KD-LX110R/KD-LX330R

3-9

Item

Parts number Parts name Area

Electrical parts list

Remarks

Block No. 01

C 408 CE4754468 CAPACITOR KD-LX330R

C 409 CE4754468 CAPACITOR KD-LX330R

C 410 CE1071468 CAPACITOR KD-LX330R

C 451 CY104423J CAPACITOR CY 0.1 UF

C 452 CY103623J CAPACITOR CY 0.01 UF

C 454 CY104423J CAPACITOR CY 0.1 UF

C 455 CZ4716D2J CAPACITOR CZ 470 PF

C 456 CE1063468 CAPACITOR CE 10 UF

C 457 CY472623J CAPACITOR CY 0.0047UF

C 458 CY224122J CAPACITOR CY 0.22 UF

C 459 CY224122J CAPACITOR CY 0.22 UF

C 461 CE4754468 CAPACITOR KD-LX110R

C 462 CE4754468 CAPACITOR KD-LX110R

C 463 CZ1016D2J CAPACITOR KD-LX110R

C 464 CZ1016D2J CAPACITOR KD-LX110R

C 501 CE1071468 CAPACITOR CE 100 UF

C 502 CY103623J CAPACITOR CY 0.01 UF

C 504 CY103623J CAPACITOR CY 0.01 UF

C 505 CY103623J CAPACITOR CY 0.01 UF

C 506 CE1071468 CAPACITOR CE 100 UF

C 507 CY103623J CAPACITOR CY 0.01 UF

C 508 CY104423J CAPACITOR CY 0.1 UF

C 509 CY104423J CAPACITOR CY 0.1 UF

C 510 CZ8206D2J CAPACITOR CZ 82 PF

C 511 CY682623J CAPACITOR CY 0.0068UF

C 512 CE1071468 CAPACITOR CE 100 UF

C 513 CY103623J CAPACITOR CY 0.01 UF

C 515 CZ5R06A2J CAPACITOR CZ 5 PF

C 521 CE1071468 CAPACITOR CE 100 UF

C 522 CE1071468 CAPACITOR CE 100 UF

C 523 CE1056468 CAPACITOR CE 1 UF

C 524 CY103623J CAPACITOR CY 0.01 UF

C 525 CY103623J CAPACITOR CY 0.01 UF

C 529 CE1071468 CAPACITOR CE 100 UF

C 533 CZ4706D2J CAPACITOR CZ 47 PF

C 534 CY153623J CAPACITOR CY 0.015 UF

C 536 CY103623J CAPACITOR CY 0.01 UF

C 537 CY272623J CAPACITOR CY 0.0027UF

C 538 CY103623J CAPACITOR CY 0.01 UF

C 539 CY333623J CAPACITOR CY 0.033 UF

C 540 CY473623J CAPACITOR CY 0.047 UF

C 542 CZ4716D2J CAPACITOR CZ 470 PF

C 543 CZ4716D2J CAPACITOR CZ 470 PF

C 545 CY473623J CAPACITOR CY 0.047 UF

C 546 CY473623J CAPACITOR CY 0.047 UF

C 547 CY473623J CAPACITOR CY 0.047 UF

C 549 CY473623J CAPACITOR CY 0.047 UF

C 550 CY333623J CAPACITOR CY 0.033 UF

C 551 CE1071468 CAPACITOR CE 100 UF

C 552 CY103623J CAPACITOR CY 0.01 UF

C 553 CY103623J CAPACITOR CY 0.01 UF

C 554 CE1071468 CAPACITOR CE 100 UF

C 555 CY103623J CAPACITOR CY 0.01 UF

C 556 CZ8R06B2J CAPACITOR CZ 8 PF

C 557 CZ8R06B2J CAPACITOR CZ 8 PF

C 558 CZ1016D2J CAPACITOR CZ 100 PF

C 571 CE1071468 CAPACITOR CE 100 UF

C 573 CY103623J CAPACITOR CY 0.01 UF

C 574 CE1071468 CAPACITOR CE 100 UF

C 581 CE2271468 CAPACITOR CE 220 UF

C 582 CY103623J CAPACITOR CY 0.01 UF

C 583 CE2263468 CAPACITOR CE 22 UF

