(No.MA665<Rev.001>)8/33
32 ENC1 I Volume Encoder Pulse Input 1
33 REMO I Remocon Input L (Pulse): Remote control data / H:
Standby
34 STAT I DSP Status Signal
35 SW1 I CD Mecha SW1
35 DEBUG_2A O For Debug
36 PVcc - Power supply for I/O circuits
37 NC O No Use
38 Vss - GND
39 RESET I Reset Input
40 Vss - GND
41 PLLVcc - Power supply for PLL
42 PAN_DET I Panel Detection input L: Panel Attached / H: Panel De-
tached
42 NC I No Use (for non detachable model)
43 Vcc - Power supply
44 EXTAL I High Speed Clock 12MHz
45 XTAL O High Speed Clock 12MHz
46 Vss - GND
47 Vss - GND
48 PVcc - Power supply for I/O circuits
49 D-0 I/O USB Data- 0
50 D+0 I/O USB Data+ 0
51 ASEMD I ASE Mode Select Pin
52 PSW I CD Mecha Position Setting SW (Reset Switch)
53 NC I No Use (for non BT model)
54 STAGE2 I Model Selecting Input 2 Refer to respective spec
54 STEERING_REMO2 I OE Remote In 2 (for DOP models)
55 STAGE1 I Model Selecting Input 1 Refer to respective spec
55 STEERING_REMO1 I OE Remote In 1 (for DOP models)
56 TEL_MUTE I Tel Mute Detection Input (for JVC Model) Refer to respective spec
56 LINE_MUTE I Line Mute Detection Input (For KWD Model) Refer to respective spec
56 NC I No Use (for non support Tel mute model)
57 DC_ERR1 I Detect DC Offset Error from EVOL IC L: DC Error ON / H: DC Error OFF
58 Avss - GND
59 Avcc - Power Supply
60 Avref - Reference Power Supply
61 TRST I Debugging Interface. Reset Input.
62 ASEBRKAK/ASEBRK I/O Emulator Break Mode Acknoledge/Break Input
63 TDO O Debugging Interface. Serial Output for Instructions and
Data
64 TDI I Debugging Interface. Serial Input for Instructions and
Data
65 TMS I Debugging Interface. Test Mode Select Signal Input.
66 TCK I Debugging Interface. Test Clock Input.
67 NC O No Use
68 NC I No Use
69 PVcc - Power supply for I/O circuits
70 SPBCLK O FLASH SPI Multi I/O Bus Clock output
71 Vss - GND
Pin No. Pin Name I/O Application
Processing/Operation/Descrip-
tion
