ENGLISH
20
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
AUDIO SETTINGS
Crossover settings
Below are the available setting items for 2-way crossover and 3-way crossover.
Caution
Select a crossover type according to how the speakers are connected.
( 31)
If you select a wrong type:
• The speakers may damage.
• The output sound level may be extremely high or low.
SPEAKER SIZE
Selects according to the connected speaker size for optimum performance.
•
The frequency and slope settings are automatically set for the crossover of the
selected speaker.
•
When 2-way crossover is selected, if
[NONE]
is selected for
[TWEETER]
of
[FRONT]
,
[REAR]
and
[SUBWOOFER]
for
[SPEAKER SIZE]
, the
[X ‘ OVER]
setting of the selected
speaker is not available.
•
When 3-way crossover is selected, if
[NONE]
is selected for
[WOOFER]
of
[SPEAKER SIZE]
,
the
[X ‘ OVER]
setting of
[WOOFER]
is not available.
X ‘ OVER
(crossover)
• [FRQ]
/
[F-HPF FRQ]
/
[R-HPF FRQ]
/
[SW LPF FRQ]
/
[HPF FRQ]
/
[LPF FRQ]
: Adjusts the crossover
frequency for the selected speakers (high pass filter or low pass filter).
If
[THROUGH]
is selected, all signals are sent to the selected speakers.
• [SLOPE]
/
[F-HPF SLOPE]
/
[R-HPF SLOPE]
/
[SW LPF SLOPE]
/
[HPF SLOPE]
/
[LPF SLOPE]:
Adjusts the
crossover slope.
Selectable only if a setting other than
[THROUGH]
is selected for the crossover
frequency.
• [SW LPF PHASE]
/
[PHASE]:
Selects the phase of the speaker output to be in line with
the other speaker output.
•
[GAIN LEFT]
/
[GAIN RIGHT]
/
[F-HPF GAIN]
/
[R-HPF GAIN]
/
[SW LPF GAIN]
/
[GAIN]
:
Adjusts the
output volume of the selected speaker.
Connection via speaker leads
For connections without using an external amplifier. However,
with this settings you can also enjoy the subwoofer output.
( 31)
Setting on
[SPK/PRE OUT]
Audio signal through rear speaker lead
L (left) R (right)
REAR/REAR
Rear speakers output Rear speakers output
REAR/SUB.W
Rear speakers output Rear speakers output
SUB.W/SUB.W
Subwoofer output (Mute)
If
[SUB.W/SUB.W]
is selected:
–
[120HZ]
is selected in
[SUBWOOFER LPF]
and
[THROUGH]
is not
available.
–
[POSITION R02]
is selected in
[FADER]
and selectable range is
[POSITION R15]
to
[POSITION 00]
.
JS_JVC_KD_R881BT_M_EN_4.indd 20JS_JVC_KD_R881BT_M_EN_4.indd 20 18/8/2016 9:53:04 AM18/8/2016 9:53:04 AM
