KD-LX555R
3-3
General assembly and parts list
Block No. [M][1][M][M]
Symbol
No.
Part No. Part Name Description Local
1 000101560 LCD
2 DG3089021 LCD CASE
3 DG4090030 LCD FILTER
4 DG4091020 ZEBRA CONTACT (
x
2)
5 DG3092040 LIGHTING CASE
6 DG4258000 SPACER(REMO)
7E
x
0000495 6P FLAT CABLE
8E
x
0000535 16P FLAT CABLE
9 DG4152010 SHEET (WIRE)
10 DG3070020 REG.IC BRACET
11 DG4009000 POWER IC BKT
12 DG3005040 REAR BRACKET
13 DG3007010 REAR HEAT SINK
14 E
x
0000558 RCA CORD ASSY
15 YM2626001 SCREW (
x
3)
16
x
T2640BSC SCREW (
x
2)
17
x
T2640BSC SCREW (
x
2)
18 DG3111000 LEAD PLATE
19 E
x
0000559 H-REM CORD ASSY
20 FU15R0031 AUTO FUSE (15A)
21 DG1002012 CHASSIS TOP
22 ------------ CD MECHANISM
23
x
T2640BSC SCREW QYSDST2604Z(
x
3)
24 DG1069011 FRONT COVER
25 DG4004000 BLIND LV40828-002A
26 DG4155000 SHEET (F.COVER)
27
x
M2030PSB SCREW
QYSPSP2003M(
x
2
)
28 E
x
0000557 22P FLAT CABLE
29
x
T2040BSC SCREW (
x
5)
30 DG4259000 SHEET(FFC)
31 DG4260000 SHEET FFC(MECHA
32 DG3010011 BOTTOM ASSY
33 DG3014000 INSULATOR
34 DG4023010 BUTTON B. GUIDE LV41545-001A
35 YM2029000 SCREW
36 YM2626000 SCREW (
x
3)
37 DG4112010 PANEL COVER ASS
38 DG3015000 DOOR BASE ASSY LV31605-001A
39 DG3022000 ROD GEAR LV31610-001A
40 DG3131040 MOVE BKT ASSY
41 YWP020300 C.WASHER (
x
7)
42 DG3038001 CLUTCH ASSY LV30981-005A
43 YWP020301 C.WASHER (
x
2)
44 DG4039000 GEAR-4 LV41466-001A
45 DG4041000 GEAR-5 LV41467-001A
46 DG3038002 CLUTCH ASSY LV30981-007A
47 DG4054000 GEAR-1 LV41463-001A
48 DG4055000 GEAR-2 LV41464-001A
49 DG3056000 GEAR-3 LV31611-001A
50 000013660 FEED MOTOR QAR0029-001
51 DG4037000 GEAR-J (WORM) LV40864-001A
52 KA2502011 2P CONECTOR ASS
53 000013680 MOTOR QAR0188-001
54 DG4052000 GEAR-A (WORM) LV40783-001A
55 KA2502012 2P CONECTOR ASS
56
x
P2020P1C SCREW (
x
4)
57 DG3151000 PUSH LEVER ASSY
58 DG3058000 FFC GUIDE
59 DG4116010 SHEET (FRONT BK
60 DG1140014 PANEL (BUTTON)
61 DG2141021 BUTTON (FUNC)
62 DG2142020 BUTTON (PRESET)
63 DG1139000 BUTTON BASE
64 DG4026030 PLATE SPRING LV41825-004A
65 YM1701004 MINI SCREW VKZ4777-004(
x
6)
66 DG1122022 DISPLAY PANEL
67 DG4130000 SPACER (UP DOWN LV40846-005A
68 DG4136000 SPACER E
69 DG3102020 FINDER ASSY
70 DG4125000 SPACER (P) LV40848-009A
71 DG4061021 UP DOWN BUTTON
72 DG3255000 KNOB VOL ASSY
73 DG4104000 ENCODER GUIDE
74 DG3148000 ENCODER PLATE
75 DG3126020 KNOB SPRING
76 YM1701001 MINI SCREW VKZ4777-001(
x
4)
77 DG3024000 BUTTON BASE BKT
78 DG4071020 BUTTON B SUPORT
79 YM2029000 SCREW (
x
3)
80 DG4029010 TENS SPRING BTM LV41452-003A(
x
2)
81
x
P1728P3B SCREW (
x
4)
82 YM2029000 SCREW (
x
4)
83
x
T2640BSC SCREW (
x
8)
84 YM2626002 SCREW (
x
4)
85 YM2626000 SCREW
86 DG3008000 SIDE HEAT SINK
87
x
T26A0BPC SCREW
88 DG4115000 SHEET (
x
2)
89 PLN128800 NAME LABEL
90 PLC013500 LASER CAUTION LV41843-001A
91 DG4087040 LEVER SPRING
