KD-LX333
3-10
D111 DIAP202UL DIODE ARRAY DAP202U-X
D131 DIAP202UL DIODE ARRAY DAP202U-X
D161 DIAN217UL SI.DIODE
D231 DIAP202UL DIODE ARRAY DAP202U-X
D3 DIAN202UL DIODE ARRAY DAN202U-W
D332 DIAN202UL DIODE ARRAY DAN202U-W
D351 DIAN202UL DIODE ARRAY DAN202U-W
D451 DIAN202UL DIODE ARRAY DAN202U-W
D701 DI0CRS03L SI.DIODE CRS03-X
D711 DI1SS400L SI.DIODE
D941 DI1SS400L SI.DIODE
D961 000372050 ZENER DIODE 1N5404TU-15
D962 DI0CRS03L SI.DIODE CRS03-X
D963 DI1SS400L SI.DIODE
D965 DIAN202UL DIODE ARRAY DAN202U-W
D967 DI0CRS03L SI.DIODE CRS03-X
D978 Z0UDZ11BL ZENER DIODE UDZ11B-X
D980 DI1SS400L SI.DIODE
IC151 000474740-T IC NJM4565MD
IC171 000474740-T IC NJM4565MD
IC21 000774230-T IC TB2118F-X
IC301 000874370-T IC BA3220FV-X
IC321 000874410-T IC M5282FP-X
IC322 000874420-T IC BU4066BCFV-X
IC323 000474740-T IC NJM4565MD
IC401 000874370-T IC BA3220FV-X
IC501 000874440-T IC TA2147F-X
IC521 000874450 IC TC9490FA
IC581 000874460 IC FAN8037
IC701 000974260 IC UPD784215AGC101
IC702 000974280-T IC
IC703 000874430-T IC BR24C16F-X
IC771 000774040-T IC HD74HC126FP
IC821 000874400-T IC NJM2100M
IC911 000874470 IC BD3860K
IC941 000874560 IC TA8273H
IC951 000574840-T IC NJM2904M
IC961 000874970 IC HA13164A
J1 EX0000487 ANTENNA JACK
L1 LC4R7J257 CHOKE COIL LC 4.7MH
L21 LC1R8K24J RF COIL 1.8MH
L521 LC470J10J CHOKE COIL LC 47MH
L522 LC470J10J CHOKE COIL LC 47MH
L524 LC470J10J CHOKE COIL LC 47MH
L701 LC470J10J CHOKE COIL LC 47MH
L718 LC1R8K24J RF COIL LC 1.8MH
L719 LC1R8K24J RF COIL 1.8MH
L771 LC1R8K24J RF COIL 1.8MH
L772 LC1R8K24J RF COIL 1.8MH
L961 000125560 CHOKE COIL
1 TRC4081(QRS)L TRANSISTOR 2SC4081/
R/-X
10 TRC114EUL-A DIGI.TRANSISTOR DTC114EUA-X
131 TRD1048(678)L TRANSISTOR 2SD1048/6-7/-X
132 TRD1048(678)L TRANSISTOR 2SD1048/6-7/-X
161 TRC4081(QRS)L TRANSISTOR 2SC4081/
R/-X
2 TRC4081(QRS)L TRANSISTOR 2SC4081/
R/-X
231 TRD1048(678)L TRANSISTOR 2SD1048/6-7/-X
232 TRD1048(678)L TRANSISTOR 2SD1048/6-7/-X
321 TRC114EUL-A DIGI.TRANSISTOR DTC114EUA-X
322 TRC114EUL-A DIGI.TRANSISTOR DTC114EUA-X
323 TRD1048(678)L TRANSISTOR 2SD1048/6-7/-X
5 TRA1576(QRS)L-A TRANSISTOR 2SA1576A/
R/-X
501 TRB1241(PQR)8 TRANSISTOR 2SB1241/
R/-T
581 TRB1241(PQR)8 TRANSISTOR 2SB1241/
R/-T
590 TRA114EUL-A DIGI.TRANSISTOR DTA114EUA-X
591 TRC114EUL-A DIGI.TRANSISTOR DTC114EUA-X
6 TRB1197(QR)L TRANSISTOR 2SB1197K/
R/-X
700 TRA114EUL-A DIGI.TRANSISTOR DTA114EUA-X
701 TRC114EUL-A DIGI.TRANSISTOR DTC114EUA-X
