ENGLISH
17
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
SUB.W LEVEL
*
4
SPK-OUT
*
5
(Not applicable when 3-way crossover is selected.)
00
to
+06
(
+03
):Adjusts the output level of the
subwoofer connected via speaker lead. (
29
)
PRE-OUT
*
6
–50
to
+10
(
00
):Adjusts the output level of the
subwoofer connected to the lineout terminals (SW or
REAR/SW) through an external amplifier. (
29
)
SUB.W
*
6
ON
/
OFF
: Turns on or off the subwoofer output.
FADER
(Not applicable when 3-way crossover is selected.)
R15
—
F15
(
00
):Adjusts the front and rear speaker output balance.
BALANCE
*
7
L15
—
R15
(
00
):Adjusts the left and right speaker output balance.
VOL
ADJUST –15
—
+06
(
00
):Preset the initial volume level of each source
(compared to the FM volume level). Before adjustment, select the source
you want to adjust.
AMP
GAIN LOW
POWER
:Limits the maximum volume level to 25. (Select if the
maximum power of each speaker is less than 50W to prevent damaging
the speakers.);
HIGHPOWER
:The maximum volume level is 35.
SPK/PRE
OUT
(Not applicable when 3-way crossover is selected.)
Depending on the speaker connection method, select the appropriate
setting to get the desired output. (
Speaker output settings
)
SPK SIZE
Depending on the crossover type you have selected (see [
X ' OVER TYPE
]
below), 2-way crossover or 3-way crossover setting items will be shown.
(
18, Crossover settings)
By default, 2-way crossover type is selected.
X ' OVER
X ' OVER TYPE Caution
: Adjust the volume before changing the
X ' OVER TYPE
to
avoid the sudden increase or decrease of the output level.
X ' OVER 2-WAY
(Displayed only when [
X ' OVER 3-WAY
] is selected)
YES
:Selects two way crossover type.;
NO
:Cancels.
X ' OVER 3-WAY
(Displayed only when [
X ' OVER 2-WAY
] is selected)
YES
:Selects three way crossover type.;
NO
:Cancels.
AUDIO SETTINGS
SND EFFECT
ENHANCE
(Not applicable for TUNER source.)
SML/ MED/ LRG
: Virtually enhances the sound space.;
OFF
:Cancels.
RESPONSE LV1
/
LV2
/
LV3
: Virtually makes the sound more realistic.;
OFF
:Cancels.
SOUND LIFT LV1
/
LV2
/
LV3
: Virtually adjust the sound position heard from the
speakers.;
OFF
:Cancels.
VOL LINK EQ ON
:Boosts the frequency to reduce the noise heard from outside the car
or running noise of the tyres.;
OFF
:Cancels.
K2
(Not applicable for TUNER source and AUX source.)
ON
:Improve the sound quality of compressed music.;
OFF
:Cancels.
*
4
Displayed only when [
SUB.W
] is set to [
ON
].
*
5
For 2-way crossover: Displayed only when [
SPK/PRE
OUT
] is set to [
SUB.W/SUB.W
].
(
17
,
18
)
*
6
For 2-way crossover: Displayed only when [
SPK/PRE
OUT
] is set to [
REAR/SUB.W
] or
[
SUB.W/SUB.W
]. (
17
,
18
)
*
7
This adjustment will not affect the subwoofer output.
Speaker output settings
(Only for
X ' OVER 2-WAY
)
Select the output setting for the speakers [
SPK/PRE OUT
], base on the
speaker connection method.
Connection via lineout terminals
For connections through an external amplifier. (
29
)
(For
KD-R971BT
)
Setting on
[
SPK/PRE OUT]
Audio signal through lineout terminal
FRONT REAR SW
REAR/REAR
(default)
Front speakers output Rear speakers output Subwoofer output
REAR/SUB.W
( Not available ) ( Not available ) ( Not available )
SUB.W/SUB.W
Front speakers output L (left): Subwoofer output
R (right): (Mute)
Subwoofer output
JS_JVC_KD_R971BT_M_EN_7_f.indd 17JS_JVC_KD_R971BT_M_EN_7_f.indd 17 15/10/2015 2:57:44 PM15/10/2015 2:57:44 PM
