JVC KD-S550

Item
Parts number
Parts name
Area
A
Electrical parts list (Main board)
Remarks
Block No.
01
C 906
NCB21EK-104X
C CAPACITOR
C 907
NCB21HK-103X
C CAPACITOR
C 908
QERF1AM-107Z
E CAPACITOR
100MF 20% 10V
C 909
QERF1AM-107Z
E CAPACITOR
100MF 20% 10V
C 910
NCB21HK-103X
C CAPACITOR
C 911
QERF1AM-227Z
E CAPACITOR
220MF 20% 10V
C 914
NCB21HK-104X
C CAPACITOR
C 915
NCB11CK-225X
C CAPACITOR
KD-S600J/550E
CJ321
QNN0170-001
PIN JACK (REEL)
CJ701
QNZ0009-001
CAR ANT JACK
CN50
QGB2027M1-26S
CONNECTOR
CN80
VMC0334-001
CONNECTOR
CN90
QNZ0002-001
16P CONNECTOR
D 321
1SS254-T2
SI DIODE
D 332
MA152WA-X
DIODE
D 551
DSK10C-T1
DIODE
D 552
DSK10C-T1
DIODE
D 553
DSK10C-T1
DIODE
D 701
1SS254-T2
SI DIODE
D 702
1SS254-T2
SI DIODE
D 711
MA152WK-X
SI DIODE
KD-S550 E
D 731
MTZJ10B-T2
ZENER DIODE
D 801
1SS254-T2
SI.DIODE
KD-S550 E
D 810
MA152WA-X
DIODE
D 861
MTZJ4.7B-T2
Z DIODE I M
D 866
MA152WA-X
DIODE
D 867
MA152WK-X
SI DIODE
D 901
1N5401-TU-15
DIODE
D 902
SB10-03A3-T2
SB DIODE
D 903
1SS254-T2
SI DIODE
D 904
CRS03-W
SB DIODE
IC151
NJM4565M-WE
IC
IC301
TEA6320T-X
IC
IC321
HA13158A
IC
IC501
AN8806SB-W
IC
IC541
LA6557-X
IC
IC561
MN35510
IC
IC801
JES01-9597
I.C(MICRO-COMP)
IC901
BA4905-V3
IC
L 501
QQL231K-4R7Y
INDUCTOR
L 561
QQL231K-4R7Y
INDUCTOR
L 562
QQL231K-4R7Y
INDUCTOR
L 701
QQL231K-330Y
INDUCTOR
L 801
QQL231K-4R7Y
INDUCTOR
L 901
QQR0703-001
CHOKE COIL
Q 321
DTC114EKA-X
TRANSISTOR
Q 332
2SD1048/6-7/-X
TRANSISTOR
Q 432
2SD1048/6-7/-X
TRANSISTOR
Q 501
2SA1706/ST/-T
TRANSISTOR
Q 541
2SA1706/ST/-T
TRANSISTOR
Q 701
DTC114EKA-X
TRANSISTOR
Q 702
DTC144EKA-X
DIGI.TRANSISTOR
KD-S550 E
Q 703
DTA144EKA-X
DIGI.TRANSISTOR
KD-S550 E
Q 731
2SC2412K/R/-X
TRANSISTOR
Q 732
2SC2412K/R/-X
TRANSISTOR
Q 791
2SB1197K/QR/-X
TRANSISTOR
Q 793
DTC114EKA-X
TRANSISTOR
KD-S600J/S550J
Q 793
DTC144EKA-X
DIGI.TRANSISTOR
KD-S550 E
Q 861
DTA114EKA-X
DIGITAL.TRANSIS
Q 902
2SC2412K/R/-X
TRANSISTOR
Q 903
2SA1037AK/RS/-X
TRANSISTOR
R 101
NRSA02J-202X
MG RESISTOR
KD-S550 E
R 101
NRSA02J-392X
MG RESISTOR
KD-S600J/S550J
R 102
NRSA02J-432X
MG RESISTOR
KD-S600J/S550J
R 102
NRSA02J-562X
MG RESISTOR
KD-S550 E
R 151
NRSA02J-102X
MG RESISTOR
R 152
NRSA02J-223X
