KD-LX110R/KD-LX330R
3-12
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 01
A
R 361 RK473JA0J RESISTOR KD-LX110R
R 362 RK473JA0J RESISTOR KD-LX110R
R 363 RK154JA0J RESISTOR KD-LX110R
R 364 RK154JA0J RESISTOR KD-LX110R
R 365 RK333JA0J RESISTOR KD-LX110R
R 366 RK333JA0J RESISTOR KD-LX110R
R 367 RK154JA0J RESISTOR KD-LX110R
R 368 RK154JA0J RESISTOR KD-LX110R
R 369 RK103JA0J RESISTOR KD-LX110R
R 370 RK103JA0J RESISTOR KD-LX110R
R 401 RK243JA0J RESISTOR KD-LX330R
R 402 RK243JA0J RESISTOR KD-LX330R
R 403 RK333JA0J RESISTOR KD-LX330R
R 404 RK333JA0J RESISTOR KD-LX330R
R 405 RK154JA0J RESISTOR KD-LX330R
R 451 RK224JA0J RESISTOR KD-LX330R
R 452 RK224JA0J RESISTOR KD-LX330R
R 454 RK682JA0J RESISTOR RK 1/10W 6.8K
R 455 RK224JA0J RESISTOR RK 1/10W 220K
R 458 RK332JA0J RESISTOR RK 1/10W 3.3K
R 461 RK473JA0J RESISTOR KD-LX110R
R 462 RK473JA0J RESISTOR KD-LX110R
R 463 RK154JA0J RESISTOR KD-LX110R
R 464 RK154JA0J RESISTOR KD-LX110R
R 465 RK333JA0J RESISTOR KD-LX110R
R 466 RK333JA0J RESISTOR KD-LX110R
R 467 RK154JA0J RESISTOR KD-LX110R
R 468 RK154JA0J RESISTOR KD-LX110R
R 469 RK103JA0J RESISTOR KD-LX110R
R 470 RK103JA0J RESISTOR KD-LX110R
R 501 RK823JA0J RESISTOR RK 1/10W 82K
R 502 RK823JA0J RESISTOR RK 1/10W 82K
R 503 RK823JA0J RESISTOR RK 1/10W 82K
R 504 RK823JA0J RESISTOR RK 1/10W 82K
R 505 RK154JA0J RESISTOR RK 1/10W 150K
R 506 RK154JA0J RESISTOR RK 1/10W 150K
R 507 RK220JA0J RESISTOR RK 1/10W 22
R 508 RK220JA0J RESISTOR RK 1/10W 22
R 509 RK821JA1J RESISTOR RK 1/10W 820
R 510 RK473JA0J RESISTOR RK 1/10W 47K
R 511 RK822JA0J RESISTOR RK 1/10W 8.2K
R 512 RK202JA0J RESISTOR RK 1/10W 2K
R 513 RK102JA0J RESISTOR RK 1/10W 1K
R 514 RK273JA0J RESISTOR RK 1/10W 27K
R 515 RK823JA0J RESISTOR RK 1/10W 82K
R 516 RK101JA0J RESISTOR RK 1/10W 100
R 520 RK222JA0J RESISTOR RK 1/10W 2.2K
R 521 RK472JA0J RESISTOR RK 1/10W 4.7K
R 522 RK472JA0J RESISTOR RK 1/10W 4.7K
R 523 RK472JA0J RESISTOR RK 1/10W 4.7K
R 524 RK472JA0J RESISTOR RK 1/10W 4.7K
R 525 RK103JA0J RESISTOR RK 1/10W 10K
R 530 RK225JA0J RESISTOR RK 1/10W 2.2K
R 531 RK562JA0J RESISTOR RK 1/10W 5.6K
R 532 RK473JA0J RESISTOR RK 1/10W 47K
R 533 RK474JA0J RESISTOR RK 1/10W 470K
R 536 RK333JA0J RESISTOR RK 1/10W 33K
R 537 RK103JA0J RESISTOR RK 1/10W 10K
R 540 RK000JA0J RESISTOR RK 1/10W 0
R 541 RK101JA0J RESISTOR RK 1/10W 100
R 542 RK101JA0J RESISTOR RK 1/10W 100
R 543 RK000JA0J RESISTOR RK 1/10W 0
R 544 RK000JA0J RESISTOR RK 1/10W 0
