KD-LX110R/KD-LX330R
3-11
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 01
A
R 24 RK222JA0J RESISTOR RK 1/10W 2.2K
R 25 RK103JA0J RESISTOR RK 1/10W 10K
R 26 RK153JA0J RESISTOR RK 1/10W 15K
R 27 RK471JA0J RESISTOR RK 1/10W 470
R 27 RK393JA0J RESISTOR RK 1/10W 39K
R 28 RK683JA0J RESISTOR RK 1/10W 68K
R 28 RK103JA0J RESISTOR RK 1/10W 10K
R 31 RK123JA0J RESISTOR RK 1/10W 12K
R 32 RK474JA0J RESISTOR RK 1/10W 470K
R 33 RK222JA0J RESISTOR RK 1/10W 2.2K
R 34 RK392JA0J RESISTOR RK 1/10W 3.9K
R 35 RK333JA0J RESISTOR RK 1/10W 33K
R 36 RK683JA0J RESISTOR RK 1/10W 68K
R 37 RK222JA0J RESISTOR RK 1/10W 2.2K
R 38 RK183JA0J RESISTOR RK 1/10W 18K
R 39 RK223JA0J RESISTOR RK 1/10W 22K
R 40 RK562JA0J RESISTOR RK 1/10W 5.6K
R 41 RK105JA0J RESISTOR RK 1/10W 1M
R 42 RK471JA0J RESISTOR RK 1/10W 470
R 43 RK104JA0J RESISTOR RK 1/10W 100K
R 44 RK102JA0J RESISTOR RK 1/10W 1K
R 45 RK473JA0J RESISTOR RK 1/10W 47K
R 46 RK563JA0J RESISTOR RK 1/10W 56K
R 47 RK000JA0J RESISTOR RK 1/10W 0K
R 51 RK101JA0J RESISTOR RK 1/10W 100K
R 52 RK222JA0J RESISTOR RK 1/10W 2.2K
R 53 RK103JA0J RESISTOR RK 1/10W 10K
R 54 RK222JA0J RESISTOR RK 1/10W 2.2K
R 101 RK682JA0J RESISTOR RK 1/10W 6.8K
R 102 RK223JA0J RESISTOR RK 1/10W 22K
R 111 RK224JA0J RESISTOR RK 1/10W 220K
R 118 RK104JA0J RESISTOR RK 1/10W 100K
R 119 RK101JA0J RESISTOR RK 1/10W 100
R 131 RK222JA0J RESISTOR KD-LX330R
R 132 RK222JA0J RESISTOR RK 1/10W 2.2K
R 133 RK681JA0J RESISTOR KD-LX110R
R 134 RK681JA0J RESISTOR RK 1/10W 680
R 135 RK101JA0J RESISTOR KD-LX330R
R 136 RK101JA0J RESISTOR RK 1/10W 100
R 141 RK473JA0J RESISTOR KD-LX330R
R 142 RK473JA0J RESISTOR KD-LX330R
R 143 RK473JA0J RESISTOR KD-LX330R
R 144 RK473JA0J RESISTOR KD-LX330R
R 145 RK473JA0J RESISTOR KD-LX110R
R 146 RK473JA0J RESISTOR KD-LX110R
R 151 RK153JA0J RESISTOR RK 1/10W 15
R 152 RK333JA0J RESISTOR RK 1/10W 33K
R 153 RK123JA0J RESISTOR RK 1/10W 12K
R 155 RK472JA0J RESISTOR RK 1/10W 4.7K
R 161 RK473JA0J RESISTOR RK 1/10W 47K
R 162 RK123JA0J RESISTOR RK 1/10W 12K
R 163 RK184JA0J RESISTOR RK 1/10W 180K
R 164 RK223JA0J RESISTOR RK 1/10W 22K
R 165 RK391JA0J RESISTOR RK 1/10W 390
R 166 RK102JA0J RESISTOR RK 1/10W 1K
R 167 RK274JA0J RESISTOR RK 1/10W 270K
R 171 RK471JA0J RESISTOR KD-LX330R
R 172 RK104JA0J RESISTOR KD-LX330R
R 173 RK822JA0J RESISTOR KD-LX330R
R 174 RK822JA0J RESISTOR KD-LX330R
R 175 RK103JA0J RESISTOR KD-LX330R