MG RESISTOR
R 153
NRSA02J-333X
MG RESISTOR
R 154
NRSA02J-223X
MG RESISTOR
R 155
NRSA02J-102X
MG RESISTOR
R 156
NRS181J-223X
MG RESISTOR
R 157
NRSA02J-223X
MG RESISTOR
R 201
NRS181J-392X
MG RESISTOR
KD-S600J/S550J
R 201
NRS181J-202X
MG RESISTOR
KD-S550 E
R 202
NRSA02J-562X
MG RESISTOR
KD-S550 E
R 202
NRSA02J-432X
MG RESISTOR
KD-S600J/S550J
R 251
NRSA02J-102X
MG RESISTOR
R 252
NRSA02J-223X
MG RESISTOR
R 253
NRSA02J-333X
MG RESISTOR
R 254
NRSA02J-223X
MG RESISTOR
R 255
NRSA02J-102X
MG RESISTOR
R 256
NRSA02J-223X
MG RESISTOR
R 257
NRSA02J-223X
MG RESISTOR
R 301
NRSA02J-223X
MG RESISTOR
R 302
NRSA02J-222X
MG RESISTOR
R 303
NRSA02J-473X
MG RESISTOR
R 304
NRSA02J-473X
MG RESISTOR
R 307
NRSA02J-273X
MG RESISTOR
R 308
NRSA02J-273X
MG RESISTOR
R 321
NRSA02J-473X
MG RESISTOR
R 322
NRSA02J-181X
MG RESISTOR
R 323
NRS181J-472X
MG RESISTOR
R 333
NRSA02J-102X
MG RESISTOR
R 334
NRSA02J-101X
MG RESISTOR
R 336
NRSA02J-222X
MG RESISTOR
R 401
NRSA02J-223X
MG RESISTOR
R 402
NRSA02J-222X
MG RESISTOR
R 403
NRSA02J-473X
MG RESISTOR
R 404
NRSA02J-473X
MG RESISTOR
R 407
NRSA02J-273X
MG RESISTOR
R 408
NRSA02J-273X
MG RESISTOR
R 433
NRSA02J-102X
MG RESISTOR
R 434
NRSA02J-101X
MG RESISTOR
R 436
NRSA02J-222X
MG RESISTOR
R 501
NRSA02J-220X
MG RESISTOR
R 502
NRSA02J-220X
MG RESISTOR
R 503
NRS181J-102X
MG RESISTOR
R 504
NRSA02J-392X
MG RESISTOR
R 505
NRSA02J-224X
MG RESISTOR
R 506
NRSA02J-223X
MG RESISTOR
R 507
NRSA02J-332X
MG RESISTOR
R 508
NRSA02J-683X
MG RESISTOR
R 509
NRSA02J-153X
MG RESISTOR
R 510
NRSA02J-154X
MG RESISTOR
R 511
NRSA02J-274X
MG RESISTOR
R 512
NRSA02J-563X
MG RESISTOR
R 513
NRSA02J-563X
MG RESISTOR
R 514
NRS181J-123X
MG RESISTOR
R 515
NRSA02J-123X
MG RESISTOR
R 516
NRSA02J-123X
MG RESISTOR
R 517
NRSA02J-123X
MG RESISTOR
R 541
NRSA02J-102X
MG RESISTOR
R 542
NRSA02J-822X
MG RESISTOR
R 543
NRSA02J-303X
MG RESISTOR
R 544
NRSA02J-332X
MG RESISTOR
R 545
NRSA02J-123X
MG RESISTOR
R 546
NRSA02J-563X
MG RESISTOR
R 547
NRSA02J-154X
MG RESISTOR
R 548
NRSA02J-822X
MG RESISTOR
R 550
NRSA02J-123X
MG RESISTOR
R 560
NRS181J-101X
MG RESISTOR
R 561
NRS181J-102X
MG RESISTOR
R 562
NRS181J-102X
MG RESISTOR
R 563
NRS181J-102X
MG RESISTOR
