AUDIO SETTINGS
SND EFFECT
ENHANCE
(Not applicable for TUNER source.)
SML/ MED/ LRG : Virtually enhances the sound space.; OFF :Cancels.
RESPONSE LV1 / LV2 / LV3 : Virtually makes the sound more realistic.; OFF :Cancels.
SOUND LIFT LV1 / LV2 / LV3 : Virtually adjust the sound position heard from the
speakers.;
OFF :Cancels.
VOL LINK EQ ON :Boosts the frequency to reduce the noice heard from outside the car
or running noise of the tyres.;
OFF :Cancels.
K2 (Not applicable for TUNER source, SIRIUS XM source, AUX source.)
ON :Improve the sound quality of compressed music.; OFF :Cancels.
Speaker output settings
(Only for X ' OVER 2-WAY )
Select the output setting for the speakers [ SPK/PRE OUT], base on the
speaker connection method.
Connection via lineout terminals
For connections through an external amplifier. (  34, 35 )
(For KD-R975BTS / KD-R97MBS / KD-R875BTS )
Setting on
[ SPK/PRE OUT]
Audio signal through lineout terminal
FRONT REAR SW
REAR/REAR
(default)
Front speakers
output
Rear speakers output Subwoofer output
REAR/SUB.W ( Not available ) ( Not available ) ( Not available )
SUB.W/SUB.W Front speakers
output
L (left): Subwoofer output
R (right): (Mute)
Subwoofer output
(For
KD-R970BTS / KD-R870BT / KD-RD97BT / KD-RD87BT )
Setting on
[ SPK/PRE OUT]
Audio signal through lineout terminal
FRONT REAR/SW
REAR/REAR Front speakers output Rear speakers output
REAR/SUB.W (default) Front speakers output Subwoofer output
SUB.W/SUB.W Front speakers output Subwoofer output
(For
KD-R770BT )
Setting on
[ SPK/PRE OUT]
Audio signal through lineout terminal
REAR/SW
REAR/REAR Rear speakers output
REAR/SUB.W (default) Subwoofer output
SUB.W/SUB.W Subwoofer output
Connection via speaker leads
For connections without using an external amplifier. However, with this
settings you can also enjoy the subwoofer output.
(  34, 35 )
Setting on
[ SPK/PRE OUT]
Audio signal through rear speaker lead
L (left) R (right)
REAR/REAR Rear speakers output Rear speakers output
REAR/SUB.W Rear speakers output Rear speakers output
SUB.W/SUB.W Subwoofer output (Mute)
If [ SUB.W/SUB.W ] is selected:
– [
FRQ120HZ ] is selected in [ SUB.W  LPF ] and [ THROUGH ] is not available.
– [
R02 ] is selected in [ FADER ] and selectable range is [ R15 ]to [ 00 ].
