JVC KD-S550 Service Manual

Item
Parts number
Parts name
Area
A
Electrical parts list (Front board)
Remarks
Block No.
02
C 601
NCB21HK-223X
C CAPACITOR
C 602
NCS21HJ-681X
C CAPACITOR
C 603
NBE20JM-106X
TS E CAP SVB20J
C 611
NCB21HK-123X
C CAPACITOR
KD-S600 J
C 612
NBE20JM-475X
TS E CAPACITOR
KD-S600 J
CJ601
VMC0335-001
CONNECTOR
D 601
LNJ308G81/1-3/X
LED
D 602
LNJ308G81/1-3/X
LED
D 603
LNJ308G81/1-3/X
LED
D 604
LNJ308G81/1-3/X
LED
D 605
LNJ308G81/1-3/X
LED
D 606
LNJ308G81/1-3/X
LED
D 607
LNJ308G81/1-3/X
LED
D 608
LNJ308G81/1-3/X
LED
D 609
LNJ308G81/1-3/X
LED
D 610
LNJ308G81/1-3/X
LED
D 611
LNJ308G81/1-3/X
LED
D 612
LNJ308G81/1-3/X
LED
D 613
LNJ308G81/1-3/X
LED
D 614
LNJ308G81/1-3/X
LED
D 615
LNJ308G81/1-3/X
LED
D 616
LNJ308G81/1-3/X
LED
D 617
SML-310VT/JK/-X
LED
KD-S600 J
D 617
LNJ308G81/1-3/X
LED
KD-S550 E/J
D 618
LNJ308G81/1-3/X
LED
KD-S550 E/J
D 618
SML-310VT/JK/-X
LED
KD-S600 J
D 619
SML-310VT/JK/-X
LED
KD-S600 J
D 619
LNJ308G81/1-3/X
LED
KD-S550 E/J
D 620
LNJ308G81/1-3/X
LED
D 621
SML-310LT/MN/-X
LED
POWER LED
D 641
MA3047/M/-X
ZENER DIODE
D 642
MA152WK-X
SI DIODE
IC601
LC75823W
IC
IC602
RPM6938-SV4
IC
KD-S600 J
PL601
QLL0056-001
PILOT LAMP
KD-S550 E
PL601
QLL0033-003
LAMP
KD-S600J/S550J
PL602
QLL0033-003
LAMP
KD-S600J/S550J
PL602
QLL0056-001
PILOT LAMP
KD-S550 E
R 601
NRSA02J-681X
MG RESISTOR
R 602
NRSA02J-511X
MG RESISTOR
R 603
NRSA02J-681X
MG RESISTOR
R 604
NRSA02J-911X
MG RESISTOR
R 605
NRSA02J-122X
MG RESISTOR
R 606
NRSA02J-681X
MG RESISTOR
R 607
NRSA02J-511X
MG RESISTOR
R 608
NRSA02J-681X
MG RESISTOR
R 609
NRSA02J-911X
MG RESISTOR
R 610
NRSA02J-122X
MG RESISTOR
R 611
NRSA02J-152X
MG RESISTOR
R 612
NRSA02J-222X
MG RESISTOR
R 613
NRSA02J-681X
MG RESISTOR
R 614
NRSA02J-511X
MG RESISTOR
R 615
NRSA02J-681X
MG RESISTOR
R 616
NRSA02J-911X
MG RESISTOR
R 617
NRSA02J-122X
MG RESISTOR
R 618
NRSA02J-152X
MG RESISTOR
R 631
NRSA02J-821X
MG RESISTOR
R 632
NRSA02J-271X
MG RESISTOR
KD-S550 E/J
R 632
NRSA02J-391X
MG RESISTOR
KD-S600 J
R 633
NRSA02J-391X
MG RESISTOR
KD-S600 J
R 633
NRSA02J-271X
MG RESISTOR
KD-S550 E/J
R 634
NRSA02J-271X
MG RESISTOR
R 635
NRSA02J-271X
MG RESISTOR
R 636
NRSA02J-271X
MG RESISTOR
R 637
NRSA02J-271X
MG RESISTOR
R 638
NRSA02J-271X
MG RESISTOR
R 639
NRSA02J-271X
MG RESISTOR
R 640
NRSA02J-271X
MG RESISTOR
R 641
NRSA02J-271X
MG RESISTOR
R 651
NRSA02J-222X
MG RESISTOR
R 652
NRSA02J-222X
MG RESISTOR
R 653
NRSA02J-103X
MG RESISTOR
R 654
NRSA02J-103X
MG RESISTOR
R 655
NRSA02J-103X
MG RESISTOR
R 656
NRSA02J-103X
MG RESISTOR
R 657
NRSA02J-513X
MG RESISTOR
R 658
NRSA02J-184X
MG RESISTOR
R 661
NRSA02J-103X
MG RESISTOR
KD-S600 J
R 662
NRSA02J-471X
MG RESISTOR
KD-S600 J
S 601
NSW0124-001X
TACT SWITCH
POWER
S 602
NSW0124-001X
TACT SWITCH
VOL UP
S 603
NSW0124-001X
TACT SWITCH
VOL DOWN
S 604
NSW0124-001X
TACT SWITCH
LOUD
S 605
NSW0124-001X
TACT SWITCH
MO
S 606
NSW0124-001X
TACT SWITCH
DOWN
S 607
NSW0124-001X
TACT SWITCH
SELECT
S 608
NSW0124-001X
TACT SWITCH
UP
S 609
NSW0124-001X
TACT SWITCH
1
S 610
NSW0124-001X
TACT SWITCH
2
S 611
NSW0124-001X
TACT SWITCH
3
S 612
NSW0124-001X
TACT SWITCH
4
S 613
NSW0124-001X
TACT SWITCH
5
S 614
NSW0124-001X
TACT SWITCH
EJECT
S 615
NSW0124-001X
TACT SWITCH
6
S 616
NSW0124-001X
TACT SWITCH
DISPLAY
S 617
NSW0124-001X
TACT SWITCH
SCAN
S 618
NSW0124-001X
TACT SWITCH
SOUND
S 619
NSW0124-001X
TACT SWITCH
AM
S 620
NSW0124-001X
TACT SWITCH
FM
S 621
NSW0124-001X
TACT SWITCH
CD
Item
Parts number
Parts name
Area
A
Remarks
