JVC KD-R810

31ENGLISH
Category Menu item Selectable setting, [ Initial: Underlined ]
Audio
Subwoofer • LPF
• Level
• Phase
: Turn the control dial to select the cutoff
frequency to the subwoofer.
Off: All signals are sent to the subwoofer.
LPF 55Hz/LPF 85Hz/LPF 120Hz: Frequencies
higher than 55 Hz/85 Hz/120 Hz are cut off.
: Turn the control dial to adjust the subwoofer
output level. Level 00 to Level 08 [ Level 04 ]
: Turn the control dial to select the subwoofer
phase. 0 Deg (normal) or 180 Deg (reverse)
HPF
High Pass Filter
Select the cutoff frequency to the front/rear speakers. Set this to
match the LPF settings.
• 62Hz/95Hz/
135Hz
• Off
: Frequencies lower than 62 Hz/95 Hz/135 Hz are
cut off.
: All signals are sent to the front/rear speakers.
Beep
Keytouch tone
• On
• Off
: Activates the keypress tone.
: Deactivates the keypress tone.
Amplifier
Gain *
6
• High Power
• Low Power
• Off *
7
: Vol 00 – Vol 50
: Vol 00 – Vol 30 (Select if the maximum power
of each speaker is less than 50 W to prevent
damaging the speakers.)
: Deactivates the built-in amplifier.
Display
Dimmer • Auto
• On
• Time Set
• Off
: Dims the display when you turn on the
headlights. *
8
: Dims the display and button illumination.
: Set the timer for dimmer. ( 35)
: Cancels.
Level Meter • Meter 1
• Meter 2
: Selects the different level meter patterns. (
7)
• Press
DISP to show the selected level meter.
Scroll *
9,
*
10
• Once
• Auto
• Off
: Scrolls the displayed information once.
: Repeats scrolling (at 5-second intervals).
: Cancels.
Pressing
DISP for more than one second can scroll the display
regardless of the setting.
*
6
The volume level automatically changes to “Vol 30” if you change to <Low Power> with the volume
level set higher than “Vol 30.”
*
7
Only for KD-A815.
*
8
The illumination control lead connection is required. (See “Installation/Connection Manual.”)
*
9
Some characters or symbols will not be shown correctly (or will be blanked) on the display.
*
10
Not applicable to HD Radio text scrolling.
