JVC KD-S777R

Item
Parts number
Parts name
Area
A
Parts list ( CD mechanism )
Q'ty
Description
Block No.
M2MM
1
30310101T
FRAME
1
2
30310103T
DANPER PIN
2
3
30310107T
UPPER PLATE
1
4
30310108T
SEL STOP PLATE
1
5
30310142T
SEL ARM (L)L
1
6
30310143T
SEL ARM (R)L
1
7
30310145T
S ARM SPRING(L)
2
8
30310112T
TRIG LEVER
1
9
30310155T
TRIG PL(Z)
1
10
30310115T
TRIG PL SPRING
1
11
30310116T
TRIG ARM
1
12
30310134T
FIX ARM (L)B
1
13
30310159T
FIX ARM (R)Z
1
14
30310150T
FIX PL (L)Z
1
15
30310156T
FIX PL (R) Z
1
16
30310138T
LDG GR (6)B
1
17
30310122T
LDG GEAR (6)SP
1
18
30310148T
S.L ARM(N)
1
19
30310125T
S.L ARM SPRING
1
20
30310149T
REAR DAM BKT(Z)
1
22
30310151T
HUNG UP SP (FZ)
2
23
30310129T
HUNG UP SP (R)
2
29
30300510T
PU GEAR(B)
1
30
---------------
T.T.BASE(Z)
1
31
---------------
TURN TABLE(Z)
1
32
30310544T
F.M.BASE(Z)
1
33
30310547T
FD GR BLK(Z)
1
34
---------------
FD GR AZ
1
35
---------------
FD GR CZ
1
36
30310546T
PU GUIDE(Z)
1
37
---------------
FD SCREW(Z)
1
38
30310533T
THRUST SPR(M)
1
39
30310548T
PU M NUT(Z)
1
40
30310512T
NUT PUSH SPR PL
1
41
30310558T
CLP ARM(Z)
1
42
30310514T
CLP ARM SPRING
1
43
30310552T
CLAMPER(Z)
1
46
---------------
LOCK PIN(FZ)
2
47
---------------
LOCK PIN(RZ)
2
48
30310557T
CLAMPER PLATE(Z
1
49
30310524T
DAMPER (J)
3
50
30310525T
CLP ARM SPR (L)
1
51
30310545T
F SCREW GUIDE(Z
1
52
30310556T
PU G.SP PLT(Z)
1
54
---------------
FEED MOTOR
2
FF030PK-09210
55
---------------
SPINDLE MOTOR
1
RF300CA-11440D
56
64180405T
DET SW
1
ESE11SF4
57
OPTIMA-720L1
C.D PICK (CAR)
1
