JVC KD-S31 Service Manual

3-13
Switch board (KD-S31_J2)
Block No. [0][4]
R521 NRSA63J-105X MG RESISTOR 1M$ 1/16W J
R522 NRSA63J-221X MG RESISTOR 220$ 1/16W J
R523 NRSA63J-472X MG RESISTOR 4.7k$ 1/16W J
R524 NRSA63J-222X MG RESISTOR 2.2k$ 1/16W J
R525 NRSA63J-102X MG RESISTOR 1k$ 1/16W J
R526 NRSA63J-102X MG RESISTOR 1k$ 1/16W J
R527 NRSA63J-222X MG RESISTOR 2.2k$ 1/16W J
R528 NRSA63J-222X MG RESISTOR 2.2k$ 1/16W J
R529 NRSA63J-222X MG RESISTOR 2.2k$ 1/16W J
R530 NRSA02J-472X MG RESISTOR 4.7k$ 1/10W J
R531 NRSA02J-472X MG RESISTOR 4.7k$ 1/10W J
R532 NRSA02J-472X MG RESISTOR 4.7k$ 1/10W J
R533 NRSA63J-273X MG RESISTOR 27k$ 1/16W J
R534 NRSA63J-683X MG RESISTOR 68k$ 1/16W J
R535 NRSA02J-103X MG RESISTOR 10k$ 1/10W J
R537 NRSA63J-155X MG RESISTOR 1.5M$ 1/16W J
R538 NRS181J-0R0X MG RESISTOR 0$ 1/8W J
R539 NRS181J-0R0X MG RESISTOR 0$ 1/8W J
R540 NRSA63J-333X MG RESISTOR 33k$ 1/16W J
R541 NRSA63J-333X MG RESISTOR 33k$ 1/16W J
R542 NRSA63J-472X MG RESISTOR 4.7k$ 1/16W J
R543 NRSA63J-0R0X MG RESISTOR 0$ 1/16W J
R544 NRSA63J-0R0X MG RESISTOR 0$ 1/16W J
R545 NRSA63J-332X MG RESISTOR 3.3k$ 1/16W J
R547 NRSA63J-0R0X MG RESISTOR 0$ 1/16W J
R548 NRSA63J-332X MG RESISTOR 3.3k$ 1/16W J
R550 NRSA63J-0R0X MG RESISTOR 0$ 1/16W J
R551 NRSA63J-0R0X MG RESISTOR 0$ 1/16W J
R553 NRSA63J-0R0X MG RESISTOR 0$ 1/16W J
R554 NRSA63J-4R7X MG RESISTOR 4.7$ 1/16W J
R555 NRSA63J-0R0X MG RESISTOR 0$ 1/16W J
R556 NRSA02J-473X MG RESISTOR 47k$ 1/10W J
R557 NRSA63J-0R0X MG RESISTOR 0$ 1/16W J
R558 NRSA02J-823X MG RESISTOR 82k$ 1/10W J
R559 NRSA02J-821X MG RESISTOR 820$ 1/10W J
R560 NRS181J-0R0X MG RESISTOR 0$ 1/8W J
R561 NRSA63J-102X MG RESISTOR 1k$ 1/16W J
R562 NRSA63J-102X MG RESISTOR 1k$ 1/16W J
R565 NRSA63J-151X MG RESISTOR 150$ 1/16W J
R566 NRSA02J-100X MG RESISTOR 10$ 1/10W J
R574 NRSA63J-0R0X MG RESISTOR 0$ 1/16W J
R581 NRSA63J-0R0X MG RESISTOR 0$ 1/16W J
R582 NRSA63J-0R0X MG RESISTOR 0$ 1/16W J
R583 NRSA63J-153X MG RESISTOR 15k$ 1/16W J
R584 NRSA63J-153X MG RESISTOR 15k$ 1/16W J
R585 NRSA63J-103X MG RESISTOR 10k$ 1/16W J
R586 NRSA63J-103X MG RESISTOR 10k$ 1/16W J
R587 NRSA63J-303X MG RESISTOR 30k$ 1/16W J
R588 NRSA63J-303X MG RESISTOR 30k$ 1/16W J
R589 NRSA63J-152X MG RESISTOR 1.5k$ 1/16W J
R590 NRSA63J-152X MG RESISTOR 1.5k$ 1/16W J
R591 NRS181J-223X MG RESISTOR 22k$ 1/8W J
R592 NRSA63J-223X MG RESISTOR 22k$ 1/16W J
R593 NRSA63J-223X MG RESISTOR 22k$ 1/16W J
R594 NRSA63J-223X MG RESISTOR 22k$ 1/16W J
R701 NRSA63J-473X MG RESISTOR 47k$ 1/16W J
R703 NRSA63J-473X MG RESISTOR 47k$ 1/16W J
R704 NRSA63J-473X MG RESISTOR 47k$ 1/16W J
R705 NRSA63J-103X MG RESISTOR 10k$ 1/16W J
R706 NRSA63J-103X MG RESISTOR 10k$ 1/16W J
R707 NRSA63J-473X MG RESISTOR 47k$ 1/16W J
R708 NRSA63J-332X MG RESISTOR 3.3k$ 1/16W J
R709 NRSA63J-332X MG RESISTOR 3.3k$ 1/16W J
R710 NRSA63J-332X MG RESISTOR 3.3k$ 1/16W J
R711 NRS181J-103X MG RESISTOR 10k$ 1/8W J
R712 NRSA63J-472X MG RESISTOR 4.7k$ 1/16W J
R713 NRSA63J-472X MG RESISTOR 4.7k$ 1/16W J
R715 NRSA63J-473X MG RESISTOR 47k$ 1/16W J
R716 NRSA63J-473X MG RESISTOR 47k$ 1/16W J
R717 NRSA63J-473X MG RESISTOR 47k$ 1/16W J
