KD-LX110R/KD-LX330R
3-10
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 01
A
C 994 CZ2716D2J CAPACITOR CZ 270PF
C 995 CZ2716D2J CAPACITOR CZ 270PF
C 996 CZ2716D2J CAPACITOR CZ 270PF
C 997 CZ2716D2J CAPACITOR CZ 270PF
C 998 CZ2716D2J CAPACITOR CZ 270PF
CN301 KN2507297 CONNECTOR 7P BASE POST
CN302 KN2506297 CONNECTOR KD-LX330R
CN503 KN2502091 CONNECTOR 2P BASE POST S
CN504 KN2502091 CONNECTOR 2P BASE POST S
CN601 KZ042260L CONNECTOR 26P TKC-W26P-
CN701 KZ041170L CONNECTOR 17P FPC 52559-
CN702 KZ040060L CONNECTOR 6P FPCR 52746-
CN704 KN530409L CONNECTOR 4P BASE POST 5
CN771 KX0040800 CONNECTOR 8P BUS CONNECTO
CN901 KX0071600 CONNECTOR DC CONNECTOR
1
D 1 DI1SS400L DIODE
D 2 DI1SS400L DIODE
D 3 DI1SS400L DIODE
D 11 DAN202U-X DIODE
D 31 DI1SS400L SI.DIODE
D 101 DAN202U-X DIODE
D 111 DAN202U-W DIODE
D 131 DAP202U-X DIODE
D 161 DIAN217UL DIODE
D 201 DAN202U-X SI.DIODE
D 231 DAP202U-X DIODE
D 332 DAN202U-X DIODE
D 351 DAN202U-X DIODE KD-LX330R
D 451 DAN202U-X DIODE KD-LX330R
D 701 CRS03-X DIODE
D 711 DI1SS400L DIODE
D 941 DI1SS400L DIODE
D 961 1N5404-TU-15 DIODE
D 962 CRS03-X DIODE
D 963 DI1SS400L DIODE
D 967 CRS03-X DIODE
D 978 UDZ11B-X Z.DIODE ZENER DI UDZ11
D 980 DI1SS400L DIODE
D 986 DIAP202UL DIODE
IC 31 LA3460M-X IC
IC 51 BU1923F-X IC
IC171 000474740-T IC KD-LX110R
IC301 BA3220FV-X I.C(M) KD-LX330R
IC321 M5282FP-X I.C(MONO-ANA) KD-LX330R
IC322 BU4066BCFV-X IC KD-LX330R
IC323 NJM4565MD IC KD-LX330R
IC361 NJM4565MD IC KD-LX110R
IC401 BA3220FV-X I.C(M) KD-LX330R
IC461 NJM4565MD IC KD-LX110R
IC521 TC9490FA IC
IC601 TA2147F-X IC
IC661 FAN8037 IC
IC701 UPD784215AGC129 IC
IC702 000874360-T IC IC PST600MGT
IC703 BR24C32F-X IC
IC771 HD74HC126FP IC
IC821 NJM2100M I.C
IC821 TA8273H I.C(MONO-ANA) KD-LX330R
IC911 BD3860K IC
IC941 TA8273H I.C(MONO-ANA)
IC951 NJM2904M IC
IC960 NJM4565MD IC
IC961 HA13164 IC
J 1 EX0000487 JACK ANTTENA CORD AS
L 1 LC4R7J257 COIL LC 4.7UH
L 521 LC470K10J COIL LC 47UH
L 522 LC470K10J COIL LC 47UH
L 523 RK820J32J COIL RK 1/4W 82K
L 524 LC470K10J COIL LC 47UH
L 701 LC470K10J COIL LC 47UH
L 718 LC1R8K24J COIL LC 1.8UH
L 719 LC1R8K24J COIL LC 1.8UH
L 961 000125560 CHOKE COIL
1 DTA114EUA-X DIGITAL.TR
11 2SB1197K/QR/-X TRANSISTOR
12 TRC114EUL-A TRANSISTOR
13 TRA1576(QRS)L-A TRANSISTOR
21 TRC4081(QRS)L TRANSISTOR
22 TRC4081(QRS)L TRANSISTOR
23 TRC4081(QRS)L TRANSISTOR
24 TRC114EUL-A TRANSISTOR
31 TRA114EUL-A TRANSISTOR
32 TRC114EUL-A TRANSISTOR
33 TRC4081(QRS)L TRANSISTOR
34 TRA114EUL-A TRANSISTOR
35 TRA1576(QRS)L-A TRANSISTOR
36 TRC114EUL-A TRANSISTOR
131 2SD1048/6-7/-X TRANSISTOR KD-LX330R
132 2SD1048/6-7/-X TRANSISTOR
161 2SC4081/QR/-X TRANSISTOR
231 2SD1048/6-7/-X TRANSISTOR KD-LX330R
232 2SD1048/6-7/-X TRANSISTOR
321 TRC114EUL-A TRANSISTOR KD-LX330R
322 TRC114EUL-A TRANSISTOR KD-LX330R
323 2SD1048/6-7/-X TRANSISTOR KD-LX330R
501 2SB1241/QR/-T TRANSISTOR
561 2SB1241/QR/-T TRANSISTOR
590 DTA114EUA-X DIGITAL.TR
591 DTA114EUA-X DIGITAL.TR
700 DTA114EUA-X DIGITAL.TR
701 DTA114EUA-X DIGITAL.TR
702 2SA1576A/QR/-X TRANSISTOR
791 DTA114EUA-X DIGITAL.TR
942 DTA114EUA-X DIGITAL.TR
943 DTA114EUA-X DIGITAL.TR
966 2SA1576A/QR/-X TRANSISTOR
977 DTA114EUA-X DIGITAL.TR
979 DTA114EUA-X DIGITAL.TR
981 DTA114EUA-X DIGITAL.TR
982 DTA114EUA-X DIGITAL.TR
983 2SC4081/QR/-X TRANSISTOR
986 TRC114EUL-A TRANSISTOR
R 1 RK000JA0J RESISTOR RK 1/10W 0
R 2 RK104JA0J RESISTOR RK 1/10W 100 K
R 3 RK100JA0J RESISTOR RK 1/10W 10
R 4 RK103JA0J RESISTOR RK 1/10W 10K
R 10 RK4R7JA0J RESISTOR RK 1/10W 4.7
R 11 RK4R7JA0J RESISTOR RK 1/10W 4.7
R 12 RK473JA0J RESISTOR RK 1/10W 47 K
R 13 RK472JA0J RESISTOR RK 1/10W 4.7K
R 14 RK473JA0J RESISTOR RK 1/10W 47 K
R 15 RK332JA0J RESISTOR RK1/10W 3.3K
R 21 RK473JA0J RESISTOR RK 1/10W 47K
R 22 RK393JA0J RESISTOR RK 1/10W 39K
R 23 RK103JA0J RESISTOR RK 1/10W 10K
R 23 RK222JA0J RESISTOR RK 1/10W 2.2K