R 176 RK103JA0J RESISTOR KD-LX330R
R 177 RK102JA0J RESISTOR KD-LX330R
R 201 RK682JA0J RESISTOR RK 1/10W 6.8K
R 202 RK223JA0J RESISTOR RK 1/10W 22K
R 211 RK224JA0J RESISTOR RK 1/10W 220K
R 218 RK104JA0J RESISTOR RK 1/10W 100K
R 219 RK101JA0J RESISTOR RK 1/10W 100
R 231 RK222JA0J RESISTOR KD-LX330R
R 231 RK222JA0J RESISTOR RK 1/10W 2.2K
R 232 RK222JA0J RESISTOR RK 1/10W 2.2K
R 233 RK681JA0J RESISTOR KD-LX330R
R 234 RK681JA0J RESISTOR RK 1/10W 680
R 235 RK101JA0J RESISTOR KD-LX330R
R 235 RK101JA0J RESISTOR RK 1/10W 100K
R 236 RK101JA0J RESISTOR RK 1/10W 100
R 241 RK473JA0J RESISTOR KD-LX330R
R 242 RK473JA0J RESISTOR KD-LX330R
R 243 RK473JA0J RESISTOR KD-LX330R
R 244 RK473JA0J RESISTOR KD-LX330R
R 245 RK473JA0J RESISTOR KD-LX330R
R 246 RK473JA0J RESISTOR KD-LX330R
R 251 RK153JA0J RESISTOR RK 1/10W 15
R 252 RK333JA0J RESISTOR RK 1/10W 33K
R 253 RK123JA0J RESISTOR RK 1/10W 12K
R 255 RK472JA0J RESISTOR RK 1/10W 4.7K
R 272 RK104JA0J RESISTOR KD-LX330R
R 273 RK822JA0J RESISTOR KD-LX330R
R 274 RK822JA0J RESISTOR KD-LX330R
R 275 RK103JA0J RESISTOR KD-LX330R
R 276 RK103JA0J RESISTOR KD-LX330R
R 277 RK102JA0J RESISTOR KD-LX330R
R 301 RK243JA0J RESISTOR KD-LX330R
R 302 RK243JA0J RESISTOR KD-LX330R
R 303 RK333JA0J RESISTOR KD-LX330R
R 304 RK333JA0J RESISTOR KD-LX330R
R 305 RK154JA0J RESISTOR KD-LX330R
R 322 RK103JA0J RESISTOR KD-LX330R
R 323 RK103JA0J RESISTOR KD-LX330R
R 324 RK104JA0J RESISTOR KD-LX330R
R 325 RK104JA0J RESISTOR KD-LX330R
R 326 RK103JA0J RESISTOR KD-LX330R
R 327 RK562JA0J RESISTOR KD-LX330R
R 328 RK153JA0J RESISTOR KD-LX330R
R 329 RK000JA0J RESISTOR KD-LX330R
R 330 RK473JA0J RESISTOR KD-LX330R
R 331 RK104JA0J RESISTOR KD-LX330R
R 332 RK104JA0J RESISTOR KD-LX330R
R 333 RK473JA0J RESISTOR KD-LX330R
R 334 RK473JA0J RESISTOR KD-LX330R
R 335 RK821JA0J RESISTOR KD-LX330R
R 336 RK473JA0J RESISTOR KD-LX330R
R 337 RK472JA0J RESISTOR KD-LX330R
R 338 RK101JA0J RESISTOR KD-LX330R
R 339 RK101JA0J RESISTOR KD-LX330R
R 340 RK474JA0J RESISTOR KD-LX330R
R 341 RK105JA0J RESISTOR KD-LX330R
R 342 RK105JA0J RESISTOR KD-LX330R
R 343 RK105JA0J RESISTOR KD-LX330R
R 344 RK105JA0J RESISTOR KD-LX330R
R 351 RK224JA0J RESISTOR KD-LX330R
R 352 RK224JA0J RESISTOR KD-LX330R
R 353 RK105JA0J RESISTOR RK 1/10W 1M
R 354 RK682JA0J RESISTOR RK 1/10W 6.8K
R 355 RK224JA0J RESISTOR RK 1/10W 220K
R 358 RK332JA0J RESISTOR RK 1/10W 3.3K
