JVC KD-R691

SERVICE MANUAL
COPYRIGHT © 2017 JVC KENWOOD Corporation
No.MA665<Rev.001>
2017/9
CD RECEIVER
MA665<Rev.001>20179SERVICE MANUAL
KD-R491, KD-R491M, KD-R496,
KD-R498, KD-R691
COPYRIGHT © 2017 JVC KENWOOD Corporation
Lead free solder used in the board (material: Sn-Ag-Cu, melting point: 219 Centigrade)
Lead free solder used in the board (material: Sn-Cu, melting point: 230 Centigrade)
DETACHABLE PANEL
Mounting sleeve
(GE20362-002A)
DC cord
(E3A-0322-00)
DC cord
(E3A-0323-00)
Escutcheon
(B0H-0015-10)
Hook
(GE40685-001A) x2
Model Parts number
KD-R491 (E0)
KD-R491 (M1)
KD-R491M
KD-R496
KD-R498
KD-R691
CP-YJ1116E00N
CP-YJ1116M01N
CP-YJ1116M02N
CP-YJ1116M04N
CP-YJ1116M03N
CP-YJ1116E01N
Carrying case
(GE40521-001A)
KD-R491 (Europe) : E0
KD-R491 (Other Areas) : M1
Remote ctl (IR)
(A7A-0018-00)
