KD-LX333
3-11
R219 RK101JA0J UNF.C.RESISTOR 1/10W 100
R22 RK622JA0J C.RESISTOR 1/10W 6.2 K
R23 RK222JA0J C.RESISTOR 1/10W 2.2 K
R231 RK222JA0J C.RESISTOR 1/10W 2.2 K
R232 RK222JA0J C.RESISTOR 1/10W 2.2 K
R233 RK681JA0J C.RESISTOR 1/10W 680
R234 RK681JA0J C.RESISTOR 1/10W 680
R235 RK101JA0J UNF.C.RESISTOR 1/10W 100
R236 RK101JA0J UNF.C.RESISTOR 1/10W 100
R24 RK222JA0J C.RESISTOR 1/10W 2.2 K
R241 RK473JA0J COMP.RESISTOR 1/10W 47 K
R242 RK473JA0J COMP.RESISTOR 1/10W 47 K
R243 RK473JA0J COMP.RESISTOR 1/10W 47 K
R244 RK473JA0J COMP.RESISTOR 1/10W 47 K
R245 RK473JA0J COMP.RESISTOR 1/10W 47 K
R246 RK473JA0J COMP.RESISTOR 1/10W 47 K
R25 RK222JA0J C.RESISTOR 1/10W 2.2 K
R251 RK153JA0J COMP.RESISTOR 1/10W 15 K
R252 RK333JA0J COMP.RESISTOR 1/10W 33 K
R253 RK123JA0J C.RESISTOR 1/10W 12 K
R255 RK472JA0J C.RESISTOR 1/10W 4.7 K
R27 RK393JA0J COMP.RESISTOR 1/10W 39 K
R272 RK104JA0J COMP.RESISTOR 1/10W 100 K
R273 RK822JA0J C.RESISTOR 1/10W 8.2 K
R274 RK822JA0J C.RESISTOR 1/10W 8.2 K
R275 RK103JA0J C.RESISTOR 1/10W 10 K
R276 RK103JA0J C.RESISTOR 1/10W 10 K
R277 RK102JA0J C.RESISTOR 1/10W 1 K
R28 RK103JA0J C.RESISTOR 1/10W 10 K
R29 RK101JA0J UNF.C.RESISTOR 1/10W 100
R301 RK243JA0J C.RESISTOR 1/10W 24 K
R302 RK243JA0J C.RESISTOR 1/10W 24 K
R303 RK333JA0J COMP.RESISTOR 1/10W 33 K
R304 RK333JA0J COMP.RESISTOR 1/10W 33 K
R305 RK154JA0J C.RESISTOR 1/10W 150 K
R31 RK222JA0J C.RESISTOR 1/10W 2.2 K
R32 RK473JA0J COMP.RESISTOR 1/10W 47 K
R322 RK103JA0J C.RESISTOR 1/10W 10 K
R323 RK103JA0J C.RESISTOR 1/10W 10 K
R324 RK104JA0J COMP.RESISTOR 1/10W 100 K
R325 RK104JA0J COMP.RESISTOR 1/10W 100 K
R326 RK103JA0J C.RESISTOR 1/10W 10 K
R327 RK562JA0J C.RESISTOR 1/10W 5.6 K
R328 RK153JA0J COMP.RESISTOR 1/10W 15 K
R329 RK000JA0J C.RESISTOR 1/10W 0
R330 RK473JA0J COMP.RESISTOR 1/10W 47 K
R331 RK104JA0J COMP.RESISTOR 1/10W 100 K
R332 RK104JA0J COMP.RESISTOR 1/10W 100 K
R333 RK473JA0J COMP.RESISTOR 1/10W 47 K
R334 RK473JA0J COMP.RESISTOR 1/10W 47 K
R335 RK821JA0J C.RESISTOR 1/10W 820
R336 RK473JA0J COMP.RESISTOR 1/10W 47 K
R337 RK472JA0J C.RESISTOR 1/10W 4.7 K
R338 RK101JA0J UNF.C.RESISTOR 1/10W 100
R339 RK101JA0J UNF.C.RESISTOR 1/10W 100
R340 RK474JA0J COMP.RESISTOR 1/10W 470 K
R341 RK105JA0J C.RESISTOR 1/10W 1 M
R342 RK105JA0J C.RESISTOR 1/10W 1 M
R343 RK105JA0J C.RESISTOR 1/10W 1 M
R344 RK105JA0J C.RESISTOR 1/10W 1 M
R351 RK224JA0J COMP.RESISTOR 1/10W 220 K
R352 RK224JA0J COMP.RESISTOR 1/10W 220 K
R353 RK105JA0J C.RESISTOR 1/10W 1 M
R354 RK682JA0J C.RESISTOR 1/10W 6.8 K
