3-11
Main board (KD-S31_J2)
Block No. [0][3]
CJ601 QGZ1601K1-15S CONNECTOR (1-15)
S601 NSW0124-001X TACT SW
S602 NSW0124-001X TACT SW
S603 NSW0124-001X TACT SW
S604 NSW0124-001X TACT SW
S605 NSW0124-001X TACT SW
S606 NSW0124-001X TACT SW
S607 NSW0124-001X TACT SW
S608 NSW0124-001X TACT SW
S609 NSW0124-001X TACT SW
S610 NSW0124-001X TACT SW
S611 NSW0124-001X TACT SW
S612 NSW0124-001X TACT SW
S613 NSW0124-001X TACT SW
S614 NSW0124-001X TACT SW
S615 NSW0124-001X TACT SW
S616 NSW0124-001X TACT SW
S617 NSW0124-001X TACT SW
S618 NSW0124-001X TACT SW
Symbol No.
Part No. Part Name Description Local
IC161 TEA6320T-X IC
IC301 LA47516 POWER IC
IC501 AN41012A-W CD BTL DRIVER
IC521 MN6627945ECUC IC
IC523 SN74LVC07ANS-X LOGIC BOFFER
IC581 NJM4565M-WE IC
IC701 LC723784-9C90 IC
IC801 HD74HC126FP-X IC
IC901 AN80T71 REGULATOR IC
IC981 NJU7772F15-X IC
Q1 UN2211-X TRANSISTOR
Q2 UN2211-X TRANSISTOR
Q4 UN2211-X TRANSISTOR
Q5 2SB1197K/QR/-X TRANSISTOR
Q6 2SB709A/QR/-X TRANSISTOR
Q31 2SD601A/QR/-X TRANSISTOR
Q32 2SD601A/QR/-X TRANSISTOR
Q301 2SD601A/QR/-X TRANSISTOR
Q341 KTD1304-X TRANSISTOR
Q351 KTD1304-X TRANSISTOR
Q501 2SB1322/RS/-T TRANSISTOR
Q521 2SB709A/QR/-X TRANSISTOR
Q781 UN2111-X TRANSISTOR
Q782 UN2111-X TRANSISTOR
Q902 2SD601A/QR/-X TRANSISTOR
Q903 2SB709A/QR/-X TRANSISTOR
D1 MA111-X SI DIODE
D2 MA111-X SI DIODE
D3 MA111-X SI DIODE
D4 MA111-X SI DIODE
D301 UDZS3.3B-X Z DIODE
D341 MA111-X SI DIODE
D351 MA111-X SI DIODE
D501 1A3G-T1 SI DIODE
D702 MA111-X SI DIODE
D703 MA111-X SI DIODE
D706 MA111-X SI DIODE
D711 MA8062/M/-X Z DIODE
D712 MA8062/M/-X Z DIODE
D713 MA8062/M/-X Z DIODE
D714 MA8062/M/-X Z DIODE
D715 MA8062/M/-X Z DIODE
D716 MA8062/M/-X Z DIODE
D717 MA8062/M/-X Z DIODE
D718 MA8062/M/-X Z DIODE
D719 MA8062/M/-X Z DIODE
Symbol No.
Part No. Part Name Description Local
D720 MA8062/M/-X Z DIODE
D721 MA8062/M/-X Z DIODE
D781 MA111-X SI DIODE
D782 MA8110/M/-X Z DIODE
D901 1N5401-F64 DIODE
D903 MA111-X SI DIODE
D904 RB160M-30-X SB DIODE
D905 RB160M-30-X SB DIODE
C1 NDC31HJ-221X C CAPACITOR 220pF 50V J
C2 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C3 QEKJ1HM-104Z E CAPACITOR 0.1uF 50V M
C4 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C6 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7 QEKJ1HM-104Z E CAPACITOR 0.1uF 50V M
C8 NDC31HJ-121X C CAPACITOR 120pF 50V J
C9 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C10 QEKJ1HM-104Z E CAPACITOR 0.1uF 50V M
C11 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C31 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C32 NCB31HK-102X C CAPACITOR 1000pF 50V K
C33 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C81 NCB31EK-273X C CAPACITOR 0.027uF 25V K
C82 NCB31HK-682X C CAPACITOR 6800pF 50V K
C83 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C91 NCB31EK-273X C CAPACITOR 0.027uF 25V K
C92 NCB31HK-682X C CAPACITOR 6800pF 50V K
C93 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C96 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C99 NCB31HK-102X C CAPACITOR 1000pF 50V K
C161 NCB31HK-822X C CAPACITOR 8200pF 50V K
C162 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C163 NCB21CK-224X C CAPACITOR 0.22uF 16V K
C164 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C165 NCB31HK-562X C CAPACITOR 5600pF 50V K
C166 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C167 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C168 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C169 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C171 NCB31HK-822X C CAPACITOR 8200pF 50V K
C172 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C173 NCB21CK-224X C CAPACITOR 0.22uF 16V K
C174 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C175 NCB31HK-562X C CAPACITOR 5600pF 50V K
C176 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C177 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C178 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C179 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C181 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C182 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C183 QTE1H54-225Z E CAPACITOR 2.2uF 50V
C184 QTE1H54-225Z E CAPACITOR 2.2uF 50V
C191 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C192 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C193 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C194 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C301 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C302 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C303 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C304 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C305 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C306 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C307 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C308 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C309 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
C310 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C311 QERF1CM-226Z E CAPACITOR 22uF 16V M
C312 NDC31HJ-101X C CAPACITOR 100pF 50V J
C313 NDC31HJ-101X C CAPACITOR 100pF 50V J
C314 NDC31HJ-101X C CAPACITOR 100pF 50V J
C315 NDC31HJ-101X C CAPACITOR 100pF 50V J
C317 QERF1HM-105Z E CAPACITOR 1uF 50V M
C318 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C319 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C341 NDC31HJ-101X C CAPACITOR 100pF 50V J
C351 NDC31HJ-101X C CAPACITOR 100pF 50V J
C501 QEKJ0JM-227Z E CAPACITOR 220uF 6.3V M
C502 NCB31EK-104X C CAPACITOR 0.1uF 25V K
Symbol No.
Part No. Part Name Description Local
