JVC KD-R691 Schematic Diagrams

(No.MA665<Rev.001>)26/33
4.7.2 ERROR CODE for MODEL with FLM-HCI MECHA (Ver1.1)
4.8 Tuner Span Change Mode
Pressing and holding [VOLUME] key, then press [RETURN] key for 3 seconds.
4.8.1 Default status immediately after the mode activation
It shall be same as normal activation.
After selection of the setting item, the receiver should exit this mode and return to the display before entering this mode.
This setting will be stored in EEPROM.
4.8.2 Mode content
Syscon shall display the following information after entering this mode.
*1: Only applicable for Asia ('U') models
*2: Only applicable for Europe ('E') models
*3: Only applicable for Australia ('X') models
DISPLAY SIGN ERROR Item Condition Details
LI-E LOADING TIME OVER
In LOAD operating. Anomaly detection of SW state at LOADING.
Or 5 sec TIME OVER from LOAD start.
EJ-E EJECT TIME OVER
In EJECT operating. Anomaly detection of SW state at EJECT.
Or 5 sec TIME OVER from EJECT start.
E-04 READ ERROR In RUNNING MODE operating TOC read error.
E-14 FOCUS ERROR In RUNNING MODE operating Focus Error. No complete Focus ON.
E-05 UNKNOWN DISC In RUNNING MODE operating No reflection.
E-20 NODISC ERROR In RUNNING MODE operating In case of DISC distinction.
E-21 DSP ACCESS ERROR In RUNNING MODE operating fails in the access to DSP.
E-22 LIM SW ERROR In RUNNING MODE operating Time over in case of that moves to an inner side.
AE-01
AUTO ADJUSTMENT
ERROR
In RUNNING MODE operating Focus Gain Error
AE-02 In RUNNING MODE operating Tracking Gain Error
AE-03 In RUNNING MODE operating RF Gain Error
AE-04 In RUNNING MODE operating Tracking Balance Error
AE-05 In RUNNING MODE operating Focus Balance Error
AE-06 In RUNNING MODE operating Focus Offset Error
AE-07 In RUNNING MODE operating Tracking Offset Error
AE-08 In RUNNING MODE operating RF Offset Error
Item Operation Display content Details
Tuner Span
Change Mode (*1)
VOLUME
+/-
default span is for Asia area
* - use Tunisia as based frequecy (AM) and tuner pa-
rameter still follow Asia.
Change to 'Asia' Span type.
Change to 'Australia' area type.
Change to 'US' area type.
Tuner Span
Change Mode (*2)
VOLUME
+/-
Default setting for Europe models.
Change to 'Europe' area type.
Turkish language setting will be hiding in setup menu
Change to 'Tunisia' area type.
Default language change to Turkish
Turkish language setting is available in setup menu
Tuner Span
Change Mode (*3)
VOLUME
+/-
Change to 'Australia' area type.
Change to 'Asia' Span type.
Change to 'US' area type.
Release Mode VOLUME
Depending on display pattern in normal mode.
AS I A
AS I A GENERAL
AUS
OTHERS
EUROPE
M.EAST
AREA TURKE Y
AUS
AS I A GENERAL
OTHERS