R355 RK224JA0J COMP.RESISTOR 1/10W 220 K
R358 RK332JA0J C.RESISTOR 1/10W 3.3 K
R4 RK473JA0J COMP.RESISTOR 1/10W 47 K
R401 RK243JA0J C.RESISTOR 1/10W 24 K
R402 RK243JA0J C.RESISTOR 1/10W 24 K
R403 RK333JA0J COMP.RESISTOR 1/10W 33 K
R404 RK333JA0J COMP.RESISTOR 1/10W 33 K
R405 RK154JA0J C.RESISTOR 1/10W 150 K
R451 RK224JA0J COMP.RESISTOR 1/10W 220 K
R452 RK224JA0J COMP.RESISTOR 1/10W 220 K
R454 RK682JA0J C.RESISTOR 1/10W 6.8 K
R455 RK224JA0J COMP.RESISTOR 1/10W 220 K
R458 RK332JA0J C.RESISTOR 1/10W 3.3 K
R5 RK332JA0J C.RESISTOR 1/10W 3.3 K
R501 RK823JA0J COMP.RESISTOR 1/10W 82 K
R502 RK823JA0J COMP.RESISTOR 1/10W 82 K
R503 RK823JA0J COMP.RESISTOR 1/10W 82 K
R504 RK823JA0J COMP.RESISTOR 1/10W 82 K
R505 RK154JA0J C.RESISTOR 1/10W 150 K
R506 RK154JA0J C.RESISTOR 1/10W 150 K
R507 RK220JA0J C.RESISTOR 1/10W 22
R508 RK220JA0J C.RESISTOR 1/10W 22
R509 RK821JA1J C.RESISTOR 1/10W 820
R510 RK473JA0J COMP.RESISTOR 1/10W 47 K
R511 RK103JA0J C.RESISTOR 1/10W 10 K
R512 RK202JA0J C.RESISTOR 1/10W 2 K
R513 RK102JA0J C.RESISTOR 1/10W 1 K
R514 RK273JA0J COMP.RESISTOR 1/10W 27 K
R515 RK823JA0J COMP.RESISTOR 1/10W 82 K
R516 RK101JA0J UNF.C.RESISTOR 1/10W 100
R520 RK222JA0J C.RESISTOR 1/10W 2.2 K
R521 RK472JA0J C.RESISTOR 1/10W 4.7 K
R522 RK472JA0J C.RESISTOR 1/10W 4.7 K
R523 RK472JA0J C.RESISTOR 1/10W 4.7 K
R524 RK472JA0J C.RESISTOR 1/10W 4.7 K
R525 RK103JA0J C.RESISTOR 1/10W 10 K
R527 RK820JA0J C.RESISTOR 1/10W 82
R530 RK225JA0J C.RESISTOR 1/10W 2.2 M
R531 RK562JA0J C.RESISTOR 1/10W 5.6 K
R532 RK473JA0J COMP.RESISTOR 1/10W 47 K
R533 RK474JA0J COMP.RESISTOR 1/10W 470 K
R536 RK153JA0J COMP.RESISTOR 1/10W 15 K
R537 RK103JA0J C.RESISTOR 1/10W 10 K
R540 RK000JA0J C.RESISTOR 1/10W 0
R541 RK101JA0J UNF.C.RESISTOR 1/10W 100
R542 RK101JA0J UNF.C.RESISTOR 1/10W 100
R543 RK000JA0J C.RESISTOR 1/10W 0
R544 RK000JA0J C.RESISTOR 1/10W 0
R545 RK101JA0J UNF.C.RESISTOR 1/10W 100
R547 RK101JA0J UNF.C.RESISTOR 1/10W 100
R550 RK105JA0J C.RESISTOR 1/10W 1 M
R555 RK000JA0J C.RESISTOR 1/10W 0
R556 RK106JA0J C.RESISTOR 1/10W 10 M
R581 RK332JA0J C.RESISTOR 1/10W 3.3 K
R582 RK122JA0J C.RESISTOR 1/10W 1.2 K
R583 RK332JA0J C.RESISTOR 1/10W 3.3 K
R584 RK182JA0J C.RESISTOR 1/10W 1.8 K
R585 RK682JA0J C.RESISTOR 1/10W 6.8 K
R586 RK682JA0J C.RESISTOR 1/10W 6.8 K
R587 RK682JA0J C.RESISTOR 1/10W 6.8 K
R588 RK682JA0J C.RESISTOR 1/10W 6.8 K
R589 RK392JA0J C.RESISTOR 1/10W 3.9 K
Item
Parts number Parts name Ar
Electrical parts list (Main board)
Remarks
Block No. 01
A
Item
Parts number Parts name Ar
Remarks
