KD-LX333
3-12
R590 RK472JA0J C.RESISTOR 1/10W 4.7 K
R591 RK392JA0J C.RESISTOR 1/10W 3.9 K
R592 RK472JA0J C.RESISTOR 1/10W 4.7 K
R593 RK392JA0J C.RESISTOR 1/10W 3.9 K
R594 RK472JA0J C.RESISTOR 1/10W 4.7 K
R595 RK103JA0J C.RESISTOR 1/10W 10 K
R596 RK333JA0J COMP.RESISTOR 1/10W 33 K
R6 RK8R2JA1J C.RESISTOR 1/10W 8.2
R7 RK473JA0J COMP.RESISTOR 1/10W 47 K
R700 RK103JA0J C.RESISTOR 1/10W 10 K
R701 RK473JA0J COMP.RESISTOR 1/10W 47 K
R702 RK101JA0J UNF.C.RESISTOR 1/10W 100
R703 RK473JA0J COMP.RESISTOR 1/10W 47 K
R704 RK473JA0J COMP.RESISTOR 1/10W 47 K
R705 RK473JA0J COMP.RESISTOR 1/10W 47 K
R706 RK103JA0J C.RESISTOR 1/10W 10 K
R707 RK472JA0J C.RESISTOR 1/10W 4.7 K
R708 RK472JA0J C.RESISTOR 1/10W 4.7 K
R709 RK472JA0J C.RESISTOR 1/10W 4.7 K
R710 RK103JA0J C.RESISTOR 1/10W 10 K
R711 RK103JA0J C.RESISTOR 1/10W 10 K
R712 RK103JA0J C.RESISTOR 1/10W 10 K
R713 RK102JA0J C.RESISTOR 1/10W 1 K
R714 RK103JA0J C.RESISTOR 1/10W 10 K
R715 RK472JA0J C.RESISTOR 1/10W 4.7 K
R716 RK472JA0J C.RESISTOR 1/10W 4.7 K
R717 RK472JA0J C.RESISTOR 1/10W 4.7 K
R718 RK104JA0J COMP.RESISTOR 1/10W 100 K
R719 RK104JA0J COMP.RESISTOR 1/10W 100 K
R720 RK331JA0J C.RESISTOR 1/10W 330
R721 RK103JA0J C.RESISTOR 1/10W 10 K
R722 RK103JA0J C.RESISTOR 1/10W 10 K
R723 RK102JA0J C.RESISTOR 1/10W 1 K
R724 RK271JA0J C.RESISTOR 1/10W 270
R725 RK271JA0J C.RESISTOR 1/10W 270
R726 RK473JA0J COMP.RESISTOR 1/10W 47 K
R727 RK473JA0J COMP.RESISTOR 1/10W 47 K
R728 RK103JA0J C.RESISTOR 1/10W 10 K
R730 RK103JA0J C.RESISTOR 1/10W 10 K
R731 RK473JA0J COMP.RESISTOR 1/10W 47 K
R732 RK473JA0J COMP.RESISTOR 1/10W 47 K
R733 RK473JA0J COMP.RESISTOR 1/10W 47 K
R734 RK472JA0J C.RESISTOR 1/10W 4.7 K
R735 RK472JA0J C.RESISTOR 1/10W 4.7 K
R737 RK103JA0J C.RESISTOR 1/10W 10 K
R738 RK103JA0J C.RESISTOR 1/10W 10 K
R739 RK473JA0J COMP.RESISTOR 1/10W 47 K
R740 RK473JA0J COMP.RESISTOR 1/10W 47 K
R742 RK103JA0J C.RESISTOR 1/10W 10 K
R743 RK473JA0J COMP.RESISTOR 1/10W 47 K
R746 RK473JA0J COMP.RESISTOR 1/10W 47 K
R747 RK473JA0J COMP.RESISTOR 1/10W 47 K
R748 RK473JA0J COMP.RESISTOR 1/10W 47 K
R749 RK473JA0J COMP.RESISTOR 1/10W 47 K
