JVC KD-S777R

Item
Parts number
Parts name
Area
A
Parts list ( CD mechanism )
Q'ty
Description
Block No.
M2MM
61
30311035T
FPC HOLDER(Z)
1
62
19501403T
WIRE CLAMPER
3
63
30311037T
PICK UP FPC(Z)
1
64
30311036T
CONNECT.PCB(Z-J
1
65
30311038T
WIRE (5P-Z)
1
66
30311039T
WIRE (LD-Z)
1
67
30311040T
WIRE (FD-Z)
1
68
30311041T
WIRE (RS-Z)
1
70
64180402T
DET SWITCH
2
ESE22MH1
71
64180403T
DET SWITCH
2
ESE22MH3
72
68150232T
CONNECTOR
1
TKC-W26X-C1
78
---------------
LDG PULLEY
1
79
30311105T
SOPPORT PLATE
1
80
30311138T
GR MT BLK(N)
1
81
30311109T
LDG GEAR (2)
1
82
30311110T
LDG GEAR (3)
1
83
---------------
LDG GEAR (4)
1
84
30311112T
LDG GEAR (5)
1
85
---------------
LDG GR ARM
1
86
30311136T
LDG ROLLER
2
87
---------------
LDG RLR SHAFT
1
88
30311118T
L.P SPRING (L)
1
89
30311119T
L.P SPRING (R)
1
90
30311123T
SW PCB
1
91
30311124T
SW ACTUATOR
1
92
30311129T
LDG BELT
1
93
30311140T
FRONT BRKT (J)
1
100
9C0620503T
C B TAP SCREW
2
M2X5
101
9C2020401T
C SCREW TS.G
5
M2X4
102
9C4320403T
C B TAP SCREW
4
M2X4
103
9C0117223T
SCREW
2
M1.7X2.2
104
9C4217703T
C TAP SCREW S3
1
M1.7X7
105
9C0320201T
C TAP SCREW S3
1
M2X2
106
9C4920013T
C TAP SCREW S3
2
M2X10
107
9C4920603T
C TAP SCREW B3
4
M2X6
108
9P0220031T
TAMS SCREW
2
M2X3
109
9C0314203T
C TAP SCREW
1
M1.4X2
110
9C0420253
C TAP SCREW
1
M2X2.5
112
---------------
POLY WASHER
1
2.1X3.5X0.3
113
9W0330276
NW BLUE
2
2.9X5X0.3
114
---------------
WAVE WASHER
1
115
---------------
LUMILAR WASHER
1
2.5X6X0.1
116
9W0725030T
LUMILAR WASHER
1
2.3X9.8X0.25
117
9W0640030T
WASHER
1
1.4X3.2X0.4
130
303105310T
FEED MO ASSY
1
131
303105311T
SPINDLE MO ASSY
1
132
303105312T
FEED SCREW ASSY
1
133
303111301T
LDG MOTOR ASSY
1
134
303111302T
ROLLER SHAFT
1
303111302T
ROLLER SHAFT
1
135
303105502T
T.T.BASE ASSY
1
NO.34,54
NO.31,55,112
NO.35,37
NO.54,78
NO.83,85,87
NO.114,115
NO.30,46,47
