JVC KD-S550 Service Manual

Item
Parts number
Parts name
Area
A
Electrical parts list (Main board)
Remarks
Block No.
01
R 564
NRS181J-102X
MG RESISTOR
R 567
NRS181J-102X
MG RESISTOR
R 568
NRS181J-102X
MG RESISTOR
R 569
NRSA02J-102X
MG RESISTOR
R 570
NRSA02J-102X
MG RESISTOR
R 571
NRSA02J-683X
MG RESISTOR
R 572
NRSA02J-105X
MG RESISTOR
R 573
NRSA02J-124X
MG RESISTOR
R 574
NRSA02J-331X
MG RESISTOR
R 701
NRS181J-102X
MG RESISTOR
R 702
NRSA02J-0R0X
MG RESISTOR
KD-S600J/S550J
R 702
NRSA02J-151X
MG RESISTOR
KD-S550 E
R 703
NRSA02J-102X
MG RESISTOR
R 704
NRSA02J-0R0X
MG RESISTOR
KD-S600 J
R 704
NRSA02J-151X
MG RESISTOR
KD-S550 E
R 705
NRSA02J-103X
MG RESISTOR
R 708
NRSA02J-155X
MG RESISTOR
R 725
NRSA02J-151X
MG RESISTOR
KD-S600 J
R 725
NRSA02J-470X
MG RESISTOR
KD-S550E/S550J
R 731
NRS181J-152X
MG RESISTOR
R 732
NRSA02J-102X
MG RESISTOR
R 733
NRS181J-103X
MG RESISTOR
R 734
NRSA02J-471X
MG RESISTOR
R 791
NRSA02J-103X
MG RESISTOR
R 792
NRS181J-102X
MG RESISTOR
R 795
NRSA02J-150X
MG RESISTOR
R 796
NRSA02J-150X
MG RESISTOR
R 798
NRSA02J-105X
MG RESISTOR
R 801
NRS181J-103X
MG RESISTOR
R 803
NRS181J-332X
MG RESISTOR
R 804
NRS181J-332X
MG RESISTOR
R 805
NRS181J-332X
MG RESISTOR
R 807
NRS181J-473X
MG RESISTOR
R 808
NRS181J-102X
MG RESISTOR
R 809
NRS181J-103X
MG RESISTOR
R 810
NRSA02J-104X
MG RESISTOR
R 811
NRSA02J-332X
MG RESISTOR
R 812
NRSA02J-332X
MG RESISTOR
R 813
NRSA02J-473X
MG RESISTOR
R 814
NRSA02J-473X
MG RESISTOR
R 815
NRSA02J-473X
MG RESISTOR
R 816
NRSA02J-473X
MG RESISTOR
R 817
NRS181J-472X
MG RESISTOR
R 818
NRS181J-473X
MG RESISTOR
KD-S550 J/E
R 822
NRSA02J-222X
MG RESISTOR
R 823
NRSA02J-473X
MG RESISTOR
R 825
NRS181J-473X
MG RESISTOR
KD-S600J/S550J
R 825
NRS181J-123X
MG RESISTOR
KD-S550 E
R 826
NRSA02J-473X
MG RESISTOR
R 827
NRSA02J-473X
MG RESISTOR
R 828
NRSA02J-473X
MG RESISTOR
R 829
NRS181J-473X
MG RESISTOR
R 830
NRS181J-223X
MG RESISTOR
R 831
NRSA02J-472X
MG RESISTOR
R 832
NRS181J-223X
MG RESISTOR
R 833
NRSA02J-472X
MG RESISTOR
R 834
NRS181J-223X
MG RESISTOR
R 835
NRS181J-472X
MG RESISTOR
R 836
NRSA02J-473X
MG RESISTOR
R 861
NRS181J-471X
MG RESISTOR
R 862
NRS181J-471X
MG RESISTOR
R 902
QRZ0125-472X
C RESISTOR
4.7K 1/1W
R 903
NRSA02J-202X
MG RESISTOR
R 904
NRSA02J-104X
MG RESISTOR
R 905
NRSA02J-472X
MG RESISTOR
R 906
NRSA02J-472X
MG RESISTOR
R 907
NRSA02J-393X
MG RESISTOR
R 908
NRSA02J-683X
MG RESISTOR
R 909
NRSA02J-273X
MG RESISTOR
R 910
NRSA02J-473X
MG RESISTOR
R 911
NRS181J-473X
MG RESISTOR
KD-S600J/550E
SP 1
VYSH101-009
SPACER
KD-S600 J
SP 2
VYSH101-009
SPACER
KD-S600 J
TU70
QAU0153-001
FM FRONT END
KD-S550 J
TU70
QAU0171-001
TUNER
KD-S600J/S550E
X 561
QAX0413-001Z
CRYSTAL
X 801
QAX0406-001Z
CRYSTAL
Item
Parts number
Parts name
Area
A
Remarks
