330R

(Main board)