R 545 RK101JA0J RESISTOR RK 1/10W 100
R 547 RK101JA0J RESISTOR RK 1/10W 100
R 550 RK105JA0J RESISTOR RK 1/10W 1M
R 555 RK000JA0J RESISTOR RK 1/10W 0
R 556 RK106JA0J RESISTOR RK 1/10W 10M
R 581 RK332JA0J RESISTOR RK 1/10W 3.3K
R 582 RK122JA0J RESISTOR RK 1/10W 1.2K
R 583 RK332JA0J RESISTOR RK 1/10W 3.3K
R 584 RK182JA0J RESISTOR RK 1/10W 1.8
R 585 RK682JA0J RESISTOR RK 1/10W 6.8K
R 586 RK682JA0J RESISTOR RK 1/10W 6.8K
R 587 RK682JA0J RESISTOR RK 1/10W 6.8K
R 588 RK682JA0J RESISTOR RK 1/10W 6.8K
R 589 RK392JA0J RESISTOR RK 1/10W 3.9K
R 590 RK472JA0J RESISTOR RK 1/10W 4.7K
R 591 RK392JA0J RESISTOR RK 1/10W 3.9K
R 592 RK472JA0J RESISTOR RK 1/10W 4.7K
R 593 RK392JA0J RESISTOR RK 1/10W 3.9K
R 594 RK472JA0J RESISTOR RK 1/10W 4.7K
R 595 RK103JA0J RESISTOR RK 1/10W 10K
R 596 RK333JA0J RESISTOR RK 1/10W 33K
R 597 RD104J3CC RESISTOR RD 1/4W 100K
R 701 RK473JA0J RESISTOR RK 1/10W 47K
R 702 RK101JA0J RESISTOR RK 1/10W 100
R 703 RK473JA0J RESISTOR RK 1/10W 47K
R 704 RK473JA0J RESISTOR RK 1/10W 47K
R 705 RK473JA0J RESISTOR RK 1/10W 47K
R 706 RK103JA0J RESISTOR RK 1/10W 10K
R 707 RK472JA0J RESISTOR RK 1/10W 4.7K
R 708 RK472JA0J RESISTOR RK 1/10W 4.7K
R 709 RK472JA0J RESISTOR RK 1/10W 4.7K
R 710 RK103JA0J RESISTOR RK 1/10W 10K
R 711 RK103JA0J RESISTOR RK 1/10W 10K
R 712 RK103JA0J RESISTOR RK 1/10W 10K
R 713 RK222JA0J RESISTOR RK 1/10W 2.2K
R 714 RK103JA0J RESISTOR RK 1/10W 10K
R 715 RK472JA0J RESISTOR RK 1/10W 4.7K
R 716 RK472JA0J RESISTOR RK 1/10W 4.7K
R 717 RK472JA0J RESISTOR RK 1/10W 4.7K
R 718 RK104JA0J RESISTOR RK 1/10W 100K
R 719 RK104JA0J RESISTOR RK 1/10W 100K
R 720 RK331JA0J RESISTOR RK 1/10W 330
R 721 RK103JA0J RESISTOR RK 1/10W 10K
R 722 RK103JA0J RESISTOR RK 1/10W 10K
R 723 RK102JA0J RESISTOR RK 1/10W 1K
R 724 RK271JA0J RESISTOR RK 1/10W 270
R 725 RK271JA0J RESISTOR RK 1/10W 270
R 726 RK473JA0J RESISTOR RK 1/10W 47K
R 728 RK103JA0J RESISTOR RK 1/10W 10K
R 730 RK103JA0J RESISTOR RK 1/10W 10K
R 731 RK473JA0J RESISTOR RK 1/10W 47K
R 732 RK473JA0J RESISTOR RK 1/10W 47K
R 733 RK473JA0J RESISTOR RK 1/10W 47K
R 734 RK472JA0J RESISTOR RK 1/10W 4.7K
R 735 RK472JA0J RESISTOR RK 1/10W 4.7K
R 736 RK102JA0J RESISTOR RK 1/10W 1K
R 737 RK103JA0J RESISTOR RK 1/10W 10K
R 738 RK103JA0J RESISTOR RK 1/10W 10K
R 739 RK473JA0J RESISTOR RK 1/10W 47K
R 740 RK473JA0J RESISTOR KD-LX330R
R 742 RK103JA0J RESISTOR RK 1/10W 10K
R 743 RK473JA0J RESISTOR RK 1/10W 47K
R 746 RK473JA0J RESISTOR RK 1/10W 47K
(Main board)