C 584 CY473623J CAPACITOR CY 0.047 UF

C 701 CZ2206D2J CAPACITOR CZ 22 PF

C 702 CZ2706D2J CAPACITOR CZ 27 PF

C 703 CZ1506D2J CAPACITOR CZ 15 PF

C 704 CZ1506D2J CAPACITOR CZ 15 PF

C 705 CZ2216D2J CAPACITOR CZ 220 PF

C 706 CY473623J CAPACITOR CY 0.047 UF

C 707 CY103623J CAPACITOR CY 0.01 UF

C 708 CE1063468 CAPACITOR CE 10 UF

C 710 CE2271468 CAPACITOR CE 220 UF

C 711 CY474122J CAPACITOR CY 0.47 UF

C 712 CY474122J CAPACITOR CY 0.47 UF

C 713 CE2271468 CAPACITOR CE 220 UF

C 719 CZ2216D2J CAPACITOR CZ 220 PF

C 720 CY473623J CAPACITOR CY 0.047 UF

C 721 CY222623J CAPACITOR CY 0.0022UF

C 722 CY222623J CAPACITOR CY 0.0022UF

C 723 CE2271468 CAPACITOR KD-LX330R

C 730 CY473623J CAPACITOR CY 0.047UF

C 750 CY474122J CAPACITOR CY 0.47UF

C 755 CY473623J CAPACITOR CY 0.047 UF

C 756 CY222623J CAPACITOR CY 0.0022UF

C 757 CY104423J CAPACITOR CY 0.1 UF

C 771 CY473623J CAPACITOR CY 0.047 UF

C 791 CE1046468 CAPACITOR CE 0.1 UF

C 821 CY183623J CAPACITOR KD-LX330R F

C 822 CY393623J CAPACITOR KD-LX330R

C 823 CY393623J CAPACITOR KD-LX330R

C 824 CY393623J CAPACITOR KD-LX330R

C 825 CY393623J CAPACITOR KD-LX330R

C 826 CY122623J CAPACITOR KD-LX330R

C 827 CE1063468 CAPACITOR KD-LX330R

C 828 CE2263468 CAPACITOR KD-LX330R

C 911 CE4763468 CAPACITOR CE 47 UF

C 912 CE1071468 CAPACITOR CE 100 UF

C 913 CY104423J CAPACITOR CY 0.1 UF

C 931 CZ1016D2J CAPACITOR CZ 100 PF

C 932 CY473623J CAPACITOR CY 0.047 UF

C 937 CY104423J CAPACITOR CY 0.1 UF

C 940 CK1026057 CAPACITOR KD-LX110R

C 941 CE4746468 CAPACITOR CE 0.47 UF

C 942 CE4763468 CAPACITOR CE 47 UF

C 943 CY103603J CAPACITOR CY 0.01 UF

C 944 CE2256468 CAPACITOR CE 2.2UF 150V

C 945 CY104423J CAPACITOR CY 0.1 UF

C 951 CY104423J CAPACITOR CY 0.1 UF

C 952 CE1063468 CAPACITOR CE 10 UF

C 961 CE3383541 CAPACITOR CE 3300 UF

C 962 CE2256468 CAPACITOR CE 2.2 UF

C 964 CE2271468 CAPACITOR CE 220 UF

C 965 CE2263468 CAPACITOR CE 22 UF

C 966 CY103623J CAPACITOR CY 0.01 UF

C 967 CE2263468 CAPACITOR CE 22 UF

C 968 CY104423J CAPACITOR CY 0.1 UF

C 969 CE2263468 CAPACITOR CE 22 UF

C 970 CY473623J CAPACITOR CY 0.047 UF

C 971 CE4763468 CAPACITOR CE 47 UF

C 977 CE2263468 CAPACITOR CE 22 UF

C 978 CE1071468 CAPACITOR CE 100 UF

C 982 CE2263468 CAPACITOR CE 22 UF

C 987 CY104423J CAPACITOR CY 0.1UF

C 991 CZ2716D2J CAPACITOR CZ 270PF

C 992 CZ2716D2J CAPACITOR CZ 270PF

C 993 CZ2716D2J CAPACITOR CZ 270PF

(Main board)

Item

Parts number Parts name Area

Remarks