702 TRA1576(QRS)L-A TRANSISTOR 2SA1576A/
R/-X
791 TRC114EUL-A DIGI.TRANSISTOR DTC114EUA-X
8 TRC114EUL-A DIGI.TRANSISTOR DTC114EUA-X
942 TRC114TUL-A DIGI.TRANSISTOR DTC114EUA-X
943 TRC114EUL-A DIGI.TRANSISTOR DTC114EUA-X
965 TRC114EUL-A DIGI.TRANSISTOR DTC114EUA-X
966 TRA1576(QRS)L-A TRANSISTOR 2SA1576A/
R/-X
967 TRC4081(QRS)L TRANSISTOR 2SC4081/
R/-X
977 TRA114EUL-A DIGI.TRANSISTOR DTA114EUA-X
979 TRA114EUL-A DIGI.TRANSISTOR DTA114EUA-X
981 TRA114EUL-A DIGI.TRANSISTOR DTA114EUA-X
982 TRC114EUL-A DIGI.TRANSISTOR DTC114EUA-X
983 TRC4081(QRS)L TRANSISTOR 2SC4081/
R/-X
R1 RK000JA0J C.RESISTOR 1/10W 0
R10 RK103JA0J C.RESISTOR 1/10W 10 K
R101 RK103JA0J C.RESISTOR 1/10W 10 K
R102 RK103JA0J C.RESISTOR 1/10W 10 K
R111 RK224JA0J COMP.RESISTOR 1/10W 220 K
R118 RK104JA0J COMP.RESISTOR 1/10W 100 K
R119 RK101JA0J UNF.C.RESISTOR 1/10W 100
R131 RK222JA0J C.RESISTOR 1/10W 2.2 K
R132 RK222JA0J C.RESISTOR 1/10W 2.2 K
R133 RK681JA0J C.RESISTOR 1/10W 680
R134 RK681JA0J C.RESISTOR 1/10W 680
R135 RK101JA0J UNF.C.RESISTOR 1/10W 100
R136 RK101JA0J UNF.C.RESISTOR 1/10W 100
R14 RK000JA0J C.RESISTOR 1/10W 0
R141 RK473JA0J COMP.RESISTOR 1/10W 47 K
R142 RK473JA0J COMP.RESISTOR 1/10W 47 K
R143 RK473JA0J COMP.RESISTOR 1/10W 47 K
R144 RK473JA0J COMP.RESISTOR 1/10W 47 K
R145 RK473JA0J COMP.RESISTOR 1/10W 47 K
R146 RK473JA0J COMP.RESISTOR 1/10W 47 K
R151 RK153JA0J COMP.RESISTOR 1/10W 15 K
R152 RK333JA0J COMP.RESISTOR 1/10W 33 K
R153 RK123JA0J C.RESISTOR 1/10W 12 K
R155 RK472JA0J C.RESISTOR 1/10W 4.7 K
R161 RK473JA0J COMP.RESISTOR 1/10W 47 K
R162 RK123JA0J C.RESISTOR 1/10W 12 K
R163 RK184JA0J C.RESISTOR 1/10W 180 K
R164 RK223JA0J COMP.RESISTOR 1/10W 22 K
R165 RK391JA0J C.RESISTOR 1/10W 390
R166 RK102JA0J C.RESISTOR 1/10W 1 K
R167 RK274JA0J COMP.RESISTOR 1/10W 270 K
R171 RK471JA0J C.RESISTOR 1/10W 470
R172 RK104JA0J COMP.RESISTOR 1/10W 100 K
R173 RK822JA0J C.RESISTOR 1/10W 8.2 K
R174 RK822JA0J C.RESISTOR 1/10W 8.2 K
R175 RK103JA0J C.RESISTOR 1/10W 10 K
R176 RK103JA0J C.RESISTOR 1/10W 10 K
R177 RK102JA0J C.RESISTOR 1/10W 1 K
R18 RK223JA0J COMP.RESISTOR 1/10W 22 K
R201 RK103JA0J C.RESISTOR 1/10W 10 K
R202 RK103JA0J C.RESISTOR 1/10W 10 K
R21 RK100JA0J C.RESISTOR 1/10W 10
R211 RK224JA0J COMP.RESISTOR 1/10W 220 K
R218 RK104JA0J COMP.RESISTOR 1/10W 100 K
Item
Parts number Parts name Ar
Electrical parts list (Main board)
Remarks
Block No. 01
A
Item
Parts number Parts name Ar
Remarks
A
