JVC KD-LX333 Service Manual

KD-LX333
3-13
Item
Parts number Parts name Ar
ea
Electrical parts list (Front board)
Remarks
Block No. 02
A
Item
Parts number Parts name Ar
ea
Remarks
A
CN601 KZ040160L CONN.TERMINAL 16P FPC CONNE
CN631 KZ040060L CONN.TERMINAL 6P FPC CONNE
C606 CY104423J C.CAPACITOR
C607 CY104423J C.CAPACITOR
C608 CY104423J C.CAPACITOR
C609 CZ6816D2J C.CAPACITOR
C610 CY475316J C.CAPACITOR
C611 CY475316J C.CAPACITOR
C612 CQ393328J C.CAPACITOR 0.039 MF ECHU
C613 CY180J90J C.CAPACITOR
C614 CY104423J C.CAPACITOR
C615 CY562623J C.CAPACITOR
C616 CY475316J C.CAPACITOR
C617 CY475316J C.CAPACITOR
C623 CY475316J C.CAPACITOR
C661 CY102623J C.CAPACITOR
C662 CY102623J C.CAPACITOR
D623 000372400-T SI.DIODE SML310LT
D624 000372400-T SI.DIODE SML310LT
D625 ZDZS5R1BL ZENER DIODE UDZS5.1 B
D627 000372390-T SI.DIODE LT1F67AF-W
D628 000372400-T SI.DIODE SML310LT
D629 000372400-T SI.DIODE SML310LT
D630 000372400-T SI.DIODE SML310LT
D632 000372400-T SI.DIODE SML310LT
D633 000372400-T SI.DIODE SML310LT
D634 000372400-T SI.DIODE SML310LT
D635 000372400-T SI.DIODE SML310LT
D636 000372400-T SI.DIODE SML310LT
D637 000372400-T SI.DIODE SML310LT
D638 000372400-T SI.DIODE SML310LT
D639 000372400-T SI.DIODE SML310LT
D640 000372340-T SI.DIODE CL-190UB-X
D641 000372340-T SI.DIODE CL-190UB-X
D643 000372400-T SI.DIODE SML310LT
D644 000372400-T SI.DIODE SML310LT
D645 000372400-T SI.DIODE SML310LT
D646 000372400-T SI.DIODE SML310LT
D647 000372400-T SI.DIODE SML310LT
D648 000372400-T SI.DIODE SML310LT
D649 000372400-T SI.DIODE SML310LT
D650 000372400-T SI.DIODE SML310LT
FL611 000282950 CFL
IC601 000974290 IC LC75878W
IC603 000874540 IC RPM6938-SV4
L611 LC680J26L CHOKE COIL 68 MH
L612 000125810-T CHOKE COIL TRANS TR11-B-S
L613 LC100J10J CHOKE COIL 10 MH
PC601 000874550 IC PR-20-W
PC602 000874550 IC PR-20-W
Q
611 TRD2150(QRS)L TRANSISTOR 2SD2150/RS/-W
Q
612 TRD2150(QRS)L TRANSISTOR 2SD2150/RS/-W
Q
613 TRC114YUL-A DIGI.TRANSISTOR DTC114YUA
Q
614 TRC114YUL-A DIGI.TRANSISTOR DTC114YUA
Q
615 TRC114YUL-A DIGI.TRANSISTOR DTC114YUA
Q
616 TRC114YUL-A DIGI.TRANSISTOR DTC114YUA
Q
691 TRC4081(QRS)L TRANSISTOR 2SC4081/
Q
R/-X
Q
692 TRC4081(QRS)L TRANSISTOR 2SC4081/
Q
R/-X
R606 RK222JA0J C.RESISTOR 1/10W 2.2 K
R607 RK222JA0J C.RESISTOR 1/10W 2.2 K
R608 RK222JA0J C.RESISTOR 1/10W 2.2 K
