JVC KD-R981BT User Manual

ENGLISH
16
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Bluetooth mode settings
1
Press and hold .
2 KD-R981BT / KD-R784BT / KD-R782BT : Turn the volume knob to select an item
( see the following table ) , then press the
knob.
KD-R889BT / KD-R881BT : Press to select an item ( see the
following table
) , then press .
3 Repeat step 2 until the desired item is selected/activated or follow the
instructions stated on the selected item.
4 Press to exit.
To return to the previous setting item, press .
Default:
XX
BT MODE
PHONE SELECT
* Selects the phone or audio device to connect or disconnect.
“
” appears in front of the device name when connected.
“
” appears in front of the current playback audio device.
AUDIO SELECT *
DEVICE DELETE KD-R981BT / KD-R784BT / KD-R782BT :
1 Turn the volume knob to select a device to delete, then press the knob.
2 Turn the volume knob to select [YES] or [NO] , then press the knob.
KD-R889BT / KD-R881BT :
1 Press to select a device to delete, then press .
2 Press to select [YES] or [NO] , then press .
PIN CODE EDIT
(0000)
Changes the PIN code (up to 6 digits).
1 Turn the volume knob (for KD-R981BT / KD-R784BT / KD-R782BT ) or press
(for KD-R889BT / KD-R881BT ) to select a number.
2 Press to move the entry position.
Repeat steps
1 and 2 until you finish entering the PIN code.
3 Press the volume knob (for KD-R981BT / KD-R784BT / KD-R782BT ) or
(for KD-R889BT / KD-R881BT ) to confirm.
RECONNECT ON :The unit automatically reconnect when the last connected Bluetooth
device is within range.;
OFF :Cancels.
AUTO PAIRING ON :The unit automatically pair supported Bluetooth device
(iPhone/iPod touch/Android device) when it is connected
through USB input terminal.Depending on the operating
system of the connected device, this function may not work. ;
OFF :Cancels.
INITIALIZE YES :Initializes all the Bluetooth settings (including stored
pairing, phonebook, and etc.).;
NO :Cancels.
INFORMATION MY  BT  NAME : Displays the unit name (“KD-R9 BT”/
“KD-R8
BT”/“KD-R7 BT”).;
MY  ADDRESS : Shows address of this unit.
* You can only connect a maximum of two Bluetooth phones and one Bluetooth audio
device at any time.
Bluetooth compatibility check mode
You can check the connectivity of the supported profile between
the Bluetooth device and the unit.
• Make sure there is no Bluetooth device paired.
1 Press and hold .
“BLUETOOTH”
“CHECK MODE” appears. “SEARCH NOW
USING PHONE”
“PIN IS 0000” scrolls on the display.
2 Search and select “KD-R9 BT”/“KD-R8 BT”/“KD-R7 BT”
on the Bluetooth device within 3minutes.
3 Perform (A), (B) or (C) depending on what appears on the
display.
(A) “PAIRING”
“XXXXXX” (6-digit passkey): Ensure that the
same passkey appears on the unit and Bluetooth device, then
operate the Bluetooth device to confirm the passkey.
(B) “PAIRING”
“PIN IS 0000”: Enter “0000” on the Bluetooth
device.
(C) “PAIRING”: Operate the Bluetooth device to confirm pairing.
BLUETOOTH®
JS_JVC_KD_R981_E_EN_5.indd 16JS_JVC_KD_R981_E_EN_5.indd 16 9/1/2016 2:06:39 PM9/1/2016 2:06:39 PM

JVC KD-R981BT Specifications

General

MP3 playback	Yes
Audio formats supported	FLAC, MP3, WAV, WMA
DIN size	1 DIN
Output power	200 W
Product color	Black
Disc types supported	CD
Audio output channels	2.1 channels
Maximum power per channel	50 W
AM band range	531 - 1611 kHz
FM band range	87.5 - 108 MHz
LW band range	153 - 279 kHz
Preset stations quantity	24
Display number of lines	2 lines
USB version	2.0
USB port position	Front
Bluetooth profiles	A2DP, AVRCP, HFP, PBAP
Line outputs (RCA)	3
USB ports quantity	1
Headphone connectivity	3.5mm
Output voltage	4 V

Weight and Dimensions

Weight	1400 g
Dimensions (WxDxH)	182 x 53 x 159 mm
