JVC KD-R771BT

ﻲﺑﺮﻋ
19
ﻦﻴﺗﺎﻨﻘﺑ ﺔﻳﺪﻌﺗ ﺩﺍﺪﻋﻹﺍ ﺩﻮﻨﺑ
SPK SIZE
FRONTSIZE
/ 17CM / 16CM / 13CM / 12CM / 10CM / 8CM
7×10"
/ 6×9" / 6×8" / 5×7" / 4×6" / 18CM
TWEETER
(ﻝﻮﺻﻮﻣ ﺮﻴﻏ) NONE / LRG / MID / SML
REAR
*
1
/ 4×6" / 18CM / 17CM / 16CM / 13CM / 12CM / 10CM / 8CM
(ﻝﻮﺻﻮﻣ ﺮﻴﻏ) NONE / 7×10" / 6×9" / 6×8" / 5×7"
SUBWOOFER
*
2
*
3
(ﻝﻮﺻﻮﻣ ﺮﻴﻏ) NONE / 38CM OVER / 30CM / 25CM / 20CM / 16CM
X ' OVER
TWEETERFRQ
/ 5KHZ / 4KHZ / 2.5KHZ / 1.6KHZ / 1KHZ
12.5KHZ
/ 10KHZ / 8KHZ / 6.3KHZ
GAIN LEFT
00DB ﻰﻟﺇ –08DB ﻦﻣ
GAIN RIGHT
00DB ﻰﻟﺇ –08DB ﻦﻣ
FRONT HPFFRQ
/ 80HZ / 70HZ / 60HZ / 50HZ / 40HZ / 30HZ
/ 180HZ / 150HZ / 120HZ / 100HZ / 90HZ
THROUGH
/ 250HZ / 220HZ
SLOPE
–24DB / –18DB / –12DB / –06DB
GAIN
00DB ﻰﻟﺇ –08DB ﻦﻣ
REAR HPF
*
1
FRQ
/ 80HZ / 70HZ / 60HZ / 50HZ / 40HZ / 30HZ
/ 180HZ / 150HZ / 120HZ / 100HZ / 90HZ
THROUGH
/ 250HZ / 220HZ
SLOPE
–24DB / –18DB / –12DB / –06DB
GAIN
00DB ﻰﻟﺇ –08DB ﻦﻣ
SUB.W LPF
*
2
*
3
FRQ
/ 80HZ / 70HZ / 60HZ / 50HZ / 40HZ / 30HZ
/ 180HZ / 150HZ / 120HZ / 100HZ / 90HZ
THROUGH
/ 250HZ / 220HZ
SLOPE
–24DB / –18DB / –12DB / –06DB
PHASE
(0°) NORMAL /(180°) REVERSE
GAIN
00DB ﻰﻟﺇ –08DB ﻦﻣ
ﺕﻮﺼﻟﺍ ﺕﺍﺩﺍﺪﻋﺇ
ﺕﺍﻮﻨﻗ 3 ﺔﻳﺪﻌﺑ ﺩﺍﺪﻋﻹﺍ ﺩﻮﻨﺑ
SPK SIZE
TWEETER
LRG / MID / SML
MID RANGE
/6×8" /5×7" /4×6" /18CM /17CM /16CM /13CM /12CM /10CM /8CM
6×9"
WOOFER
*
3
(ﻝﻮﺻﻮﻣ ﺮﻴﻏ) NONE / 38CM OVER / 30CM / 25CM / 20CM / 16CM
X ' OVER
TWEETERHPF FRQ
/ 6.3KHZ / 5KHZ / 4KHZ / 2.5KHZ / 1.6KHZ / 1KHZ
12.5KHZ
/ 10KHZ / 8KHZ
SLOPE
–12DB / –06DB
PHASE
(0°) NORMAL /(180°) REVERSE
GAIN
00DB ﻰﻟﺇ –08DB ﻦﻣ
MID RANGEHPF FRQ
/ 90HZ / 80HZ / 70HZ / 60HZ / 50HZ / 40HZ / 30HZ
/ 250HZ / 220HZ / 180HZ / 150HZ / 120HZ / 100HZ
THROUGH
HPF SLOPE
–12DB / –06DB
LPF FRQ
/ 6.3KHZ / 5KHZ / 4KHZ / 2.5KHZ / 1.6KHZ / 1KHZ
THROUGH
/ 12.5KHZ / 10KHZ / 8KHZ
LPF SLOPE
–12DB / –06DB
PHASE
(0°) NORMAL /(180°) REVERSE
GAIN
00DB ﻰﻟﺇ –08DB ﻦﻣ
WOOFER
*
3
LPF FRQ
/90HZ /80HZ /70HZ /60HZ /50HZ /40HZ /30HZ
/250HZ /220HZ /180HZ /150HZ /120HZ /100HZ
THROUGH
SLOPE
–12DB / –06DB
PHASE
(0°) NORMAL /(180°) REVERSE
GAIN
00DB ﻰﻟﺇ –08DB ﻦﻣ
ﻭﺃ [
REAR/REAR ] ﺮﻔﻳﻮﻟﺍ ﻰﻠﻋ ﻁﻮﺒﻀﻣ [ SPK/PRE OUT ] ﻊﺿﻮﻟﺍ ﻥﻮﻜﻳ ﺎﻣﺪﻨﻋ ﻂﻘﻓ ﺽﺮﻌﻳ
*
1
( 18 ، 17 ) .[ REAR/SUB.W ]
ﻰﻠﻋ ﻁﻮﺒﻀﻣ [
SPK/PRE OUT ] ﻊﺿﻮﻟﺍ ﻥﻮﻜﻳ ﺎﻣﺪﻨﻋ ﻂﻘﻓ ﺽﺮﻌﻳ : KD-R771BT ﻲﻠﻳﺩﻮﻤﻟ
*
2
( 18 ، 17 ) .[ SUB.W/SUB.W ] ﻭﺃ [ REAR/SUB.W ] ﺮﻔﻳﻮﻟﺍ
( 17 ) .[ ON ] ﺮﻔﻳﻮﻟﺍ ﻰﻠﻋ ﻁﻮﺒﻀﻣ [ SUB.W ] ﻊﺿﻮﻟﺍ ﻥﻮﻜﻳ ﺎﻣﺪﻨﻋ ﻂﻘﻓ ﺽﺮﻌﻳ
*
3