R750 RK473JA0J COMP.RESISTOR 1/10W 47 K
R751 RK106JA0J C.RESISTOR 1/10W 10 M
R757 RK103JA0J C.RESISTOR 1/10W 10 K
R772 RK473JA0J COMP.RESISTOR 1/10W 47 K
R773 RK223JA0J COMP.RESISTOR 1/10W 22 K
R775 RK103JA0J C.RESISTOR 1/10W 10 K
R776 RK104JA0J COMP.RESISTOR 1/10W 100 K
R777 RK223JA0J COMP.RESISTOR 1/10W 22 K
R779 RK473JA0J COMP.RESISTOR 1/10W 47 K
R781 RK331JA0J C.RESISTOR 1/10W 330
R782 RK104JA0J COMP.RESISTOR 1/10W 100 K
R791 RK102JA0J C.RESISTOR 1/10W 1 K
R8 RK472JA0J C.RESISTOR 1/10W 4.7 K
R821 RD102J3CQ C.RESISTOR 1/4W 1 K
R822 RK822JA0J C.RESISTOR 1/10W 8.2 K
R823 RK223JA0J COMP.RESISTOR 1/10W 22 K
R824 RK822JA0J C.RESISTOR 1/10W 8.2 K
R825 RK223JA0J COMP.RESISTOR 1/10W 22 K
R826 RK153JA0J COMP.RESISTOR 1/10W 15 K
R827 RK472JA0J C.RESISTOR 1/10W 4.7 K
R828 RK223JA0J COMP.RESISTOR 1/10W 22 K
R829 RK223JA0J COMP.RESISTOR 1/10W 22 K
R830 RK103JA0J C.RESISTOR 1/10W 10 K
R831 RK820JA0J C.RESISTOR 1/10W 82
R9 RK473JA0J COMP.RESISTOR 1/10W 47 K
R911 RK222JA0J C.RESISTOR 1/10W 2.2 K
R912 RK222JA0J C.RESISTOR 1/10W 2.2 K
R941 RK273JA0J COMP.RESISTOR 1/10W 27 K
R943 RK562JA0J C.RESISTOR 1/10W 5.6 K
R950 RK000JA0J C.RESISTOR 1/10W 0
R954 RK103JA0J C.RESISTOR 1/10W 10 K
R962 RK912JA0J C.RESISTOR 1/10W 9.1 K
R963 RK472JA0J C.RESISTOR 1/10W 4.7 K
R965 RK473JA0J COMP.RESISTOR 1/10W 47 K
R970 RK123JA0J C.RESISTOR 1/10W 12 K
R971 RK393JA0J COMP.RESISTOR 1/10W 39 K
R975 RK153JA0J COMP.RESISTOR 1/10W 15 K
R976 RK222JA1J C.RESISTOR 1/10W 2.2 K
R977 RK222JA1J C.RESISTOR 1/10W 2.2 K
R978 RK104JA1J C.RESISTOR 1/10W 100 K
R979 RD102J3CQ C.RESISTOR 1/4W 1 K
R981 RK183JA0J COMP.RESISTOR 1/10W 18 K
R984 RK473JA0J COMP.RESISTOR 1/10W 47 K
R985 RK472JA1J COMP.RESISTOR 1/10W 4.7 K
R988 RK332JA0J C.RESISTOR 1/10W 3.3 K
S651 000392900-T TACT SW
S652 000392900-T TACT SW
S653 000392900-T TACT SW
TH700 TH103J05J THERMISTOR
TH981 TH103J05J THERMISTOR
TU1 000153550 TUNNER FAE347-A20
X21 000171510-T CRYSTAL 10.25MHZ
X521 000171590-T CRYSTAL 6.9344MHZ
X701 000171600-T CRYSTAL 12.5MHZ
X702 QAX0401-001 CRYSTAL 32.768KHZ
Item
Parts number Parts name Ar
Electrical parts list (Main board)
Remarks
Block No. 01
