JVC KD-LX330R Service Manual

KD-LX110R/KD-LX330R
3-13
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 01
A
R 747 RK473JA0J RESISTOR RK 1/10W 47K
R 748 RK473JA0J RESISTOR RK 1/10W 47K
R 749 RK473JA0J RESISTOR RK 1/10W 47K
R 750 RK473JA0J RESISTOR RK 1/10W 47K
R 751 RK106JA0J RESISTOR RK 1/10W 10M
R 752 RK473JA0J RESISTOR KD-LX110R
R 757 RK103JA0J RESISTOR RK 1/10W 10K
R 758 RK331JA0J RESISTOR RK 1/10W 330
R 761 RK103JA0A RESISTOR RK1/10W 10 K
R 762 RK222JA0J RESISTOR RK1/10W 2.2K
R 763 RK222JA0J RESISTOR RK1/10W 2.2K
R 764 RK222JA0J RESISTOR RK1/10W 2.2K
R 765 RK222JA0J RESISTOR RK1/10W 2.2K
R 772 RK473JA0J RESISTOR RK 1/10W 47K
R 773 RK223JA0J RESISTOR RK 1/10W 22K
R 774 RK101JA0J RESISTOR RK 1/10W 100
R 775 RK103JA0J RESISTOR RK 1/10W 10K
R 776 RK104JA0J RESISTOR RK 1/10W 100K
R 777 RK223JA0J RESISTOR RK 1/10W 22K
R 778 RK101JA0J RESISTOR RK 1/10W 100
R 779 RK473JA0J RESISTOR RK 1/10W 47K
R 781 RK331JA0J RESISTOR RK 1/10W 330
R 782 RK104JA0J RESISTOR RK 1/10W 100K
R 791 RK102JA0J RESISTOR RK 1/10W 1K
R 821 RD102J3CQ RESISTOR KD-LX330R
R 822 RK822JA0J RESISTOR KD-LX330R
R 823 RK223JA0J RESISTOR KD-LX330R
R 824 RK822JA0J RESISTOR KD-LX330R
R 825 RK223JA0J RESISTOR KD-LX330R 22K
R 826 RK153JA0J RESISTOR KD-LX330R
R 827 RK472JA0J RESISTOR KD-LX330R
R 828 RK223JA0J RESISTOR KD-LX330R
R 829 RK223JA0J RESISTOR KD-LX330R
R 830 RK103JA0J RESISTOR KD-LX330R
R 831 RK820JA0J RESISTOR KD-LX330R
R 911 RK222JA0J RESISTOR RK 1/10W 2.2K
R 912 RK222JA0J RESISTOR RK 1/10W 2.2K
R 941 RK273JA0J RESISTOR RK 1/10W 27K
R 943 RK562JA0J RESISTOR RK 1/10W 5.6
R 951 RK562JA0J RESISTOR KD-LX330R
R 952 RK102JA0J RESISTOR RK 1/10W 1K
R 953 RK562JA0J RESISTOR RK 1/10W 5.6K
R 954 RK103JA0J RESISTOR RK 1/10W 10K
R 962 RK912JA0J RESISTOR RK 1/10W 9.1K
R 963 RK472JA0J RESISTOR RK 1/10W 4.7K
R 970 RK123JA0J RESISTOR RK 1/10W 12K
R 971 RK393JA0J RESISTOR RK 1/10W 39K
R 976 RK222JA1J RESISTOR RK 1/10W 2.2
R 977 RK222JA1J RESISTOR RK 1/10W 2.2
R 978 RK104JA1J N.F RESISTOR RK 1/10W 100
R 979 RD102J3CQ RESISTOR RD 1/4W 1
R 981 RK183JA0J RESISTOR
R 984 RK473JA0J RESISTOR RK 1/10W 47K
R 985 RK472JA0J N.F RESISTOR RK 1/10W 4.7K
R 986 RK102JA0J RESISTOR RK 1/10W 1K
R 987 RK473JA0J RESISTOR RK 1/10W 47K
R 988 RK332JA0J RESISTOR RK 1/10W 3.3K
S 651 000392900-T SWITCH SW MPU12270MLB1
S 652 000392900-T SWITCH SW MPU12270MLB1
S 653 000392900-T SWITCH SW MPU12270MLB1
TH981 TH103J05J THERMISTOR THERMISTOR 10K
TU 1 000153580 TUNNER PUCK
VR 31 SFR503027 ENCODER
X 31 000067990 CRYSTAL
X 51 000171200-T CRYSTAL X'TAL 4.332MHZ
X 521 000171590-T CRYSTAL X'TAL 16.9344MH
X 701 000171600-T CRYSTAL X'TAL 12.5MHZ
X 702 QAX0401-001 CRYSTAL X'TAL 32.768KHZ
(Main board)
Item
Parts number Parts name Area
Remarks
A