R609 RK683JA0J C.RESISTOR 1/10W 68K
R610 RK222JA0J C.RESISTOR 1/10W 2.2 K
R611 RK472JA0J C.RESISTOR 1/10W 4.7 K
R612 RK472JA0J C.RESISTOR 1/10W 4.7 K
R613 RK681JA0J C.RESISTOR 1/10W 680
R620 RK102JA0J C.RESISTOR 1/10W 1 K
R621 RK271JA0J C.RESISTOR 1/10W 270
R622 RK331JA0J C.RESISTOR 1/10W 330
R623 RK821JA0J C.RESISTOR 1/10W 820
R624 RK821JA0J C.RESISTOR 1/10W 820
R625 RK471JA0J C.RESISTOR 1/10W 470
R626 RK103JA0J C.RESISTOR 1/10W 10 K
R627 RK121JA0J C.RESISTOR 1/10W 120
R628 RK000JA0J C.RESISTOR 1/10W 0
R629 RK102JA0J C.RESISTOR 1/10W 1 K
R630 RK271JA0J C.RESISTOR 1/10W 270
R631 RK391JA0J C.RESISTOR 1/10W 390
R632 RK391JA0J C.RESISTOR 1/10W 390
R633 RK391JA0J C.RESISTOR 1/10W 390
R634 RK391JA0J C.RESISTOR 1/10W 390
R636 RK391JA0J C.RESISTOR 1/10W 390
R637 RK821JA0J C.RESISTOR 1/10W 820
R638 RK821JA0J C.RESISTOR 1/10W 820
R639 RK122JA0J C.RESISTOR 1/10W 1.2 K
R640 RK182JA0J C.RESISTOR 1/10W 1.8 K
R641 RK272JA0J C.RESISTOR 1/10W 2.7 K
R642 RK392JA0J C.RESISTOR 1/10W 3.9 K
R644 RK391JA0J C.RESISTOR 1/10W 390
R645 RK391JA0J C.RESISTOR 1/10W 390
R646 RK271JA0J C.RESISTOR 1/10W 270
R647 RK271JA0J C.RESISTOR 1/10W 270
R648 RK271JA0J C.RESISTOR 1/10W 270
R649 RK271JA0J C.RESISTOR 1/10W 270
R650 RK821JA0J C.RESISTOR 1/10W 820
R651 RK821JA0J C.RESISTOR 1/10W 820
R652 RK122JA0J C.RESISTOR 1/10W 1.2 K
R653 RK182JA0J C.RESISTOR 1/10W 1.8 K
R654 RK272JA0J C.RESISTOR 1/10W 2.7 K
R658 RK181JA0J C.RESISTOR 1/10W 180
R667 RK104JA0J COMP.RESISTOR 1/10W 100 K
R668 RK104JA0J COMP.RESISTOR 1/10W 100 K
R671 RK331JA0J C.RESISTOR 1/10W 330
R672 RK331JA0J C.RESISTOR 1/10W 330
R673 RK332JA0J C.RESISTOR 1/10W 3.3 K
R675 RK332JA0J C.RESISTOR 1/10W 3.3 K
R676 RK181JA0J C.RESISTOR 1/10W 180
R691 RK104JA0J COMP.RESISTOR 1/10W 100 K
R692 RK393JA0J COMP.RESISTOR 1/10W 39 K
R693 RK104JA0J COMP.RESISTOR 1/10W 100 K
R694 RK393JA0J COMP.RESISTOR 1/10W 39 K
S623 000392970-T TACT SW
S624 000392970-T TACT SW
S625 000392980-T TACT SW
S631 000392970-T TACT SW
S632 000392970-T TACT SW
S633 000392970-T TACT SW
S634 000392970-T TACT SW
S635 000392970-T TACT SW
S636 000392970-T TACT SW
S637 000392970-T TACT SW
S639 000392970-T TACT SW
S640 000392970-T TACT SW
S641 000392970-T TACT SW
S642 000392970-T TACT SW
S643 000392970-T TACT SW
VR621 000392860 ENCODER