R718 NRSA63J-103X MG RESISTOR 10k$ 1/16W J
R719 NRSA63J-0R0X MG RESISTOR 0$ 1/16W J
R723 NRSA63J-472X MG RESISTOR 4.7k$ 1/16W J
R724 NRSA63J-472X MG RESISTOR 4.7k$ 1/16W J
R725 NRSA63J-472X MG RESISTOR 4.7k$ 1/16W J
R726 NRSA63J-472X MG RESISTOR 4.7k$ 1/16W J
R727 NRSA63J-472X MG RESISTOR 4.7k$ 1/16W J
R728 NRSA63J-472X MG RESISTOR 4.7k$ 1/16W J
 Symbol No. Part No. Part Name Description Local
R729 NRSA63J-473X MG RESISTOR 47k$ 1/16W J
R730 NRSA63J-103X MG RESISTOR 10k$ 1/16W J
R731 NRSA63J-103X MG RESISTOR 10k$ 1/16W J
R732 NRSA63J-102X MG RESISTOR 1k$ 1/16W J
R733 NRSA63J-473X MG RESISTOR 47k$ 1/16W J
R735 NRSA63J-472X MG RESISTOR 4.7k$ 1/16W J
R736 NRSA63J-103X MG RESISTOR 10k$ 1/16W J
R737 NRSA63J-472X MG RESISTOR 4.7k$ 1/16W J
R738 NRSA63J-472X MG RESISTOR 4.7k$ 1/16W J
R739 NRSA63J-103X MG RESISTOR 10k$ 1/16W J
R740 NRSA63J-103X MG RESISTOR 10k$ 1/16W J
R741 NRSA63J-473X MG RESISTOR 47k$ 1/16W J
R742 NRSA63J-512X MG RESISTOR 5.1k$ 1/16W J
R743 NRSA63J-473X MG RESISTOR 47k$ 1/16W J
R745 NRSA63J-473X MG RESISTOR 47k$ 1/16W J
R749 NRSA63J-473X MG RESISTOR 47k$ 1/16W J
R751 NRSA63J-103X MG RESISTOR 10k$ 1/16W J
R752 NRSA63J-103X MG RESISTOR 10k$ 1/16W J
R753 NRSA63J-103X MG RESISTOR 10k$ 1/16W J
R754 NRSA63J-103X MG RESISTOR 10k$ 1/16W J
R755 NRSA63J-473X MG RESISTOR 47k$ 1/16W J
R756 NRSA63J-473X MG RESISTOR 47k$ 1/16W J
R801 NRSA63J-104X MG RESISTOR 100k$ 1/16W J
R802 NRSA63J-104X MG RESISTOR 100k$ 1/16W J
R803 NRSA63J-101X MG RESISTOR 100$ 1/16W J
R804 NRSA63J-334X MG RESISTOR 330k$ 1/16W J
R805 NRSA63J-334X MG RESISTOR 330k$ 1/16W J
R806 NRSA63J-104X MG RESISTOR 100k$ 1/16W J
R807 NRSA63J-101X MG RESISTOR 100$ 1/16W J
R808 NRSA63J-223X MG RESISTOR 22k$ 1/16W J
R809 NRSA63J-103X MG RESISTOR 10k$ 1/16W J
R810 NRSA63J-104X MG RESISTOR 100k$ 1/16W J
R811 NRSA63J-4R7X MG RESISTOR 4.7$ 1/16W J
R901 NRSA63J-912X MG RESISTOR 9.1k$ 1/16W J
R902 QRE142J-102X C RESISTOR 1k$ 1/4W J
R903 NRSA63J-472X MG RESISTOR 4.7k$ 1/16W J
R905 NRSA63J-102X MG RESISTOR 1k$ 1/16W J
R906 NRSA63J-102X MG RESISTOR 1k$ 1/16W J
R907 NRSA63J-123X MG RESISTOR 12k$ 1/16W J
R908 NRSA63J-273X MG RESISTOR 27k$ 1/16W J
R909 NRSA63J-273X MG RESISTOR 27k$ 1/16W J
R910 NRSA63J-473X MG RESISTOR 47k$ 1/16W J
R911 NRSA02J-222X MG RESISTOR 2.2k$ 1/10W J
R912 NRSA02J-222X MG RESISTOR 2.2k$ 1/10W J
R971 NRSA02J-101X MG RESISTOR 100$ 1/10W J
R972 NRSA02J-101X MG RESISTOR 100$ 1/10W J
L1 QQL244J-4R7Z COIL 4.7uH J
L571 QQL244K-4R7Z COIL 4.7uH K
L701 QQL244K-4R7Z COIL 4.7uH K
L901 QQR0703-001 CHOKE COIL
CN501 QGB2027M4-22S CONNECTOR B-B (1-22)
CN701 QGZ1601J1-15 CONNECTOR (1-15)
CN901 QNZ0611-001 16P CONNECTOR
J1 QNB0190-001 ANTENNA JACK
J321 QNN0519-001 PIN JACK
J801 QNZ0095-001 CONNECTOR
TU1 QAU0394-001 TUNER PACK
X521 QAX0714-001Z C RESONATOR 16.000MHz
X701 QAX0406-001Z CRYSTAL 4.500MHz
 Symbol No. Part No. Part Name Description Local
IC601 PT6523LQ-L LCD DRIVER
IC602 RPM7338-V4 RM.RECEIVER
Q671 2SB624/4/-X TRANSISTOR
Q672 UN2211-X TRANSISTOR
D601 SML-310VT/JK/-X LED
 Symbol No. Part No. Part Name Description Local
