4.3 Service Test Mode
Pressing and holding [DISP] key, then press [] key for 7 seconds.
(Starting to press [DISP] key and [] key at the same time can not be entered into the mode)
4.3.1 Default status immediately after the mode activation
It shall be same as the normal activation.
4.3.2 Mode content
Syscon shall display the following information after entering this mode.
4.3.3 Common operation mode for only STANDBY sources
*1 This includes all media (CD, USB, iPod, SD) action duration.
Display content Details
Display is released when an operation is executed.
RSVT TES
Item Operation Display content Details
Syscom version
display
5
## = File Number
@@@ = Syscon Version Number
Power ON
duration display
2
00 to 50 are displayed in "XX".
For less than 1 hour, the display is indicated per 10
minutes.
00001 to 10922 are displayed in "XXXXX".
MAX=10922 (hours)
Disc action
duration display
1 (*1)
00 to 50 are displayed in "XX".
For less than 1 hour, the display is indicated per 10
minutes.
00001 to 10922 are displayed in "XXXXX".
MAX=10922 (hours)
Disc Eject No. of
times
DISP
00001 to 99999 are displayed in "XXXXX"
Disc Eject No. of
times clear
DISP
Clear Disc Eject number of times by pressing for 2
seconds when it is displayed.
Y–SS##@@@
OPNTM HX0X
OPNTM XXxXX
DCTM HX0X
DCTM XXXXX
JECNT XXXXX
JECNT 0 0000
